Fig. 106: ATF Temperature Sensor Circuit Diagram General Description The ATF temperature sensor is a thermistor type sensor whose resistance changes according to the change in When the ATF temperature sensor signal voltage to the PCM is above the specification, indicating that the Monitor Execution, Sequence, Duration, DTC Type, OBD Status MONITOR DESCRIPTION CHART Enable Conditions ENABLE CONDITIONS Malfunction Threshold The ATF temperature sensor output voltage is 4.93 V or more for at least 10 seconds. Driving Pattern Start the engine, shift to the P position, and wait for at least 10 seconds. Diagnosis Details Execution Continuous Sequence None Duration 10 seconds or more DTC Type One drive cycle, MIL OFF, D indicator blinks OBD Status PASSED/FAILED/NOT COMPLETED (STILL TESTING) Condition Minimum Maximum Battery voltage 11.0 V - No active DTCs P0711, P0712
2007 Acura RL 2007 ENGINE PERFORMANCE Advanced Diagnostics - RL
