− − − 01 SNR9A00A14400049201FEAT01 − − − 01 SNR9A00A14400049001FEAT02 10-4 10-4 Cooling System Radiator Cap Test Radiator Test A B A 1. Wait until the engine is cool, then carefully remove the radiator cap (A). Wet the radiator cap seal with 2. Apply a pressure of 93 123 kPa (0.95 1.25 kgf/cm , 14 18 psi). 3. Check for a drop in pressure. 4. If the pressure drops, replace the cap. 1. Wait until the engine is cool, then carefully remove the radiator cap and fill the radiator with engine 2. Attach a commercially available pressure tester (A) to the radiator, and apply a pressure of 93 123 kPa (0.95 1.25 kgf/cm , 14 18 psi). 3. Inspect for engine coolant leaks and a drop in pressure. 4. Check for engine oil in the coolant and/or coolant in the engine oil. 5. Remove the tester, and reinstall the radiator cap. 2 2 08/08/21 14:39:57 61SNR030_100_0004 |
