11. Start the engine and let it run until it warms up (the radiator fan comes on at least twice).

12. Turn off the engine. Check the level in the radiator and add Acura Long Life Antifreeze/Coolant Type

2, if needed.

13. Put the radiator cap on tightly, then run the engine again and check for leaks.

14. Clean up any spilled engine coolant.

THERMOSTAT REPLACEMENT

1. Make sure you have the anti-theft codes for the audio system and navigation system. Make sure the

ignition switch is OFF.

2. Disconnect the negative cable from the battery, then the positive cable. Remove the battery.

3. Drain the engine coolant (see COOLANT CHECK ).

4. Remove the ground cable and thermostat cover, then remove the thermostat.

Fig. 13: Identifying Thermostat Components And Ground Cable With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

NOTE:

Removing the radiator cap while the engine is hot can cause the
coolant to spray out. Always let the engine and radiator cool before
removing the cap.



2007 Acura RL

2005-08 ENGINE Cooling System - RL



me



Friday, June 05, 2009 3:11:22 PM

Page 8

© 2005 Mitchell Repair Information Company, LLC.

5. Install the thermostat with a new rubber seal and with the pin on the top side.

6. Install the battery. Clean the battery posts and cable terminals then assemble them and apply grease to

prevent corrosion.

7. Refill the radiator with engine coolant, then bleed air from the cooling system (see step 8 ).

8. Clean up any spilled engine coolant.

9. Do the steering column position memorization procedure (see STEERING COLUMN POSITION

MEMORIZATION ).

10. Enter the anti-theft codes for the audio system and the navigation system.

WATER PASSAGE REPLACEMENT

1. Make sure you have the anti-theft codes for the audio system and navigation system. Make sure the

ignition switch is OFF.

2. Disconnect the negative cable from the battery, then the positive cable. Remove the battery.

3. Drain the engine coolant (see COOLANT CHECK ).

4. Remove the air cleaner (see AIR CLEANER REMOVAL/INSTALLATION ).

5. Remove the two bolts securing the harness holder and the two bolts securing the vacuum line, then

remove the harness clamp (see step 18 under CYLINDER HEAD REMOVAL ).

6. Disconnect the upper radiator hose, lower radiator hose, heater hoses, and water bypass hoses from

the water passage. Remove the water passage.

Fig. 14: Identifying EGR Valve, ECT Sensors, Water Passage, Connecting Pipe And Gaskets
With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.



2007 Acura RL

2005-08 ENGINE Cooling System - RL



me



Friday, June 05, 2009 3:11:22 PM

Page 9

© 2005 Mitchell Repair Information Company, LLC.

7. Install the water passage in the reverse order of removal.

8. Install the battery. Clean the battery posts and cable terminals, then assemble them and apply grease to

prevent corrosion.

9. Refill the radiator with engine coolant, then bleed air from the cooling system (see step 8 ).

10. Clean up any spilled engine coolant.

11. Do the steering column position memorization procedure (see STEERING COLUMN POSITION

MEMORIZATION ).

12. Enter the anti-theft codes for the audio system and the navigation system.

RADIATOR AND FAN REPLACEMENT

1. Drain the engine coolant (see COOLANT CHECK ).

2. Remove the right upper fender trim, battery trim, left upper fender trim, then remove the upper grille

cover (see step 1 under RFC UNIT REPLACEMENT ). Remove the splash shield (see step 33
under ENGINE REMOVAL ).

3. Remove the air cleaner (see AIR CLEANER REMOVAL/INSTALLATION ).

4. Remove the automatic transmission fluid (ATF) cooler hoses from the radiator (see ATF COOLER

HOSE REPLACEMENT ). Remove the upper radiator hose and lower radiator hose from the
radiator.

Fig. 15: Identifying Radiator And Fan Components With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.



2007 Acura RL

2005-08 ENGINE Cooling System - RL



me



Friday, June 05, 2009 3:11:22 PM

Page 10

© 2005 Mitchell Repair Information Company, LLC.

5. Disconnect the RFC unit connectors. Remove the harness clamps and A/C compressor clutch

connector.

6. Remove the upper bracket cushions, then pull up the radiator.

7. Disconnect the fan motor connectors, then remove the fan shroud assemblies and other parts from the

radiator.

8. Install the radiator in the reverse order of removal. Make sure the upper and lower cushions are set

securely.

9. Fill the radiator with engine coolant, then bleed air from the cooling system (see step 8 ).
