103

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the power mode is in ACCESSORY.

—

●

Appears after the driver’s door is opened when the
power mode is in ACCESSORY.

●

Press the POWER button twice with your foot off the
brake pedal to change the power mode to VEHICLE OFF.

●

Appears when you close the door with the power mode
is in ON without the keyless access remote inside the
vehicle.

●

Disappears when you bring the keyless access remote
back inside the vehicle and close the door.

2 Keyless Access Remote Reminder P. 166

●

Appears when the keyless access remote’s battery
becomes weak.

●

Replace the battery as soon as possible.

2 Replacing the Button Battery P. 371

●

Appears if the keyless access remote’s battery is too
weak to start the power system or the key is not within
operating range to start the power system.
The beeper sounds six times.

●

Bring the keyless access remote in front of the POWER
button to be touched with.

2 If the Keyless Access Remote Battery is Weak P. 405

17 ACURA MDX E-AWD-31TRX6000.book  103 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

104

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the transmission system temperature is
too high.

●

Immediately stop in a safe place in

(

P.

●

Let the engine idle until the message disappears.

●

Appears when you turn the power system on with the
transmission not in

(

P.

●

Press the

(

P button.

●

Appears if there is a problem with the electric system.

●

Appears when you set the power mode to OFF while
driving.

●

Immediately stop in a safe place and set the parking
brake.

●

Continue driving if the message goes off soon after.

●

If there is a problem with the transmission system, the
transmission system indicator comes on.

2 Transmission System Indicator P. 84

17 ACURA MDX E-AWD-31TRX6000.book  104 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

105

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when you attempt to change to another gear
position with the transmission in

(

P and the engine

OFF.

●

To select another gear position while in

(

P the engine

must be ON.

●

Appears when you try to change the gear position after
the position has automatically been changed to

(

P with

the driver’s door open and the driver’s seat belt
unfastened.

●

Press the

(

P button If you leave the vehicle.

●

Appears when the vehicle is stopped with the driver’s
seat belt unfastened and there is a chance that the
vehicle may roll unintentionally.

●

Press the

(

P button before release the brake pedal

when idling, parking or exiting the vehicle.

2 Shift Operation P. 249

●

Appears when you change to

(

N, then release the

(

N

button.

2 If you want to keep the transmission in

(

N



position [car wash mode] P. 251

17 ACURA MDX E-AWD-31TRX6000.book  105 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

106

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when you try to change the gear position
without depressing the brake pedal.

●

Depress the brake pedal, then select a shift button.

●

Appears when you try to change the gear position
without releasing your foot off the accelerator pedal.

●

Release your foot off the accelerator pedal, then select a
shift button.

●

Appears when the

(

P button is pressed while the

vehicle is moving.

●

Appears if you change the gear position to

(

R while the

vehicle is moving forward, or to

(

D while the vehicle is

reversing.

●

Make sure that the vehicle comes to a stop before
operating the select button.

●

Appears when you set the power mode to ON without
fastening the driver’s seat belt.

●

Appears when you change the gear position after

(

P

has been automatically selected with the driver’s door
open, the driver’s seat belt unfastened, then the brake
pedal is released.

●

Fasten the seat belt properly before you start to drive.

2 Shift Operation P. 249

●

Appears when you press the

(

P button but it is not

engaged due to low ATF temperature.

●

Depress the brake pedal until this message disappear.

17 ACURA MDX E-AWD-31TRX6000.book  106 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

107

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when pressing the Dynamic Mode button.

u

Press again to change the next mode.

2 Integrated Dynamics System P. 256

●

Appears if there is a problem with the active damper
system.

●

Have your vehicle checked by a dealer. With this icon
on, your vehicle has limited damping ability without the
active damper system.

●

Appears if there is a problem with the cooling system.

●

Drive slowly to prevent overheating and have your
vehicle checked by a dealer as soon as possible.

●

Appears when there is a problem with the headlights.

●

Appears while driving - The headlights may not be
on. When conditions allow you to drive safety, have
your vehicle checked by a dealer as soon as possible.

●

Appears if there is a problem with the parking sensor
system

*

.

●

Check if the area around the sensor(s) is covered with
mud, ice, snow, etc. If the indicator(s) stays on or the
beeper does not stop even after you clean the area,
have the system checked by a dealer.

* Not available on all models

17 ACURA MDX E-AWD-31TRX6000.book  107 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

108

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if the automatic brake hold is automatically
canceled while it is in operation.

●

Immediately depress the brake pedal.

●

Appears when the automatic brake hold system is
turned off.

2 Automatic Brake Hold P. 303

●

Appears when the automatic brake hold button is
pressed without wearing the driver’s seat belt.

●

Fasten the driver’s seat belt.

2 Automatic Brake Hold P. 303

●

Appears when the automatic brake hold button is
pressed without depressing the brake pedal while the
automatic brake hold is in operation.

●

Press the automatic brake hold button with the brake
pedal depressed.

2 Automatic Brake Hold P. 303

●

Appears when the parking brake is applied
automatically while it is in operation.

2 Automatic Brake Hold P. 303
2 Parking Brake P. 299

17 ACURA MDX E-AWD-31TRX6000.book  108 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

109

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if there is a problem with the Auto high-beam.

●

Manually operate the headlight switch.

●

If you are driving with the high-beam headlights when
this happens, the headlights are changed to low beams.

●

Appears if the temperature inside the camera is too
high and either the auto high beams are in operation or
the headlight switch is turned to AUTO.

●

Use the climate control system to cool down the
camera.

●

 Goes off - The camera has cooled down. To resume
the system, turn the headlight switch to AUTO.

2 Front Sensor Camera P. 257

●

Appears when the area around the camera is blocked
by dirt, mud, etc. Stop your vehicle in a safe place, and
wipe it off with a soft cloth.

●

May appear when driving in bad weather (rain, snow,
fog, etc.)

●

Have your vehicle checked by a dealer if the message
comes back on after you have cleaned the area around
the camera.

●

Appears after the 12-volt battery charging system
indicator comes on.

●

Your vehicle has less ability to accelerate and may be
harder to start on an incline.

●

Contact a dealer immediately.

●

Appears if there is a problem with the acoustic vehicle
alerting system.

●

Have your vehicle checked by a dealer immediately.

17 ACURA MDX E-AWD-31TRX6000.book  109 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

110

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the high voltage battery temperature is
too low to operate (approx. –22°F [–30°C] or below).

●

You can start the engine and use the climate control
system to warm up the interior, which will also warm
the high voltage battery enough for you to drive the
vehicle.

●

The engine speed does not increase even if you fully
depress the accelerator pedal.

●

Appears when the high voltage battery and other
system control temperatures are too low to operate
(approx. –40°F [–40°C] or below).

●

You must wait for an increase in the ambient
temperature or move the vehicle to a warmer location.

●

Consult a dealer.

●

Appears when the high voltage battery is running
extremely low due to continuous slow driving.

●

Driving at low speed for a long time decreases the
amount of electricity generated, leading to high voltage
battery drain.

●

Appears when the high voltage battery is drained even
further and a stop is needed to charge the battery.

●

Stop in a safe place in

(

P, then charge the high voltage

battery by idling the engine.

2 If the 12-Volt Battery Charging System Indicator

Comes On P. 412

●

Appears while the high voltage battery is being charged
with the engine running after the vehicle is parked with
an extremely low battery level.

●

Do not drive the vehicle until Ready To Drive appears.

2 READY Indicator P. 86

17 ACURA MDX E-AWD-31TRX6000.book  110 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

111

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the rear motor fluid temperature is
extremely low.

●

The vehicle speed is temporarily limited up to 81 mph
(130 km/h).
This is canceled after the fluid temperature rises.

●

Appears if the AWD system has a problem due to a
hybrid system or power distribution control failure.

●

Set the power mode to OFF, then set it back to ON.
Have your vehicle checked by a dealer if the message
appears again.

17 ACURA MDX E-AWD-31TRX6000.book  111 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

112

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Flashes when the system senses a likely collision with a
vehicle in front of you.

●

Take the appropriate means to prevent a collision (apply
the brakes, change lanes, etc.)

2 Collision Mitigation Braking System

TM

 (CMBS

TM

)

P. 307

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when ACC with LSF has been automatically
canceled.

●

You can resume the set speed after the condition that
caused ACC with LSF to cancel improves. Press the RES/
+/SET/– switch up.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when the vehicle speed slows down to 25 mph
(40 km/h) and the vehicle ahead of you goes out of the
ACC with LSF range while ACC with LSF is in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when pressing the RES/+/SET/– switch down
while the vehicle speed is less than 25 mph (40 km/h)
and the vehicle ahead of you goes out of the ACC with
LSF range.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when the distance between your vehicle and
the vehicle ahead of you is too close while ACC with LSF
is in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

17 ACURA MDX E-AWD-31TRX6000.book  112 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

113

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when pressing the RES/+/SET/– switch down
while the distance between your vehicle and the vehicle
ahead of you is too close.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when pressing the RES/+/SET/– switch down
while the driver’s seat belt is unfastened.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when pressing the RES/+/SET/– switch down
while the transmission is not in

(

D.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

17 ACURA MDX E-AWD-31TRX6000.book  113 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

114

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the vehicle is stopped on a very steep
slope while ACC with LSF is in operation.

●

ACC with LSF has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when pressing the RES/+/SET/– switch down
while the vehicle is stopped on a very steep slope.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when pressing the RES/+/SET/– switch down
while the parking brake is applied.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

2 Parking Brake P. 299

17 ACURA MDX E-AWD-31TRX6000.book  114 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

115

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if ACC with LSF is canceled while your vehicle
is automatically stopped by ACC with LSF. The beeper
sounds.

●

Immediately depress the brake pedal.

●

Appears when pressing the RES/+/SET/– switch down
while the vehicle is moving and the brake pedal is
depressed.

●

ACC with LSF cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF) P. 259

●

Appears when you unlock and open the driver’s door
while the power system is on by two-way keyless access
remote.

2 Remote Engine Start with Vehicle Feedback P. 241

17 ACURA MDX E-AWD-31TRX6000.book  115 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

116

uu

Indicators

u

Multi-Information Display (MID) Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the vehicle is driving out of a detected
lane. Rapid vibrations on the steering wheel.

●

Appears when the vehicle is driving out of a detected
lane.

- Rapid vibrations on the steering wheel when the

vehicle is drifting out of a detected lane.

- Rapid vibrations on the steering wheel with steering

assist when the vehicle is drifting out of a detected
lane.

●

Keep the vehicle within the lane you are driving.

●

The color of either line changes from white to amber as
the vehicle gets closer to that side of the lane line.

2 Lane Keeping Assist System (LKAS) P. 279
2 Road Departure Mitigation (RDM) System P. 274

●

Blinks when you fail to steer the vehicle. The beeper
sounds simultaneously if selected by customization.

●

Operate the steering wheel to resume the LKAS.

●

Appears when the LKAS is in operation, or the LKAS
button is pressed, but there is a problem with a system
related to the LKAS. The LKAS cancels automatically.
The beeper sounds simultaneously if selected by
customization.

●

If any other system indicators come on, such as the
VSA®, ABS and brake system, take appropriate action.

2 Indicators P. 78

Lane Keeping Assist System (LKAS)

Road Departure Mitigation (RDM) System

When you selected Warning Only

When you selected Normal or Wide

17 ACURA MDX E-AWD-31TRX6000.book  116 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

117

Continued

In

strum

e

nt Pa

nel

Gauges and Multi-Information Display (MID)

Gauges

Gauges include the speedometer, tachometer, fuel gauge, high voltage battery
charge level gauge, and related indicators. They are displayed when the power
mode is in ON.

Displays your driving speed in mph (U.S.) or km/h (Canada).

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

■

Speedometer

■

Tachometer

■

Fuel Gauge

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

17 ACURA MDX E-AWD-31TRX6000.book  117 ページ  ２０１７年１月２０日　金曜日　午後２時５３分

uu

Gauges and Multi-Information Display (MID)

u

Gauges

118

In

strum

e

nt Pa

nel

Shows the remaining high voltage battery charge level.

■

High Voltage Battery Charge Level Gauge

1

High Voltage Battery Charge Level Gauge

The high voltage battery charge level may decrease
under the following conditions:

•

When the 12-volt battery has been replaced.

•

When the 12-volt battery has been disconnected.

•

When the high voltage battery control system
corrects its reading.

The charge level reading will be corrected
automatically while driving.

Changes in the temperature of the high voltage
battery can increase or decrease the battery’s
charging capacity. If temperature changes cause the
battery’s capacity to change, the number of
indicators in the battery charge level gauge may also
change, even if the amount of charging remains the
same.

17 ACURA MDX E-AWD-31TRX6000.book  118 ページ  ２０１７年１月２０日　金曜日　午後２時５３分
