Acura RL (1996-2004 year). Manual - part 166

2004 American Honda Motor Co., Inc.

199. Left of Steering Column (’04)

C439
(13-WHT)

2004 American Honda Motor Co., Inc.

200. Behind Instrument Cluster (Behind Foam) (’04)

HAZARD WARNING
LIGHTS DIODES 1
AND 2 (2-BLK)

2004 American Honda Motor Co., Inc.

201. Behind Climate Control Unit (’04)

CLIMATE
CONTROL
UNIT

CONNECTOR B
(20-BLK)

CONNECTOR A
(12-GRY)

2004 American Honda Motor Co., Inc.

202. Behind Navigation Display Unit (’04)

NAVIGATION
DISPLAY UNIT

CONNECTOR B
(5-GRN)

CONNECTOR A
(20-BLU)
