18-45
A
’06 model:
12 x 1.25 mm
108 N·m (11.0 kgf·m, 79.6 lbf·ft)
’07-08 except Type S models:
12 x 1.25 mm
110 N·m (11.2 kgf·m, 81.0 lbf·ft)
’07-08 Type S models:
12 x 1.25 mm
115 N·m (11.7 kgf·m, 84.6 lbf·ft)
’09 model:
12 x 1.25 mm
115 N·m (11.7 kgf·m, 84.6 lbf·ft)
A
12 x 1.25 mm
108 N·m
(11.0 kgf·m,
79.6 lbf·ft)
B
C
A
B
C
Except Type S model:
12 x 1.25 mm
59 N·m
(6.0 kgf·m, 43 lbf·ft)
Type S model:
12 x 1.25 mm
69 N·m
(7.0 kgf·m, 51 lbf·ft)
3. Loosely install new trailing arm front mounting
bolts (A).
4. Loosely install the new flange bolt (A) that connects
the knuckle (B) and the upper arm (C).
5. Slowly raise the jack until you can align the bolt
hole with the holes in the trailing arm (A) and the
damper (B), and install the new flange bolt (C).
6. Install the stabilizer link on the trailing arm
(see page 18-37).
7. Raise the rear suspension with a floor jack to load
the vehicle weight.
8. Tighten all mounting hardware to the specified
torque values.
Replace.
Replace.
Replace.
Replace.
Replace.
Replace.
Replace.
