Acura RSX Honda Integra. Manual - part 10

Ｓ６Ｍ６Ａ００００００００００００００ＮＢＡＴ００

Item

Measurement

Qualification

Specification

2-22

Design Specifications

DIMENSIONS

Overall length

2002-2004 models

4,395 mm (173.0 in.)

2005-2006 models

4,385 mm (172.6 in.)

Overall width

2002-2004 models

1,725 mm (67.9 in.)

2005-2006 models

1,725 mm (67.9 in.)

Overall height

2002-2004 models

1,400 mm (55.1 in.)

2005-2006 models

1,395 mm (54.9 in.)

Wheelbase

2,570 mm (101.2 in.)

Track

Front

2002-2004 models

1,482 mm (58.3 in.)

2005-2006 models

1,485 mm (58.5 in.)

Rear

2002-2004 models

1,481 mm (58.3 in.)

2005-2006 models

1,485 mm (58.5 in.)

Ground clearance

Type S

2002-2004 models

149 mm (5.9 in.)

RSX, Premium

152 mm (6.0 in.)

Type S

2005-2006 models

137 mm (5.4 in.)

RSX, Premium

146 mm (5.7 in.)

Seating capacity

four (4)

WEIGHT (U.S.A.)

Gross Vehicle Weight

Rating (GVWR)

RSX

2002-2004 models

3,700 lbs

Type S

3,690 lbs

RSX, Type S

2005-2006 models

3,725 lbs

WEIGHT

(CANADA)

Gross Vehicle Weight

Rating (GVWR)

RSX, Type S

2002-2004 models

1,670 kg

Premium

1,675 kg

RSX, Premium,

Type S

2005-2006 models

1,690 kg

ENGINE

Type

Water cooled, 4-stroke DOHC i-VTEC engine

Cylinder arrangement

Inline 4-cylinder, transverse

Bore and stroke

86 x 86 mm (3.39 x 3.39 in.)

Displacement

1,998 cm (121.9 cu in.)

Compression ratio

K20A2 (2002-2004

models), K20Z1

(2005-2006 models)

engines

11.0

K20A3 engine

9.8

Valve train

Chain drive, DOHC i-VTEC 4 valves per cylinder

Lubrication system

Forced, wet sump, with trochoid pump

Oil pump displacement

At 6,000 rpm

54.3 L (57.4 US qt)/minute

Water pump displacement

At 6,000 rpm

82 L (87 US qt)/minute

Fuel required

K20A2 (2002-2004

models), K20Z1

(2005-2006 models)

engines

Premium UNLEADED gasoline with 91 Pump

Octane Number or higher

K20A3 engine

Regular UNLEADED gasoline with 87 Pump Octane

Number or higher

STARTER

Type

Gear reduction

Normal output

K20A2 (2002-2004

models), K20Z1

(2005-2006 models)

engines

1.1 kW

K20A3 engine

1.2 kW

Normal voltage

12 V

Hour rating

30 seconds

Direction of rotation

Clockwise as viewed from gear end

3

Item

Measurement

Qualification

Specification

2-23

CLUTCH

Clutch type

M/T

Single plate dry, diaphragm spring

A/T

3-element torque converter with lock-up clutch

Clutch friction material surface area

M/T

174 cm (26.97 sq in.)

5-speed

MANUAL

TRANSMISSION

Type

Synchronized, 5-speed forward, 1 reverse

Primary reduction

Direct 1:1

Gear ratio

1st

3.266

2nd

1.880

3rd

1.212

4th

0.921

5th

0.738

Reverse

3.583

Final reduction

Type

Single helical gear

Gear ratio

4.388

6-speed

MANUAL

TRANSMISSION

Type

Synchronized, 6-speed forward, 1 reverse

Primary reduction

Direct 1:1

Gear ratio

1st

3.266

2nd

2.130

3rd

1.517

4th

1.147

5th

0.921

6th

0.738

Reverse

3.583

Final reduction

Type

Single helical gear

Gear ratio

(2002-2004 models)

4.388

Gear ratio

(2005-2006 models)

4.765

AUTOMATIC

TRANSMISSION

Type

Electronically controlled automatic, 5-speed forward,

1 reverse

Primary reduction

Direct 1:1

Gear ratio

1st

2.684

2nd

1.500

3rd

0.984

4th

0.733

5th

0.571

Reverse

2.000

Final reduction

Type

Single helical gear

Gear ratio

4.563

STEERING

Type

Power-assisted rack and pinion

Overall ratio

2002-2004 models

15.06

2005-2006 models

14.92

Turns, lock-to-lock

2002-2004 models

2.64

2005-2006 models

2.59

Steering wheel diameter

360 mm (14.2 in.)

(cont’d)

2

−

(cont’d)

Item

Measurement

Qualification

Specification

2-24

Design Specifications

SUSPENSION

Type

Front

Independent strut with stabilizer, coil spring

Rear

Double wishbone

Shock absorber

Front

Telescopic, hydraulic, nitrogen gas-filled

Rear

Telescopic, hydraulic, nitrogen gas-filled

TIRES

(U.S.A.)

Size of front and rear tires

RSX

P205/55R16 89V

Type S

P205/55R16 89V (2002-2004 models), P215/45R17 87V

(2005-2006 models)

Size of spare tire

RSX

T135/70D15 99M

Type S

T125/70D16 96M

TIRES

(CANADA)

Size of front and rear tires

RSX

P195/65R15 89H

Premium

P205/55R16 89V

Type S

P205/55R16 89V (2002-2004 models), P215/45R17 87V

(2005-2006 models)

Size of spare tire

RSX

T135/70D15 99M

Premium

T135/70D15 99M

Type S

T125/70D16 96M

WHEEL

ALIGNMENT

Camber

Front

0°

Rear

0°45’

Caster

Front

1°30’

Total toe-in

Front

0 mm (0 in.)

Rear

2 mm (1/16 in.)

BRAKES

Type of service brake

Front

Power-assisted self-adjusting ventilated disc

Rear

Power-assisted self-adjusting solid disc

Type of parking brake

Mechanical actuating, rear wheels

Pad friction surface area

Front

42 cm (6.5 sq in.) x 2

Rear

21 cm (3.3 sq in.) x 2

Shoe friction surface area

Rear

49.0 cm (7.60 sq in.) x 2

2

2

2

―――

−

−

−

−

−

−

−

−

−
−
−
−
−
−
−
−
−
−
−
−

Item

Measurement

Qualification

Specification

2-25

AIR

CONDITIONING

Compressor

Type

Scroll

Number of cylinder

Capacity

85.7 mL (5.23 cu in.)/rev.

Maximum speed

12,000 rpm

Lubricant capacity

130

150 mL (4 1/3

5 fl oz, 4.6

5.3 Imp oz)

Lubricant type

KEIHIN SP-10 (P/N 38897-P13-A01AH or 38899-P13-A01)

Condenser

Type

Corrugated fin

Evaporator

Type

Corrugated fin

Blower

Type

Sirocco fan

Motor type

220 W/12 V

Speed control

Infinite variable

Maximum capacity

480 m (16.900 cu ft)/h

Temperature control

Air-mix type

Compressor clutch

Type

Dry, single plate, poly-V belt drive

Electrical power

consumption at 68 °F

(20 °C)

42 W maximum at 12 V

Refrigerant

Type

HFC-134a (R-134a)

Capacity

500

550 g (17.6

19.4 oz)

ELECTRICAL

RATINGS

Battery

12 V

36 AH/5 hours

Fuses

Under-hood fuse/relay

box

100A, 50A, 40A, 30A, 20A, 15A, 10A, 7.5A

Under-dash fuse/relay

box

20A, 15A, 10A, 7.5A

Under-dash auxiliary

fuse/relay box

15A

Light bulbs

Headlight high beam

12 V

55 W (2002-2004 models), 12 V

65 W (2005-2006

models)

Headlight low beam

12 V

55 W

Front turn signal lights

12 V

21 W

Front parking lights

12 V

5 W

Rear turn signal lights

12 V

21 W

Rear side marker lights

12 V

5 W

Brake/taillights

12 V

21/5 W

High-mount brake light

12 V

21 W

Back-up lights

12 V

21 W

License plate light

12 V

5 W

Ceiling light

12 V

8 W

Cargo area light

12 V

5 W

Spotlights

12 V

8 W

Gauge lights

LED

Indicator lights

LED

3
