Kia Sedona (2008 year). Manual - part 373

Fig. 219: Locating Pressure Lines And Radiator Assembly
Courtesy of KIA MOTORS AMERICA, INC.

7. Connect transaxle oil cooler hoses (A). Refer to AUTOMATIC TRANSAXLE SYSTEM .

Fig. 220: Locating Transaxle Oil Cooler Hoses
Courtesy of KIA MOTORS AMERICA, INC.

8. Connect radiator upper and lower hoses (A).

2008 Kia Sedona

2008 ENGINE Mechanical - Sedona

Microsoft

Saturday, May 22, 2010 3:54:38 PM

Page 150

Fig. 221: Locating Radiator Upper And Lower Hoses
Courtesy of KIA MOTORS AMERICA, INC.

9. Install the radiator support upper member assembly (A).

Fig. 222: Locating Radiator Support Upper Member Assembly
Courtesy of KIA MOTORS AMERICA, INC.

10. Install under cover.

11. Install the radiator grille upper cover (A).

2008 Kia Sedona

2008 ENGINE Mechanical - Sedona

Microsoft

Saturday, May 22, 2010 3:54:38 PM

Page 151

Fig. 223: Locating Radiator Grille Upper Cover
Courtesy of KIA MOTORS AMERICA, INC.

12. Fill with engine coolant.

13. Start engine and check for leaks.

14. Recheck engine coolant level.

LUBRICATION SYSTEM

COMPONENT

2008 Kia Sedona

2008 ENGINE Mechanical - Sedona

Microsoft

Saturday, May 22, 2010 3:54:38 PM

Page 152

Fig. 224: Identifying Lubrication System Components And Torque Specifications
Courtesy of KIA MOTORS AMERICA, INC.

OIL AND FILTER

CAUTION:



Prolonged and repeated contact with mineral oil will result in the
removal of natural fats from the skin, leading to dryness, irritation
and dermatitis. In addition, used engine oil contains potentially
harmful contaminants which may cause skin cancer.



Exercise caution in order to minimize the length and frequency of

2008 Kia Sedona

2008 ENGINE Mechanical - Sedona

Microsoft

Saturday, May 22, 2010 3:54:38 PM

Page 153
