BATTERY DIAGNOSTIC TEST (2)

1. Make sure the ignition switch and all accessories are in the OFF position.

2. Disconnect the battery cables (negative first).

3. Remove the battery from the vehicle.

Fig. 18: Disconnecting Negative Battery Cable
Courtesy of KIA MOTORS AMERICA, INC.

4. Inspect the battery tray for damage caused by the loss of electrolyte. If acid damage is present, it will be

necessary to clean the area with a solution of clean warm water and baking soda. Scrub the area with a
stiff brush and wipe off with a cloth moistened with baking soda and water.

Voltage

Temperature

9.6V 20°C (68.0°F) and above
9.5V

16°C (60.8°F)

9.4V

10°C (50.0°F)

9.3V

4°C (39.2°F)

9.1V

-1°C (30.2°F)

8.9V

-7°C (19.4°F)

8.7V

-12°C (10.4°F)

8.5V

-18°C (-0.4°F)

NOTE:



If the voltage is greater than shown in BATTERY TEST VOLTAGE, the
battery is good.



If the voltage is less than shown in BATTERY TEST VOLTAGE,
replace the battery.

CAUTION: Care should be taken in the event the battery case is cracked or

leaking, to protect your skin from the electrolyte.
Heavy rubber gloves (not the household type) should be wore when
removing the battery.



2008 Kia Sedona

2008 ELECTRICAL Charging System - Sedona



Microsoft



Saturday, May 22, 2010 4:06:11 PM

Page 16

© 2006 Mitchell Repair Information Company, LLC.

5. Clean the top of the battery with the same solution as described above.

6. Inspect the battery case and cover for cracks. If cracks are present, the battery must be replaced.

7. Clean the battery posts with a suitable battery post tool.

8. Clean the inside surface of the terminal clamps with a suitable battery cleaning tool. Replace damaged or

frayed cables and broken terminal clamps.

9. Install the battery in the vehicle.

10. Connect the cable terminals to the battery post, making sure tops of the terminals are flush with the tops

of the posts.

11. Tighten the terminal nuts securely.

12. Coat all connections with light mineral grease after tightening.

Fig. 19: View Of Battery
Courtesy of KIA MOTORS AMERICA, INC.

CAUTION: When batteries are being charged, an explosive gas forms beneath

the cover of each cell. Do not smoke near batteries being charged or
which have recently been charged. Do not break live circuit at the
terminals of batteries being charged. A spark will occur when the
circuit is broken. Keep open flames away from battery.



2008 Kia Sedona

2008 ELECTRICAL Charging System - Sedona



Microsoft



Saturday, May 22, 2010 4:06:11 PM

Page 17

© 2006 Mitchell Repair Information Company, LLC.

CRASH PAD

COMPONENTS

Fig. 7: Identifying Crash Pad Components
Courtesy of KIA MOTORS AMERICA, INC.

REPLACEMENT

CLUSTER FASCIA PANEL REPLACEMENT

NOTE:



When prying with a flat-tipped screwdriver, wrap it with protective tape,
and apply protective tape around the related parts, to prevent damage.



2008 Kia Sedona

2008 ACCESSORIES & BODY, CAB Interior - Sedona





2008 Kia Sedona

2008 ACCESSORIES & BODY, CAB Interior - Sedona



Microsoft



Saturday, May 22, 2010 6:56:12 PM

Page 1

© 2006 Mitchell Repair Information Company, LLC.

Microsoft



Saturday, May 22, 2010 6:56:15 PM

Page 1

© 2006 Mitchell Repair Information Company, LLC.

1. Tilt the steering column down.

2. Remove the screws, and detach the clips.

3. After disconnecting the connector (A), remove the cluster fascia panel (B).

Fig. 8: Identifying Connector And Cluster Fascia Panel
Courtesy of KIA MOTORS AMERICA, INC.

4. Installation is the reverse of removal.

CENTER FASCIA PANEL REPLACEMENT

1. Detach the clips, then remove the center fascia panel (A).



Put on gloves to protect your hands.

NOTE:



Make sure the connector is plugged in properly.

NOTE:



When prying with a flat-tipped screwdriver, wrap it with protective tape,
and apply protective tape around the related parts, to prevent damage.



Put on gloves to protect your hands.
