Fig. 78: Identifying Backing Plate And Parking Brake Cable Bracket With Torque
Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove the parking brake cable (C) from the parking brake cable bracket.

4. Install the parking brake cable in the reverse order of removal, and adjust the parking brake (see

PEDAL FREE PLAY ). Apply the parking brake firmly 10 times, then adjust it again.



2007 Acura RL

2005-08 BRAKES Conventional Brake Components - RL



me



Friday, June 05, 2009 3:00:07 PM

Page 53

© 2005 Mitchell Repair Information Company, LLC.

2005-08 ACCESSORIES AND EQUIPMENT

Bumpers - RL

FRONT BUMPER REMOVAL/INSTALLATION

Special Tools Required

Push pin puller 07AAC-SJAA100

1. Remove these items:



Front air spoiler (see FRONT AIR SPOILER REPLACEMENT )



Upper grille cover (see UPPER GRILLE COVER REPLACEMENT )

2. Remove the bolts (A), screws (B), and clips (C) securing the front bumper (D).

Fig. 1: Identifying Front Bumper And Fasteners With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Pull on the front bumper (A) at the wheel arch areas to release it from the hooks (B) on the side

spacers (C).

NOTE:



Have an assistant help you when removing and installing the front
bumper.



Take care not to scratch the front bumper and body.



Put on gloves to protect your hands.



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Bumpers - RL





2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Bumpers - RL



me



Friday, June 05, 2009 3:36:03 PM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

me



Friday, June 05, 2009 3:36:07 PM

Page 1

© 2005 Mitchell Repair Information Company, LLC.

Fig. 2: Pulling Front Bumper
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. With the help of an assistant, pull the wheel arch portion away from the side spacer (A) while pulling

the front bumper (B) to release the bumper from the hooks (C) on the corner upper beam (D).

Fig. 3: Pulling Side Spacer, Front Bumper And Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Disconnect the front fog light connectors (A), outside temperature sensor connector (B), and headlight

washer tube (C), then remove the front bumper (D).



2007 Acura RL

2005-08 ACCESSORIES AND EQUIPMENT Bumpers - RL



me



Friday, June 05, 2009 3:36:03 PM

Page 2

© 2005 Mitchell Repair Information Company, LLC.

Fig. 4: Identifying Front Fog Light Connectors, Outside Temperature Sensor Connector And
Headlight Washer Tube
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Release the hooks, then remove the front bumper absorber (A).

Fig. 5: Identifying Front Bumper Absorber
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Install the bumper in the reverse order of removal, and note these items:



Make sure the front fog light connectors and outside temperature sensor connector are plugged
in properly, and the headlight washer tube is connected properly.



Make sure the front bumper engages the hooks (of both corner upper beams and side spacers)
on each side securely.



Check if the clips are damaged or stress-whitened, and if necessary, replace them with new
ones.



Push the clips and hooks into place securely.

LOWER FRONT BUMPER PLATE REPLACEMENT

1. Remove the front bumper (see FRONT BUMPER REMOVAL/INSTALLATION ).

2. Remove the bolts (A) and loosen the bolts (B), then remove the front bumper lower plate (C) from the

front bumper (D).

NOTE:



Take care not to scratch the front bumper.



Put on gloves to protect your hands.
