Fig. 33: Identifying Windshield Washer Nozzles, Tube And Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install in the reverse order of removal. Take care not to pinch the washer tube. Check the windshield

washer operation.

HEADLIGHT WASHER

1. Remove the front bumper (see FRONT BUMPER REMOVAL/INSTALLATION ).

2. Remove the tube, mounting bolts and washer nozzles.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Wipers/Washers - RL



me



Friday, June 05, 2009 3:19:36 PM

Page 25

© 2005 Mitchell Repair Information Company, LLC.

Fig. 34: Identifying Washer Nozzles, Tube And Mounting Bolts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install in the reverse order of removal. Take care not to pinch the washer tube. Check the headlight

washer operation.
