Acura CSX. Manual - part 9

−

＋

−

＋

−

＋

−

＋

−

ＳＮＲ９Ａ００００００００００００００ＮＤＡＴ０４

Steering

Suspension

Item

Measurement

Qualification

Standard or New

Item

Measurement

Qualification

Standard or New

Service Limit

2-18

Standards and Service Limits

Steering wheel

Rotational play measured at outside

edge with engine running

10 mm (0

0.39 in.)

Initial turning load measured at

outside edge with engine running

34 N (3.5 kgf, 7.7 lbf)

Gearbox

Angle of rack guide screw loosened

from locked position

3 °

Wheel alignment

Camber

Front

0 ° 00 ’

30 ’

Rear (without

‘‘C’’ marks on the

rear upper arm)

1 ° 30 ’

Rear (with ‘‘C’’

marks on the

rear upper arm)

0 ° 45 ’

Caster

Front

7 ° 00 ’

1 °

Total toe-in

Front

2 mm (0

0.08 in.)

Rear

mm (0.08

in.)

Front wheel turning angle

Inward

38 ° 46 ’

2 °

Outward

(reference)

31 ° 14 ’

Wheel

Runout

Axial

0.7 mm (0

0.03 in.)

2.0 mm (0.08 in.)

Radial

0.7 mm (0

0.03 in.)

1.5 mm (0.06 in.)

Wheel bearing

End play

Front

0.05 mm (0

0.002 in.)

Rear

0.05 mm (0

0.002 in.)

1 ° 05 ’

0 ° 45 ’

1 ° 05 ’

0 ° 45 ’

0.08

0.04

−

―――
―――

−

Brakes

Air Conditioning

Item

Measurement

Qualification

Standard or New

Service Limit

Item

Measurement

Qualification

Standard or New

2-19

Parking brake

Distance traveled when lever pulled

with 196 N (20 kgf, 44 lbf) of force

8 to 10 clicks

Brake pedal

Pedal height (carpet moved aside)

M/T

153 mm (6.02 in.)

A/T

158 mm (6.22 in.)

Free play

5 mm (0.04

0.20 in.)

Brake disc

Thickness

Front

(except TYPE S)

22.9

23.1 mm (0.90

0.91 in.)

21.0 mm (0.83 in.)

Front (TYPE S)

24.9

25.1 mm (0.98

0.99 in.)

23.0 mm (0.91 in.)

Rear

8.9

9.1 mm (0.35

0.36 in.)

8.0 mm (0.31 in.)

Runout

Front and rear

0.04 mm (0.0016 in.)

Parallelism

Front and rear

0.015 mm (0.0006 in.)

Brake pad

Thickness

Front

(except TYPE S)

9.6

10.2 mm (0.38

0.40 in.)

1.6 mm (0.06 in.)

Front (TYPE S)

9.0

9.7 mm (0.35

0.38 in.)

1.6 mm (0.06 in.)

Rear

8.3

9.4 mm (0.33

0.37 in.)

1.6 mm (0.06 in.)

Refrigerant

Type

HFC-134a (R-134a)

Capacity of system

400

450 g (14.1

15.8 oz)

Refrigerant oil

Type

SP-10 (P/N 38897-P13-A01)

Capacity of components

Condenser

50 mL (1 2/3 fl·oz)

Evaporator

40 mL (1 1/3 fl·oz)

Each Line and

hose

10 mL (1/3 fl·oz)

Compressor

85 mL (2 1/2

2 5/6 fl·oz)

Compressor

Field coil resistance

At 20 °C (68 °F)

3.15

3.45

Pulley-to-armature-plate clearance

0.35

0.65 mm (0.014

0.026 in.)

ＳＮＲ９Ａ００００００００００００００ＮＢＡＴ００

Item

Measurement

Qualification

Specification

2-20

Design Specifications

DIMENSIONS

Overall length

4.544 mm (178.9 in.)

Overall width

1,752 mm (69.0 in.)

Overall height

1,435 mm (56.5 in.)

Wheelbase

2,700 mm (106.3 in.)

Track

Front

1,499 mm (59.0 in.)

Rear

1,528 mm (60.2 in.)

Ground clearance

145 mm (5.7 in.)

Seating capacity

Five (5)

WEIGHT

Gross Vehicle Weight Rating

(GVWR)

See the certification label attached to the driver’s doorjamb

ENGINE

Type

Water cooled, 4-stroke DOHC i-VTEC engine

Cylinder arrangement

Inline 4-cylinder, transverse

Bore and stroke

86 x 86 mm (3.39 x 3.39 in.)

Displacement

1,998 cm (122 cu in.)

Compression ratio

K20Z2

9.6

K20Z3

11.0

Valve train

Chain drive, DOHC i-VTEC 4 valves per cylinder

Lubrication system

Forced, wet sump, with trochoid pump

Fuel required

K20Z2

Regular UNLEADED gasoline 87 Pump Octane Number or

higher

K20Z3

Premium UNLEADED gasoline 91 Pump Octane Number or

higher

STARTER

Type

Gear Reduction

Nominal output

1.6 kW

Nominal voltage

12 V

Hour rating

30 seconds

Direction of rotation

Clockwise as viewed from drive end

CLUTCH

Type

Single plate dry, diaphragm spring

Clutch friction material surface area

174 cm (27 sq in.)

Item

Measurement

Qualification

Specification

2-21

MANUAL

TRANSMISSION

(5-speed)

Type

Synchronized, five-speed forward, one reverse

Primary reduction

Direct 1:1

Gear ratio

1st

3.267

2nd

1.880

3rd

1.212

4th

0.921

5th

0.738

Reverse

3.583

Final reduction

Type

Single helical gear

Gear ratio

4.839

MANUAL

TRANSMISSION

(6-speed)

Type

Synchronized, six-speed forward, one reverse

Primary reduction

Direct 1:1

Gear ratio

1st

3.267

2nd

2.130

3rd

1.517

4th

1.147

5th

0.921

6th

0.659

Reverse

3.583

Final reduction

Type

Single helical gear

Gear ratio

4.765

AUTOMATIC

TRANSMISSION

Type

Electronically-controlled automatic, five-speed forward, one

reverse three-element torque converter with lock-up clutch

Primary reduction

Direct 1:1

Gear ratio

1st

2.651

2nd

1.516

3rd

1.081

4th

0.772

5th

0.566

Reverse

2.000

Final reduction

Type

Single helical gear

Gear ratio

4.562

STEERING

Type

Electrical power-assisted rack and pinion

Overall ratio

13.62

Turns, lock-to-lock

2.65

Steering wheel diameter

360 mm (14.2 in.)

SUSPENSION

Type

Front

Independent strut with stabilizer, coil spring

Rear

Independent double wishbone with stabilizer, coil spring

Shock absorber

Front and rear

Telescopic, hydraulic, nitrogen gas-filled

TIRES

Size of front and rear tires

(’06-08 models)

Except TYPE S

P205/55R16 89H

TYPE S

P215/45R17 87V

Size of front and rear tires

(’09 model)

P215/45R17 87V

Size of spare tire (’06-07 models)

Except TYPE S

T125/70D15 95M

TYPE S

T135/80R16 101M

Size of spare tire (’08-09 models)

T135/80R16 101M
