HOOD ADJUSTMENT PROCEDURES

1. After loosening the hinge (A) mounting bolt, adjust the hood (B) by moving it up or down, or right or left.

2. Adjust the hood height by turning the hood overslam bumpers (C).

3. After loosening the hood latch (D) mounting bolts, adjust the latch by moving it up or down, or right or

left.

Fig. 14: Identifying Hinge Mounting Bolts, Hood, Overslam Bumper And Hood Latch
Courtesy of KIA MOTORS AMERICA, INC.

TAILGATE



Make sure the hood latch cable is connected properly.



Make sure the hood locks securely.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:08 PM

Page 12

© 2006 Mitchell Repair Information Company, LLC.

REPLACEMENT

INSIDE HANDLE REPLACEMENT

1. After loosening the mounting screws, remove the inside handle (A).

Fig. 15: Identifying Inside Handle And Screw
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

ROOM LAMP REPLACEMENT

1. Remove the room lamp.



Remove the lens (A).



Remove the screw.



Pull out the room lamp (B).



Disconnect the connector (C).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:08 PM

Page 13

© 2006 Mitchell Repair Information Company, LLC.

Fig. 16: Identifying Lens, Room Lamp And Connector
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

TAILGATE TRIM REPLACEMENT

1. Remove the following items.



Room lamp. See ROOM LAMP REPLACEMENT.



Inside handle. See TAILGATE.

2. Disconnect the clip (A), remove the tailgate lifter (B).

NOTE:



When prying with a flat-tipped screwdriver, wrap it with protective tape,
and apply protective tape around the related parts, to prevent damage.



Put on gloves to protect your hands.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:08 PM

Page 14

© 2006 Mitchell Repair Information Company, LLC.

Fig. 17: Identifying Clip And Tailgate Lifter
Courtesy of KIA MOTORS AMERICA, INC.

3. Using a screwdriver, remove the tailgate switch (A).

4. Disconnect the connector (B).

Fig. 18: Identifying Tailgate Switch And Connector
Courtesy of KIA MOTORS AMERICA, INC.

5. Using a screwdriver, remove the tailgate upper trim (A).
