Acura RLX Hybrid (2017 year). Manual - part 2

21

Quick

 Referenc

e Guide

Features

(P 211)

Audio system

(P 216)

*1:Icons that appear on the screen vary by the source selected.

Audio/Information Screen

Interface Dial/ENTER Button

 (Power) Button

CD Slot

 (CD Eject) Button

SETTINGS Button

VOL (Volume) Knob

BACK Button

NAV Button

AUDIO Button

INFO Button

On Demand Multi-Use Display

TM

PHONE Button

Preset Icons

*1

 (Tune Up) Icon

*1

Audio Source

*1

 (Tune Down) Icon

*1

Tune

TAG

*1

More

 Button

Shortcuts

*1

MENU Button

17 ACURA RLX E-AWD-31TY36300.book  21 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

22

Quick

 Referenc

e Guide

Audio Remote Controls

(P 215)

● SOURCE Button

Press to change the audio mode: FM/AM/
SiriusXM®/CD/HDD/USB/iPod/

Bluetooth®

Audio/Pandora®

*

/Aha

TM

/AUX.

● Left Selector Wheel

Roll to adjust the volume up/down.
Radio:Shift to change the preset station.

Shift and hold to select the next or
previous strong station.

CD/HDD/USB device:

Shift to skip to the beginning of
the next song or return to the
beginning of the current song.
Shift and hold to change a folder.

Left Selector Wheel

SOURCE Button

17 ACURA RLX E-AWD-31TY36300.book  22 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

23

Quick

 Referenc

e Guide

Driving

(P 357)

Electronic Gear Selector

(P 371)

● Select

(

P and depress the brake pedal when turning on the power.

Park
Press the

(

P button.

Used when parking or before turning the power on or off.
Transmission is locked.

Reverse
Press back the

(

R button.

Used when reversing.

Neutral
Press the

(

N button.

Transmission is not locked.

Drive
Press the

(

D button.

Used for normal driving.
The sequential shift mode can be used.

Gear Position Indicator
The gear position indicator
and the shift button indicator
indicate the current gear
selection.

Gear Position Indicator

Shift Button
Indicator

● Gear selection

* Not available on all models

17 ACURA RLX E-AWD-31TY36300.book  23 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

24

Quick

 Referenc

e Guide

Paddle Shifters

(P377)

● Paddle shifters allow you to shift gears much like a manual

transmission (1st through 7th). This is useful for regenerative
braking.

● D-paddle shift mode: The

transmission will shift back to
automatic mode once the system
detects that the vehicle is cruising.

● Sequential mode gear selection:

Holds the selected gear, and the
M (sequential mode) indicator
comes on, when the SPORT mode
is on.

● The sequential mode gear

selection is shown in the
instrument panel.

Gear Position Indicator

Shift Down

(

-

Paddle Shifter

Shift Up

(

+

Paddle Shifter

Sequential Mode Gear

Selection Indicator

M (sequential

mode) Indicator

17 ACURA RLX E-AWD-31TY36300.book  24 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

25

Quick

 Referenc

e Guide

VSA® OFF Button

(P 409)

● The vehicle stability assist (VSA®) system

helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

● VSA® comes on automatically every time

you turn on the power system.

● To turn VSA® on or off, press and hold

the button until you hear a beep.

Collision Mitigation
Braking System

TM

 (CMBS

TM

)

OFF Button

(P 429)

● When a possible collision is likely

unavoidable, the CMBS

TM

 can help you to

reduce the vehicle speed and the severity
of the collision.

● To turn the CMBS

TM

 on or off, press and

hold the button until you hear a beep.

Tire Pressure Monitoring
System (TPMS)

(P 414)

● The TPMS monitors tire pressure.

● The TPMS is turned on automatically

every time you turn on the power system.

Refueling

(P 455)

a

Press the fuel fill
door release button.

b

After refueling, wait
for about five
seconds before
removing the filler
nozzle.

Fuel recommendation: Unleaded premium gasoline with a pump octane

number 91 or higher recommended

Fuel tank capacity: 15.1 US gal (57 L)

Wait for five seconds

17 ACURA RLX E-AWD-31TY36300.book  25 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

26

Quick

 Referenc

e Guide

Maintenance

(P 459)

Under the Hood

(P 468)

● Check engine oil and engine coolant, inverter coolant. Add

when necessary.

● Check brake fluid.

● Check the 12-volt battery condition monthly.

a

Pull the hood release handle under the corner of the
dashboard.

b

Locate the hood latch lever, push up the lever and lift the
hood.

c

When finished, close the hood and make sure it is firmly
locked in place.

Lights

(P 480)

● Inspect all lights regularly.

Wiper Blades

(P 485)

● Replace blades if they leave streaks

across the windshield.

Tires

(P 488)

● Inspect tires and wheels regularly.

● Check tire pressures regularly.

● Install snow tires for winter driving.

17 ACURA RLX E-AWD-31TY36300.book  26 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

Quick

 Referenc

e Guide

27

Handling the Unexpected

(P 509)

Flat Tire

(P 511)

● Park in a safe location and repair the flat

tire using the temporary tire repair kit.

Park in a safe location and replace the
flat tire with the compact spare tire in the
trunk.

Indicators Come On

(P 537)
● Identify the indicator and consult the

owner’s manual.

Vehicles with optional spare tire kit

Power System Won’t Start

(P 529)

● If the 12-volt battery is dead, jump start

using a booster battery.

Blown Fuse


(P 542)

● Check for a blown fuse if an electrical

device does not operate.

Overheating

(P 535)

● Park in a safe location. If you do not see

steam under the hood, open the hood,
and let the power system and the engine
cool down.

Emergency Towing

(P 548)
● Call a professional towing service if you

need to tow your vehicle.

17 ACURA RLX E-AWD-31TY36300.book  27 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

28

Quick

 Referenc

e Guide

What to Do If

Why does the brake pedal
pulsate slightly when
applying the brakes?

This can occur when the ABS activates, and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.

The rear door cannot be
opened from inside the
vehicle. Why?

Check if the childproof lock is in
the LOCK position. If so, open the
rear door with the outside door
handle.
To cancel this function, push the
lever to the UNLOCK position.

Why do the doors lock
after I unlocked the doors
using a remote
transmitter?

If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.

Why does the beeper
sound when I open the
driver’s door?

The beeper sounds when:

●

The power mode is in ACCESSORY.

●

The exterior lights are left on.

17 ACURA RLX E-AWD-31TY36300.book  28 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

29

Quick

 Referenc

e Guide

Why does the beeper
sound when I start driving?

The beeper sounds when the driver and/or front passenger are
not wearing their seat belts.

Why do I hear a screeching
sound when I apply the
brake pedal?

The brake pads may need to be replaced. Have your vehicle
inspected by a dealer.

Pressing the electric
parking brake switch does
not release the parking
brake. Why?

Press the electric parking brake switch with the brake pedal
depressed.

Depressing the accelerator
pedal does not release the
parking brake
automatically. Why?

●

Fasten the driver’s seat belt.

●

Check if the transmission is in

(

P

 or

(

N

. If so, select any other

position.

Why does the gear position
automatically change to

(

P



when I open the driver's
door to check for parking
space lines when
reversing?

●

Fasten the driver’s seat belt.

●

Close the driver's door and manually change the gear
position.

u

When opening the driver’s door



(P 374)

17 ACURA RLX E-AWD-31TY36300.book  29 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

30

Quick

 Referenc

e Guide

Is it possible to use
unleaded gasoline with a
Pump Octane Number
(PON) of 87 or lower on
this vehicle?

Unleaded gasoline with a Pump Octane Number (PON) of 91 or
higher is recommended.
Use of lower octane gasoline can cause occasional metallic
knocking noise in the engine and will result in decreased engine
performance.
Use of gasoline with a pump octane less than 87 can lead to
engine damage.

17 ACURA RLX E-AWD-31TY36300.book  30 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

31

Safe Driving

You can find many safety recommendations throughout this chapter, and throughout this manual.

For Safe Driving

Important Safety Precautions.............. 32
Your Vehicle’s Safety Features............ 34
Safety Checklist ................................. 35

Seat Belts

About Your Seat Belts ........................ 36
Fastening a Seat Belt .......................... 39
Seat Belt Inspection............................ 42

Airbags

Airbag System Components ............... 43
Types of Airbags ................................ 46
Front Airbags (SRS) ............................ 46

Driver’s Knee Airbag .......................... 50
Side Airbags....................................... 52
Side Curtain Airbags .......................... 54
Airbag System Indicators.................... 55
Airbag Care ....................................... 57

Child Safety

Protecting Child Passengers ............... 58
Safety of Infants and Small Children....... 60
Safety of Larger Children ................... 68

Exhaust Gas Hazard

Carbon Monoxide Gas ....................... 70

Safety Labels

Label Locations .................................. 71

17 ACURA RLX E-AWD-31TY36300.book  31 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

32

Safe Driving

For Safe Driving

The following pages explain your vehicle’s safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.

Important Safety Precautions

■

Always wear your seat belt

A seat belt is your best protection in all types of collisions. Airbags are designed to
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passengers always wear your seat belts, and
wear them properly.

■

Restrain all children

Children ages 12 and under should ride properly restrained in a back seat, not the
front seat. Infants and small children should be restrained in a child seat. Larger
children should use a booster seat and a lap/shoulder seat belt until they can use the
belt properly without a booster seat.

■

Be aware of airbag hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants
who sit too close to them, or are not properly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.

■

Don’t drink and drive

Alcohol and driving don’t mix. Even one drink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive, either.

1

Important Safety Precautions

Some states, provinces and territories prohibit the use
of cell phones other than hands-free devices by the
driver while driving.

17 ACURA RLX E-AWD-31TY36300.book  32 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

33

uu

For Safe Driving

u

Important Safety Precautions

Safe Driving

■

Pay appropriate attention to the task of driving safely

Engaging in cell phone conversation or other activities that keep you from paying
close attention to the road, other vehicles, and pedestrians could lead to a crash.
Remember, situations can change quickly, and only you can decide when it is safe to
divert some attention away from driving.

■

Control your speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for current conditions, regardless of the maximum
speed posted.

■

Keep your vehicle in safe condition

Having a tire blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tire pressures and condition
frequently, and perform all regularly scheduled maintenance.

17 ACURA RLX E-AWD-31TY36300.book  33 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

34

uu

For Safe Driving

u

Your Vehicle’s Safety Features

Safe Driving

Your Vehicle’s Safety Features

The following checklist will help you take an active role in protecting yourself and
your passengers.

1

Your Vehicle’s Safety Features

Your vehicle is equipped with many features that
work together to help protect you and your
passengers during a crash.

Some features do not require any action on your part.
These include a strong steel framework that forms a
safety cage around the passenger compartment,
front and rear crush zones, a collapsible steering
column, and tensioners that tighten the front seat
belts in a sufficient crash.

However, you and your passengers cannot take full
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
injuries if they are not used properly.

6

7

9

10

11

12

Safety Cage
Crush Zones
Seats and Seat-Backs
Head Restraints
Collapsible Steering Column
Seat Belts
Front Airbags

Side Curtain Airbags
Door Locks

Side Airbags

Seat Belt Tensioners/Seat Belt
e-pretensioners

7

7

10

10

9

9

11

11

6

12

8

Knee Airbag

8

17 ACURA RLX E-AWD-31TY36300.book  34 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

35

uu

For Safe Driving

u

Safety Checklist

Safe Driving

Safety Checklist

For the safety of you and your passengers, make a habit of checking these items
each time before you drive.
• After everyone has entered the vehicle, be sure all doors are closed and locked.

Locking the doors helps prevent an occupant from being ejected and an outsider
from unexpectedly opening a door.

2 Locking/Unlocking the Doors from the Inside P. 142

• Adjust your seat to a position suitable for driving. Be sure the front seats are

adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.

2 Adjusting the Seats P. 175

• Adjust head restraints to the proper position. Head restraints are most effective

when the center of the head restraint aligns with the center of your head. Taller
persons should adjust their head restraint to the highest position.

2 Adjusting the Head Restraints P. 178

• Always wear your seat belt, and make sure you wear it properly. Confirm that any

passengers are properly belted as well.

2 Fastening a Seat Belt P. 39

• Protect children by using seat belts or child seats according to a child’s age, height

and weight.

2 Child Safety P. 58

1

Safety Checklist

If the door and/or trunk open message appears on
the multi-information display, a door and/or the
trunk is not completely closed. Close all doors and
the trunk tightly until the message disappears.

2 Multi-Information Display Warning and

Information Messages P. 97

17 ACURA RLX E-AWD-31TY36300.book  35 ページ  ２０１６年６月１７日　金曜日　午前８時２９分

36

Safe Driving

Seat Belts

About Your Seat Belts

Seat belts are the single most effective safety device because they keep you
connected to the vehicle so that you can take advantage of many built-in safety
features. They also help keep you from being thrown against the inside of the
vehicle, against any passengers, or out of the vehicle. When worn properly, seat
belts also keep your body properly positioned in a crash so that you can take full
advantage of the additional protection provided by the airbags.

In addition, seat belts help protect you in almost every type of crash, including:
- frontal impacts
- side impacts
- rear impacts
- rollovers

■

Lap/shoulder seat belts

All five seating positions are equipped with lap/shoulder seat belts with emergency
locking retractors. In normal driving the retractor lets you move freely while keeping
some tension on the belt. During a collision or sudden stop the retractor locks to
restrain your body. The front passenger’s and rear seat belts also have a lockable
retractor for use with child seats.

2 Installing a Child Seat with a Lap/Shoulder Seat Belt P. 65

1

About Your Seat Belts

Seat belts cannot completely protect you in every
crash. But in most cases, seat belts can reduce your
risk of serious injury.

Most states and all Canadian provinces and territories
require you to wear seat belts.

The emergency locking retractor may lock if you lean
forward too quickly. Slower movements will allow
the belt to extend fully without locking.

3

WARNING

Not wearing a seat belt properly increases
the chance of serious injury or death in a
crash, even though your vehicle has
airbags.

Be sure you and your passengers always
wear seat belts and wear them properly.

17 ACURA RLX E-AWD-31TY36300.book  36 ページ  ２０１６年６月１７日　金曜日　午前８時２９分
