COMPONENT LOCATION GRAPHICS
Fig. 1: Right Side Of Engine Compartment
Courtesy of AMERICAN HONDA MOTOR CO., INC.
G503
Under middle of dash. See Fig. 73.
G504
Under middle of dash. See Fig. 75.
G505
Under center console. See Fig. 81.
G506
Behind glove box. See Fig. 86.
G601
At left side of floor. See Fig. 117.
G602
In left "C" pillar. See Fig. 116.
G603
In left "C" pillar. See Fig. 144.
G604
In left "C" pillar. See Fig. 142.
G651
At right side of floor. See Fig. 117.
G652
In right "C" pillar. See Fig. 116.
G653
Behind right kick panel. See Fig. 196.
G701
Left side of trunk. See Fig. 150.
G801
In rear of roof. See Fig. 201.
G851
In right "C" pillar. See Fig. 139.
NOTE:
Figures may show multiple component locations. Refer to appropriate table
for proper figure references.
