*10 *11 *12 − − − − − − YES NO YES NO YES NO 23-209 STEREO AMPLIFIER CONNECTOR A (20P) ACC RADIO (PUR) STEREO AMPLIFIER CONNECTOR B (14P) AMP ON (LT BLU) STEREO AMPLIFIER CONNECTOR A (20P) GND (BLK) 15. Turn the ignition switch to ON (II). 16. Measure the voltage between stereo amplifier connector A (20P) terminal No. 9 and body ground. Go to step 17. Repair open in the wire between the No. 35 (7.5 A) fuse in the under-dash fuse/relay box and 17. Measure the voltage between stereo amplifier connector B (14P) terminal No. 7 and body ground. Go to step 18. Repair open in the wire between the stereo amplifier connector B (14P) terminal No. 7 and 18. Measure the voltage between stereo amplifier connector A (20P) terminal No. 20 and body ground. Go to step 19. Repair open in the wire between stereo amplifier connector A (20P) terminal No. 20 and 19. Turn the ignition switch to LOCK (0). Wire side of female terminals Wire side of female terminals Wire side of female terminals Is ther e batter y voltage? Is ther e batter y voltage? Is ther e less than 0.1 V on both ter minals? 08/08/21 14:10:46 61SNR030_230_0212 |
