Intel 64 and IA-32 Architectures. Software Developer’s Manual (Collection, 2023) - page 125

INSTRUCTION FORMATS AND ENCODINGS

Table B-35. Encodings of SSE4.1 instructions

Instruction and Format

Encoding

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 1110:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 1110: mod xmmreg r/m

PMINSB — Minimum of Packed Signed Byte Integers

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 1000:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 1000: mod xmmreg r/m

PMINSD — Minimum of Packed Signed Dword Integers

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 1001:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 1001: mod xmmreg r/m

PMINUD — Minimum of Packed Unsigned Dword Integers

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 1011:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 1011: mod xmmreg r/m

PMINUW — Minimum of Packed Unsigned Word Integers

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 1010:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 1010: mod xmmreg r/m

PMOVSXBD — Packed Move Sign Extend - Byte to Dword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 0001:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 0001: mod xmmreg r/m

PMOVSXBQ — Packed Move Sign Extend - Byte to Qword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 0010:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 0010: mod xmmreg r/m

PMOVSXBW — Packed Move Sign Extend - Byte to Word

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 0000:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 0000: mod xmmreg r/m

PMOVSXWD — Packed Move Sign Extend - Word to Dword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 0011:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 0011: mod xmmreg r/m

PMOVSXWQ — Packed Move Sign Extend - Word to Qword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 0100:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 0100: mod xmmreg r/m

PMOVSXDQ — Packed Move Sign Extend - Dword to Qword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 0101:11 xmmreg1

xmmreg2

Vol. 2D B-67

INSTRUCTION FORMATS AND ENCODINGS

Table B-35. Encodings of SSE4.1 instructions

Instruction and Format

Encoding

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 0101: mod xmmreg r/m

PMOVZXBD — Packed Move Zero Extend - Byte to Dword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 0001:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0001: mod xmmreg r/m

PMOVZXBQ — Packed Move Zero Extend - Byte to Qword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 0010:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0010: mod xmmreg r/m

PMOVZXBW — Packed Move Zero Extend - Byte to Word

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 0000:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0000: mod xmmreg r/m

PMOVZXWD — Packed Move Zero Extend - Word to Dword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 0011:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0011: mod xmmreg r/m

PMOVZXWQ — Packed Move Zero Extend - Word to Qword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 0100:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0100: mod xmmreg r/m

PMOVZXDQ — Packed Move Zero Extend - Dword to Qword

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0011 0101:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0101: mod xmmreg r/m

PMULDQ — Multiply Packed Signed Dword Integers

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0010 1000:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0010 1000: mod xmmreg r/m

PMULLD — Multiply Packed Signed Dword Integers, Store low Result

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0100 0000:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0100 0000: mod xmmreg r/m

PTEST — Logical Compare

xmmreg2 to xmmreg1

0110 0110:0000 1111:0011 1000: 0001 0111:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0001 0111: mod xmmreg r/m

ROUNDPD — Round Packed Double Precision Values

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0000 1001:11 xmmreg1

xmmreg2: imm8

mem to xmmreg, imm8

0110 0110:0000 1111:0011 1010: 0000 1001: mod xmmreg r/m:

imm8

B-68

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-35. Encodings of SSE4.1 instructions

Instruction and Format

Encoding

ROUNDPS — Round Packed Single Precision Values

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0000 1000:11 xmmreg1

xmmreg2: imm8

mem to xmmreg, imm8

0110 0110:0000 1111:0011 1010: 0000 1000: mod xmmreg r/m:

imm8

ROUNDSD — Round Scalar Double Precision Value

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0000 1011:11 xmmreg1

xmmreg2: imm8

mem to xmmreg, imm8

0110 0110:0000 1111:0011 1010: 0000 1011: mod xmmreg r/m:

imm8

ROUNDSS — Round Scalar Single Precision Value

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0000 1010:11 xmmreg1

xmmreg2: imm8

mem to xmmreg, imm8

0110 0110:0000 1111:0011 1010: 0000 1010: mod xmmreg r/m:

imm8

B.15 SSE4.2 FORMATS AND ENCODING TABLE

The tables in this section provide SSE4.2 formats and encodings. Some SSE4.2 instructions require a mandatory

prefix (66H, F2H, F3H) as part of the three-byte opcode. These prefixes are included in the tables. In 64-bit mode,

some instructions requires REX.W, the byte sequence of REX.W prefix in the opcode sequence is shown.

Table B-36. Encodings of SSE4.2 instructions

Instruction and Format

Encoding

CRC32 — Accumulate CRC32

reg2 to reg1

1111 0010:0000 1111:0011 1000: 1111 000w :11 reg1 reg2

mem to reg

1111 0010:0000 1111:0011 1000: 1111 000w : mod reg r/m

bytereg2 to reg1

1111 0010:0100 WR0B:0000 1111:0011 1000: 1111 0000 :11

reg1 bytereg2

m8 to reg

1111 0010:0100 WR0B:0000 1111:0011 1000: 1111 0000 : mod

reg r/m

qwreg2 to qwreg1

1111 0010:0100 1R0B:0000 1111:0011 1000: 1111 0001 :11

qwreg1 qwreg2

mem64 to qwreg

1111 0010:0100 1R0B:0000 1111:0011 1000: 1111 0001 : mod

qwreg r/m

PCMPESTRI— Packed Compare Explicit-Length Strings To Index

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0110 0001:11 xmmreg1

xmmreg2: imm8

mem to xmmreg

0110 0110:0000 1111:0011 1010: 0110 0001: mod xmmreg r/m

PCMPESTRM— Packed Compare Explicit-Length Strings To Mask

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0110 0000:11 xmmreg1

xmmreg2: imm8

Vol. 2D B-69

INSTRUCTION FORMATS AND ENCODINGS

Table B-36. Encodings of SSE4.2 instructions

Instruction and Format

Encoding

mem to xmmreg

0110 0110:0000 1111:0011 1010: 0110 0000: mod xmmreg r/m

PCMPISTRI— Packed Compare Implicit-Length String To Index

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0110 0011:11 xmmreg1

xmmreg2: imm8

mem to xmmreg

0110 0110:0000 1111:0011 1010: 0110 0011: mod xmmreg r/m

PCMPISTRM— Packed Compare Implicit-Length Strings To Mask

xmmreg2 to xmmreg1, imm8

0110 0110:0000 1111:0011 1010: 0110 0010:11 xmmreg1

xmmreg2: imm8

mem to xmmreg

0110 0110:0000 1111:0011 1010: 0110 0010: mod xmmreg r/m

PCMPGTQ— Packed Compare Greater Than

xmmreg to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0111:11 xmmreg1

xmmreg2

mem to xmmreg

0110 0110:0000 1111:0011 1000: 0011 0111: mod xmmreg r/m

POPCNT— Return Number of Bits Set to 1

reg2 to reg1

1111 0011:0000 1111:1011 1000:11 reg1 reg2

mem to reg1

1111 0011:0000 1111:1011 1000:mod reg1 r/m

qwreg2 to qwreg1

1111 0011:0100 1R0B:0000 1111:1011 1000:11 reg1 reg2

mem64 to qwreg1

1111 0011:0100 1R0B:0000 1111:1011 1000:mod reg1 r/m

B.16 AVX FORMATS AND ENCODING TABLE

The tables in this section provide AVX formats and encodings. A mixed form of bit/hex/symbolic forms are used to

express the various bytes:

The C4/C5 and opcode bytes are expressed in hex notation; the first and second payload byte of VEX, the modR/M

byte is expressed in combination of bit/symbolic form. The first payload byte of C4 is expressed as combination of

bits and hex form, with the hex value preceded by an underscore. The VEX bit field to encode upper register 8-15

uses 1’s complement form, each of those bit field is expressed as lower case notation rxb, instead of RXB.

The hybrid bit-nibble-byte form is depicted below:

hex notation

7 6 ----3 2 1 0

hex notation

7-6

5-3

2-0

C5

R srcreg Lp p

Opcode byte

Mod Reg* R/M

Two-Byte VEX

7 6 5

4 ----- 0

7 6 ----3 2 1 0

hex notation

7-6

5-3

2-0

C4

R X B

0_hex

W srcreg L pp

Opcode byte

Mod Reg R/M

mmmmm

Three-Byte VEX

Figure B-2. Hybrid Notation of VEX-Encoded Key Instruction Bytes

B-70

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-37. Encodings of AVX instructions

Instruction and Format

Encoding

VBLENDPD — Blend Packed Double Precision Floats

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_3: w xmmreg2 001:0D:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_3: w xmmreg2 001:0D:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 into ymmreg1

C4: rxb0_3: w ymmreg2 101:0D:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1

C4: rxb0_3: w ymmreg2 101:0D:mod ymmreg1 r/m: imm

VBLENDPS — Blend Packed Single Precision Floats

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_3: w xmmreg2 001:0C:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_3: w xmmreg2 001:0C:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 into ymmreg1

C4: rxb0_3: w ymmreg2 101:0C:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1

C4: rxb0_3: w ymmreg2 101:0C:mod ymmreg1 r/m: imm

VBLENDVPD — Variable Blend Packed Double Precision Floats

xmmreg2 with xmmreg3 into xmmreg1 using xmmreg4 as

C4: rxb0_3: 0 xmmreg2 001:4B:11 xmmreg1 xmmreg3: xmmreg4

mask

xmmreg2 with mem to xmmreg1 using xmmreg4 as mask

C4: rxb0_3: 0 xmmreg2 001:4B:mod xmmreg1 r/m: xmmreg4

ymmreg2 with ymmreg3 into ymmreg1 using ymmreg4 as

C4: rxb0_3: 0 ymmreg2 101:4B:11 ymmreg1 ymmreg3: ymmreg4

mask

ymmreg2 with mem to ymmreg1 using ymmreg4 as mask

C4: rxb0_3: 0 ymmreg2 101:4B:mod ymmreg1 r/m: ymmreg4

VBLENDVPS — Variable Blend Packed Single Precision Floats

xmmreg2 with xmmreg3 into xmmreg1 using xmmreg4 as

C4: rxb0_3: 0 xmmreg2 001:4A:11 xmmreg1 xmmreg3: xmmreg4

mask

xmmreg2 with mem to xmmreg1 using xmmreg4 as mask

C4: rxb0_3: 0 xmmreg2 001:4A:mod xmmreg1 r/m: xmmreg4

ymmreg2 with ymmreg3 into ymmreg1 using ymmreg4 as

C4: rxb0_3: 0 ymmreg2 101:4A:11 ymmreg1 ymmreg3: ymmreg4

mask

ymmreg2 with mem to ymmreg1 using ymmreg4 as mask

C4: rxb0_3: 0 ymmreg2 101:4A:mod ymmreg1 r/m: ymmreg4

VDPPD — Packed Double Precision Dot Products

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_3: w xmmreg2 001:41:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_3: w xmmreg2 001:41:mod xmmreg1 r/m: imm

VDPPS — Packed Single Precision Dot Products

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_3: w xmmreg2 001:40:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_3: w xmmreg2 001:40:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 into ymmreg1

C4: rxb0_3: w ymmreg2 101:40:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1

C4: rxb0_3: w ymmreg2 101:40:mod ymmreg1 r/m: imm

VEXTRACTPS — Extract From Packed Single Precision Floats

reg from xmmreg1 using imm

C4: rxb0_3: w_F 001:17:11 xmmreg1 reg: imm

mem from xmmreg1 using imm

C4: rxb0_3: w_F 001:17:mod xmmreg1 r/m: imm

VINSERTPS — Insert Into Packed Single Precision Floats

use imm to merge xmmreg3 with xmmreg2 into xmmreg1

C4: rxb0_3: w xmmreg2 001:21:11 xmmreg1 xmmreg3: imm

use imm to merge mem with xmmreg2 into xmmreg1

C4: rxb0_3: w xmmreg2 001:21:mod xmmreg1 r/m: imm

VMOVNTDQA — Load Double Quadword Non-temporal Aligned

m128 to xmmreg1

C4: rxb0_2: w_F 001:2A:11 xmmreg1 r/m

Vol. 2D B-71

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

VMPSADBW — Multiple Packed Sums of Absolute Difference

xmmreg3 with xmmreg2 into xmmreg1

C4: rxb0_3: w xmmreg2 001:42:11 xmmreg1 xmmreg3: imm

m128 with xmmreg2 into xmmreg1

C4: rxb0_3: w xmmreg2 001:42:mod xmmreg1 r/m: imm

VPACKUSDW — Pack with Unsigned Saturation

xmmreg3 and xmmreg2 to xmmreg1

C4: rxb0_2: w xmmreg2 001:2B:11 xmmreg1 xmmreg3: imm

m128 and xmmreg2 to xmmreg1

C4: rxb0_2: w xmmreg2 001:2B:mod xmmreg1 r/m: imm

VPBLENDVB — Variable Blend Packed Bytes

xmmreg2 with xmmreg3 into xmmreg1 using xmmreg4 as

C4: rxb0_3: w xmmreg2 001:4C:11 xmmreg1 xmmreg3: xmmreg4

mask

xmmreg2 with mem to xmmreg1 using xmmreg4 as mask

C4: rxb0_3: w xmmreg2 001:4C:mod xmmreg1 r/m: xmmreg4

VPBLENDW — Blend Packed Words

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_3: w xmmreg2 001:0E:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_3: w xmmreg2 001:0E:mod xmmreg1 r/m: imm

VPCMPEQQ — Compare Packed Qword Data of Equal

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:29:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:29:mod xmmreg1 r/m:

VPEXTRB — Extract Byte

reg from xmmreg1 using imm

C4: rxb0_3: 0_F 001:14:11 xmmreg1 reg: imm

mem from xmmreg1 using imm

C4: rxb0_3: 0_F 001:14:mod xmmreg1 r/m: imm

VPEXTRD — Extract DWord

reg from xmmreg1 using imm

C4: rxb0_3: 0_F 001:16:11 xmmreg1 reg: imm

mem from xmmreg1 using imm

C4: rxb0_3: 0_F 001:16:mod xmmreg1 r/m: imm

VPEXTRQ — Extract QWord

reg from xmmreg1 using imm

C4: rxb0_3: 1_F 001:16:11 xmmreg1 reg: imm

mem from xmmreg1 using imm

C4: rxb0_3: 1_F 001:16:mod xmmreg1 r/m: imm

VPEXTRW — Extract Word

reg from xmmreg1 using imm

C4: rxb0_3: 0_F 001:15:11 xmmreg1 reg: imm

mem from xmmreg1 using imm

C4: rxb0_3: 0_F 001:15:mod xmmreg1 r/m: imm

VPHMINPOSUW — Packed Horizontal Word Minimum

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:41:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:41:mod xmmreg1 r/m

VPINSRB — Insert Byte

reg with xmmreg2 to xmmreg1, imm8

C4: rxb0_3: 0 xmmreg2 001:20:11 xmmreg1 reg: imm

mem with xmmreg2 to xmmreg1, imm8

C4: rxb0_3: 0 xmmreg2 001:20:mod xmmreg1 r/m: imm

VPINSRD — Insert DWord

reg with xmmreg2 to xmmreg1, imm8

C4: rxb0_3: 0 xmmreg2 001:22:11 xmmreg1 reg: imm

mem with xmmreg2 to xmmreg1, imm8

C4: rxb0_3: 0 xmmreg2 001:22:mod xmmreg1 r/m: imm

VPINSRQ — Insert QWord

r64 with xmmreg2 to xmmreg1, imm8

C4: rxb0_3: 1 xmmreg2 001:22:11 xmmreg1 reg: imm

B-72

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

m64 with xmmreg2 to xmmreg1, imm8

C4: rxb0_3: 1 xmmreg2 001:22:mod xmmreg1 r/m: imm

VPMAXSB — Maximum of Packed Signed Byte Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:3C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:3C:mod xmmreg1 r/m

VPMAXSD — Maximum of Packed Signed Dword Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:3D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:3D:mod xmmreg1 r/m

VPMAXUD — Maximum of Packed Unsigned Dword Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:3F:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:3F:mod xmmreg1 r/m

VPMAXUW — Maximum of Packed Unsigned Word Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:3E:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:3E:mod xmmreg1 r/m

VPMINSB — Minimum of Packed Signed Byte Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:38:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:38:mod xmmreg1 r/m

VPMINSD — Minimum of Packed Signed Dword Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:39:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:39:mod xmmreg1 r/m

VPMINUD — Minimum of Packed Unsigned Dword Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:3B:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:3B:mod xmmreg1 r/m

VPMINUW — Minimum of Packed Unsigned Word Integers

xmmreg2 with xmmreg3 into xmmreg1

C4: rxb0_2: w xmmreg2 001:3A:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:3A:mod xmmreg1 r/m

VPMOVSXBD — Packed Move Sign Extend - Byte to Dword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:21:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:21:mod xmmreg1 r/m

VPMOVSXBQ — Packed Move Sign Extend - Byte to Qword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:22:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:22:mod xmmreg1 r/m

VPMOVSXBW — Packed Move Sign Extend - Byte to Word

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:20:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:20:mod xmmreg1 r/m

VPMOVSXWD — Packed Move Sign Extend - Word to Dword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:23:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:23:mod xmmreg1 r/m

VPMOVSXWQ — Packed Move Sign Extend - Word to Qword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:24:11 xmmreg1 xmmreg2

Vol. 2D B-73

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

mem to xmmreg1

C4: rxb0_2: w_F 001:24:mod xmmreg1 r/m

VPMOVSXDQ — Packed Move Sign Extend - Dword to Qword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:25:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:25:mod xmmreg1 r/m

VPMOVZXBD — Packed Move Zero Extend - Byte to Dword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:31:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:31:mod xmmreg1 r/m

VPMOVZXBQ — Packed Move Zero Extend - Byte to Qword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:32:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:32:mod xmmreg1 r/m

VPMOVZXBW — Packed Move Zero Extend - Byte to Word

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:30:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:30:mod xmmreg1 r/m

VPMOVZXWD — Packed Move Zero Extend - Word to Dword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:33:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:33:mod xmmreg1 r/m

VPMOVZXWQ — Packed Move Zero Extend - Word to Qword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:34:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:34:mod xmmreg1 r/m

VPMOVZXDQ — Packed Move Zero Extend - Dword to Qword

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:35:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:35:mod xmmreg1 r/m

VPMULDQ — Multiply Packed Signed Dword Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:28:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:28:mod xmmreg1 r/m

VPMULLD — Multiply Packed Signed Dword Integers, Store low Result

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:40:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:40:mod xmmreg1 r/m

VPTEST — Logical Compare

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:17:11 xmmreg1 xmmreg2

mem to xmmreg

C4: rxb0_2: w_F 001:17:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_2: w_F 101:17:11 ymmreg1 ymmreg2

mem to ymmreg

C4: rxb0_2: w_F 101:17:mod ymmreg1 r/m

VROUNDPD — Round Packed Double Precision Values

xmmreg2 to xmmreg1, imm8

C4: rxb0_3: w_F 001:09:11 xmmreg1 xmmreg2: imm

mem to xmmreg1, imm8

C4: rxb0_3: w_F 001:09:mod xmmreg1 r/m: imm

ymmreg2 to ymmreg1, imm8

C4: rxb0_3: w_F 101:09:11 ymmreg1 ymmreg2: imm

mem to ymmreg1, imm8

C4: rxb0_3: w_F 101:09:mod ymmreg1 r/m: imm

VROUNDPS — Round Packed Single Precision Values

B-74

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 to xmmreg1, imm8

C4: rxb0_3: w_F 001:08:11 xmmreg1 xmmreg2: imm

mem to xmmreg1, imm8

C4: rxb0_3: w_F 001:08:mod xmmreg1 r/m: imm

ymmreg2 to ymmreg1, imm8

C4: rxb0_3: w_F 101:08:11 ymmreg1 ymmreg2: imm

mem to ymmreg1, imm8

C4: rxb0_3: w_F 101:08:mod ymmreg1 r/m: imm

VROUNDSD — Round Scalar Double Precision Value

xmmreg2 and xmmreg3 to xmmreg1, imm8

C4: rxb0_3: w xmmreg2 001:0B:11 xmmreg1 xmmreg3: imm

xmmreg2 and mem to xmmreg1, imm8

C4: rxb0_3: w xmmreg2 001:0B:mod xmmreg1 r/m: imm

VROUNDSS — Round Scalar Single Precision Value

xmmreg2 and xmmreg3 to xmmreg1, imm8

C4: rxb0_3: w xmmreg2 001:0A:11 xmmreg1 xmmreg3: imm

xmmreg2 and mem to xmmreg1, imm8

C4: rxb0_3: w xmmreg2 001:0A:mod xmmreg1 r/m: imm

VPCMPESTRI — Packed Compare Explicit Length Strings, Return Index

xmmreg2 with xmmreg1, imm8

C4: rxb0_3: w_F 001:61:11 xmmreg1 xmmreg2: imm

mem with xmmreg1, imm8

C4: rxb0_3: w_F 001:61:mod xmmreg1 r/m: imm

VPCMPESTRM — Packed Compare Explicit Length Strings, Return Mask

xmmreg2 with xmmreg1, imm8

C4: rxb0_3: w_F 001:60:11 xmmreg1 xmmreg2: imm

mem with xmmreg1, imm8

C4: rxb0_3: w_F 001:60:mod xmmreg1 r/m: imm

VPCMPGTQ — Compare Packed Data for Greater Than

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:28:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:28:mod xmmreg1 r/m

VPCMPISTRI — Packed Compare Implicit Length Strings, Return Index

xmmreg2 with xmmreg1, imm8

C4: rxb0_3: w_F 001:63:11 xmmreg1 xmmreg2: imm

mem with xmmreg1, imm8

C4: rxb0_3: w_F 001:63:mod xmmreg1 r/m: imm

VPCMPISTRM — Packed Compare Implicit Length Strings, Return Mask

xmmreg2 with xmmreg1, imm8

C4: rxb0_3: w_F 001:62:11 xmmreg1 xmmreg2: imm

mem with xmmreg, imm8

C4: rxb0_3: w_F 001:62:mod xmmreg1 r/m: imm

VAESDEC — Perform One Round of an AES Decryption Flow

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:DE:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:DE:mod xmmreg1 r/m

VAESDECLAST — Perform Last Round of an AES Decryption Flow

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:DF:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:DF:mod xmmreg1 r/m

VAESENC — Perform One Round of an AES Encryption Flow

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:DC:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:DC:mod xmmreg1 r/m

VAESENCLAST — Perform Last Round of an AES Encryption Flow

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:DD:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:DD:mod xmmreg1 r/m

VAESIMC — Perform the AES InvMixColumn Transformation

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:DB:11 xmmreg1 xmmreg2

Vol. 2D B-75

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

mem to xmmreg1

C4: rxb0_2: w_F 001:DB:mod xmmreg1 r/m

VAESKEYGENASSIST — AES Round Key Generation Assist

xmmreg2 to xmmreg1, imm8

C4: rxb0_3: w_F 001:DF:11 xmmreg1 xmmreg2: imm

mem to xmmreg, imm8

C4: rxb0_3: w_F 001:DF:mod xmmreg1 r/m: imm

VPABSB — Packed Absolute Value

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:1C:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:1C:mod xmmreg1 r/m

VPABSD — Packed Absolute Value

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:1E:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:1E:mod xmmreg1 r/m

VPABSW — Packed Absolute Value

xmmreg2 to xmmreg1

C4: rxb0_2: w_F 001:1D:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_2: w_F 001:1D:mod xmmreg1 r/m

VPALIGNR — Packed Align Right

xmmreg2 with xmmreg3 to xmmreg1, imm8

C4: rxb0_3: w xmmreg2 001:DD:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1, imm8

C4: rxb0_3: w xmmreg2 001:DD:mod xmmreg1 r/m: imm

VPHADDD — Packed Horizontal Add

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:02:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:02:mod xmmreg1 r/m

VPHADDW — Packed Horizontal Add

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:01:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:01:mod xmmreg1 r/m

VPHADDSW — Packed Horizontal Add and Saturate

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:03:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:03:mod xmmreg1 r/m

VPHSUBD — Packed Horizontal Subtract

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:06:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:06:mod xmmreg1 r/m

VPHSUBW — Packed Horizontal Subtract

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:05:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:05:mod xmmreg1 r/m

VPHSUBSW — Packed Horizontal Subtract and Saturate

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:07:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:07:mod xmmreg1 r/m

VPMADDUBSW — Multiply and Add Packed Signed and Unsigned Bytes

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:04:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:04:mod xmmreg1 r/m

VPMULHRSW — Packed Multiply High with Round and Scale

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:0B:11 xmmreg1 xmmreg3

B-76

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:0B:mod xmmreg1 r/m

VPSHUFB — Packed Shuffle Bytes

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:00:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:00:mod xmmreg1 r/m

VPSIGNB — Packed SIGN

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:08:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:08:mod xmmreg1 r/m

VPSIGND — Packed SIGN

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:0A:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:0A:mod xmmreg1 r/m

VPSIGNW — Packed SIGN

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: w xmmreg2 001:09:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: w xmmreg2 001:09:mod xmmreg1 r/m

VADDSUBPD — Packed Double-FP Add/Subtract

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D0:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D0:mod xmmreg1 r/m

xmmreglo2¹ with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D0:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D0:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:D0:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:D0:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:D0:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:D0:mod ymmreg1 r/m

VADDSUBPS — Packed Single-FP Add/Subtract

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:D0:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:D0:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:D0:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:D0:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 111:D0:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 111:D0:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 111:D0:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 111:D0:mod ymmreg1 r/m

VHADDPD — Packed Double-FP Horizontal Add

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:7C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:7C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:7C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:7C:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:7C:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:7C:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:7C:11 ymmreg1 ymmreglo3

Vol. 2D B-77

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:7C:mod ymmreg1 r/m

VHADDPS — Packed Single-FP Horizontal Add

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:7C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:7C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:7C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:7C:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 111:7C:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 111:7C:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 111:7C:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 111:7C:mod ymmreg1 r/m

VHSUBPD — Packed Double-FP Horizontal Subtract

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:7D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:7D:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:7D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:7D:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:7D:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:7D:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:7D:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:7D:mod ymmreg1 r/m

VHSUBPS — Packed Single-FP Horizontal Subtract

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:7D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:7D:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:7D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:7D:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 111:7D:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 111:7D:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 111:7D:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 111:7D:mod ymmreg1 r/m

VLDDQU — Load Unaligned Integer 128 Bits

mem to xmmreg1

C4: rxb0_1: w_F 011:F0:mod xmmreg1 r/m

mem to xmmreg1

C5: r_F 011:F0:mod xmmreg1 r/m

mem to ymmreg1

C4: rxb0_1: w_F 111:F0:mod ymmreg1 r/m

mem to ymmreg1

C5: r_F 111:F0:mod ymmreg1 r/m

VMOVDDUP — Move One Double-FP and Duplicate

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 011:12:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 011:12:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 011:12:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 011:12:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 111:12:11 ymmreg1 ymmreg2

B-78

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

mem to ymmreg1

C4: rxb0_1: w_F 111:12:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_ F 111:12:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 111:12:mod ymmreg1 r/m

VMOVHLPS — Move Packed Single Precision Floating-Point Values High to Low

xmmreg2 and xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:12:11 xmmreg1 xmmreg3

xmmreglo2 and xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:12:11 xmmreg1 xmmreglo3

VMOVSHDUP — Move Packed Single-FP High and Duplicate

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 010:16:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 010:16:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 010:16:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 010:16:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 110:16:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 110:16:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 110:16:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 110:16:mod ymmreg1 r/m

VMOVSLDUP — Move Packed Single-FP Low and Duplicate

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 010:12:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 010:12:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 010:12:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 010:12:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 110:12:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 110:12:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 110:12:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 110:12:mod ymmreg1 r/m

VADDPD — Add Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:58:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:58:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:58:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:58:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:58:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:58:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:58:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:58:mod ymmreg1 r/m

VADDSD — Add Scalar Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:58:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:58:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:58:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5 r_xmmreglo2 011:58:mod xmmreg1 r/m

VANDPD — Bitwise Logical AND of Packed Double Precision Floating-Point Values

Vol. 2D B-79

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:54:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:54:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:54:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:54:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:54:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:54:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:54:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:54:mod ymmreg1 r/m

VANDNPD — Bitwise Logical AND NOT of Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:55:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:55:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:55:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:55:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:55:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:55:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:55:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:55:mod ymmreg1 r/m

VCMPPD — Compare Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:C2:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:C2:mod xmmreg1 r/m: imm

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:C2:11 xmmreg1 xmmreglo3: imm

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:C2:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:C2:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:C2:mod ymmreg1 r/m: imm

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:C2:11 ymmreg1 ymmreglo3: imm

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:C2:mod ymmreg1 r/m: imm

VCMPSD — Compare Scalar Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:C2:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:C2:mod xmmreg1 r/m: imm

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:C2:11 xmmreg1 xmmreglo3: imm

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:C2:mod xmmreg1 r/m: imm

VCOMISD — Compare Scalar Ordered Double Precision Floating-Point Values and Set EFLAGS

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:2F:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:2F:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:2F:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:2F:mod xmmreg1 r/m

VCVTDQ2PD— Convert Packed Dword Integers to Packed Double Precision FP Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 010:E6:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 010:E6:mod xmmreg1 r/m

B-80

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo to xmmreg1

C5: r_F 010:E6:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 010:E6:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 110:E6:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 110:E6:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 110:E6:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 110:E6:mod ymmreg1 r/m

VCVTDQ2PS— Convert Packed Dword Integers to Packed Single Precision FP Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:5B:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:5B:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:5B:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:5B:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:5B:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:5B:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:5B:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:5B:mod ymmreg1 r/m

VCVTPD2DQ— Convert Packed Double Precision FP Values to Packed Dword Integers

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 011:E6:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 011:E6:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 011:E6:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 011:E6:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 111:E6:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 111:E6:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 111:E6:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 111:E6:mod ymmreg1 r/m

VCVTPD2PS— Convert Packed Double Precision FP Values to Packed Single Precision FP Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:5A:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:5A:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:5A:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:5A:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:5A:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 101:5A:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 101:5A:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:5A:mod ymmreg1 r/m

VCVTPS2DQ— Convert Packed Single Precision FP Values to Packed Dword Integers

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:5B:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:5B:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:5B:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:5B:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:5B:11 ymmreg1 ymmreg2

Vol. 2D B-81

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

mem to ymmreg1

C4: rxb0_1: w_F 101:5B:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 101:5B:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:5B:mod ymmreg1 r/m

VCVTPS2PD— Convert Packed Single Precision FP Values to Packed Double Precision FP Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:5A:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:5A:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:5A:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:5A:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:5A:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:5A:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:5A:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:5A:mod ymmreg1 r/m

VCVTSD2SI— Convert Scalar Double Precision FP Value to Integer

xmmreg1 to reg32

C4: rxb0_1: 0_F 011:2D:11 reg xmmreg1

mem to reg32

C4: rxb0_1: 0_F 011:2D:mod reg r/m

xmmreglo to reg32

C5: r_F 011:2D:11 reg xmmreglo

mem to reg32

C5: r_F 011:2D:mod reg r/m

ymmreg1 to reg64

C4: rxb0_1: 1_F 111:2D:11 reg ymmreg1

mem to reg64

C4: rxb0_1: 1_F 111:2D:mod reg r/m

VCVTSD2SS — Convert Scalar Double Precision FP Value to Scalar Single Precision FP Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:5A:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:5A:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:5A:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:5A:mod xmmreg1 r/m

VCVTSI2SD— Convert Dword Integer to Scalar Double Precision FP Value

xmmreg2 with reg to xmmreg1

C4: rxb0_1: 0 xmmreg2 011:2A:11 xmmreg1 reg

xmmreg2 with mem to xmmreg1

C4: rxb0_1: 0 xmmreg2 011:2A:mod xmmreg1 r/m

xmmreglo2 with reglo to xmmreg1

C5: r_xmmreglo2 011:2A:11 xmmreg1 reglo

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:2A:mod xmmreg1 r/m

ymmreg2 with reg to ymmreg1

C4: rxb0_1: 1 ymmreg2 111:2A:11 ymmreg1 reg

ymmreg2 with mem to ymmreg1

C4: rxb0_1: 1 ymmreg2 111:2A:mod ymmreg1 r/m

VCVTSS2SD — Convert Scalar Single Precision FP Value to Scalar Double Precision FP Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:5A:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:5A:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:5A:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:5A:mod xmmreg1 r/m

VCVTTPD2DQ— Convert with Truncation Packed Double Precision FP Values to Packed Dword Integers

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:E6:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:E6:mod xmmreg1 r/m

B-82

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo to xmmreg1

C5: r_F 001:E6:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:E6:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:E6:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 101:E6:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 101:E6:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:E6:mod ymmreg1 r/m

VCVTTPS2DQ— Convert with Truncation Packed Single Precision FP Values to Packed Dword Integers

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 010:5B:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 010:5B:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 010:5B:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 010:5B:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 110:5B:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 110:5B:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 110:5B:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 110:5B:mod ymmreg1 r/m

VCVTTSD2SI— Convert with Truncation Scalar Double Precision FP Value to Signed Integer

xmmreg1 to reg32

C4: rxb0_1: 0_F 011:2C:11 reg xmmreg1

mem to reg32

C4: rxb0_1: 0_F 011:2C:mod reg r/m

xmmreglo to reg32

C5: r_F 011:2C:11 reg xmmreglo

mem to reg32

C5: r_F 011:2C:mod reg r/m

xmmreg1 to reg64

C4: rxb0_1: 1_F 011:2C:11 reg xmmreg1

mem to reg64

C4: rxb0_1: 1_F 011:2C:mod reg r/m

VDIVPD — Divide Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:5E:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:5E:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:5E:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:5E:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:5E:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:5E:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:5E:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:5E:mod ymmreg1 r/m

VDIVSD — Divide Scalar Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:5E:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:5E:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:5E:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:5E:mod xmmreg1 r/m

VMASKMOVDQU— Store Selected Bytes of Double Quadword

xmmreg1 to mem; xmmreg2 as mask

C4: rxb0_1: w_F 001:F7:11 r/m xmmreg1: xmmreg2

xmmreg1 to mem; xmmreg2 as mask

C5: r_F 001:F7:11 r/m xmmreg1: xmmreg2

Vol. 2D B-83

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

VMAXPD — Return Maximum Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:5F:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:5F:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:5F:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:5F:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:5F:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:5F:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:5F:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:5F:mod ymmreg1 r/m

VMAXSD — Return Maximum Scalar Double Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:5F:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:5F:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:5F:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:5F:mod xmmreg1 r/m

VMINPD — Return Minimum Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:5D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:5D:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:5D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:5D:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:5D:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:5D:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:5D:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:5D:mod ymmreg1 r/m

VMINSD — Return Minimum Scalar Double Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:5D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:5D:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:5D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:5D:mod xmmreg1 r/m

VMOVAPD — Move Aligned Packed Double Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:28:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:28:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:28:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:28:mod xmmreg1 r/m

xmmreg1 to xmmreg2

C4: rxb0_1: w_F 001:29:11 xmmreg2 xmmreg1

xmmreg1 to mem

C4: rxb0_1: w_F 001:29:mod r/m xmmreg1

xmmreg1 to xmmreglo

C5: r_F 001:29:11 xmmreglo xmmreg1

xmmreg1 to mem

C5: r_F 001:29:mod r/m xmmreg1

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:28:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 101:28:mod ymmreg1 r/m

B-84

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

ymmreglo to ymmreg1

C5: r_F 101:28:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:28:mod ymmreg1 r/m

ymmreg1 to ymmreg2

C4: rxb0_1: w_F 101:29:11 ymmreg2 ymmreg1

ymmreg1 to mem

C4: rxb0_1: w_F 101:29:mod r/m ymmreg1

ymmreg1 to ymmreglo

C5: r_F 101:29:11 ymmreglo ymmreg1

ymmreg1 to mem

C5: r_F 101:29:mod r/m ymmreg1

VMOVD — Move Doubleword

reg32 to xmmreg1

C4: rxb0_1: 0_F 001:6E:11 xmmreg1 reg32

mem32 to xmmreg1

C4: rxb0_1: 0_F 001:6E:mod xmmreg1 r/m

reg32 to xmmreg1

C5: r_F 001:6E:11 xmmreg1 reg32

mem32 to xmmreg1

C5: r_F 001:6E:mod xmmreg1 r/m

xmmreg1 to reg32

C4: rxb0_1: 0_F 001:7E:11 reg32 xmmreg1

xmmreg1 to mem32

C4: rxb0_1: 0_F 001:7E:mod mem32 xmmreg1

xmmreglo to reg32

C5: r_F 001:7E:11 reg32 xmmreglo

xmmreglo to mem32

C5: r_F 001:7E:mod mem32 xmmreglo

VMOVQ — Move Quadword

reg64 to xmmreg1

C4: rxb0_1: 1_F 001:6E:11 xmmreg1 reg64

mem64 to xmmreg1

C4: rxb0_1: 1_F 001:6E:mod xmmreg1 r/m

xmmreg1 to reg64

C4: rxb0_1: 1_F 001:7E:11 reg64 xmmreg1

xmmreg1 to mem64

C4: rxb0_1: 1_F 001:7E:mod r/m xmmreg1

VMOVDQA — Move Aligned Double Quadword

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:6F:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:6F:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:6F:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:6F:mod xmmreg1 r/m

xmmreg1 to xmmreg2

C4: rxb0_1: w_F 001:7F:11 xmmreg2 xmmreg1

xmmreg1 to mem

C4: rxb0_1: w_F 001:7F:mod r/m xmmreg1

xmmreg1 to xmmreglo

C5: r_F 001:7F:11 xmmreglo xmmreg1

xmmreg1 to mem

C5: r_F 001:7F:mod r/m xmmreg1

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:6F:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 101:6F:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 101:6F:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:6F:mod ymmreg1 r/m

ymmreg1 to ymmreg2

C4: rxb0_1: w_F 101:7F:11 ymmreg2 ymmreg1

ymmreg1 to mem

C4: rxb0_1: w_F 101:7F:mod r/m ymmreg1

ymmreg1 to ymmreglo

C5: r_F 101:7F:11 ymmreglo ymmreg1

ymmreg1 to mem

C5: r_F 101:7F:mod r/m ymmreg1

VMOVDQU — Move Unaligned Double Quadword

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 010:6F:11 xmmreg1 xmmreg2

Vol. 2D B-85

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

mem to xmmreg1

C4: rxb0_1: w_F 010:6F:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 010:6F:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 010:6F:mod xmmreg1 r/m

xmmreg1 to xmmreg2

C4: rxb0_1: w_F 010:7F:11 xmmreg2 xmmreg1

xmmreg1 to mem

C4: rxb0_1: w_F 010:7F:mod r/m xmmreg1

xmmreg1 to xmmreglo

C5: r_F 010:7F:11 xmmreglo xmmreg1

xmmreg1 to mem

C5: r_F 010:7F:mod r/m xmmreg1

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 110:6F:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 110:6F:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 110:6F:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 110:6F:mod ymmreg1 r/m

ymmreg1 to ymmreg2

C4: rxb0_1: w_F 110:7F:11 ymmreg2 ymmreg1

ymmreg1 to mem

C4: rxb0_1: w_F 110:7F:mod r/m ymmreg1

ymmreg1 to ymmreglo

C5: r_F 110:7F:11 ymmreglo ymmreg1

ymmreg1 to mem

C5: r_F 110:7F:mod r/m ymmreg1

VMOVHPD — Move High Packed Double Precision Floating-Point Value

xmmreg1 and mem to xmmreg2

C4: rxb0_1: w xmmreg1 001:16:11 xmmreg2 r/m

xmmreg1 and mem to xmmreglo2

C5: r_xmmreg1 001:16:11 xmmreglo2 r/m

xmmreg1 to mem

C4: rxb0_1: w_F 001:17:mod r/m xmmreg1

xmmreglo to mem

C5: r_F 001:17:mod r/m xmmreglo

VMOVLPD — Move Low Packed Double Precision Floating-Point Value

xmmreg1 and mem to xmmreg2

C4: rxb0_1: w xmmreg1 001:12:11 xmmreg2 r/m

xmmreg1 and mem to xmmreglo2

C5: r_xmmreg1 001:12:11 xmmreglo2 r/m

xmmreg1 to mem

C4: rxb0_1: w_F 001:13:mod r/m xmmreg1

xmmreglo to mem

C5: r_F 001:13:mod r/m xmmreglo

VMOVMSKPD — Extract Packed Double Precision Floating-Point Sign Mask

xmmreg2 to reg

C4: rxb0_1: w_F 001:50:11 reg xmmreg1

xmmreglo to reg

C5: r_F 001:50:11 reg xmmreglo

ymmreg2 to reg

C4: rxb0_1: w_F 101:50:11 reg ymmreg1

ymmreglo to reg

C5: r_F 101:50:11 reg ymmreglo

VMOVNTDQ — Store Double Quadword Using Non-Temporal Hint

xmmreg1 to mem

C4: rxb0_1: w_F 001:E7:11 r/m xmmreg1

xmmreglo to mem

C5: r_F 001:E7:11 r/m xmmreglo

ymmreg1 to mem

C4: rxb0_1: w_F 101:E7:11 r/m ymmreg1

ymmreglo to mem

C5: r_F 101:E7:11 r/m ymmreglo

VMOVNTPD — Store Packed Double Precision Floating-Point Values Using Non-Temporal Hint

xmmreg1 to mem

C4: rxb0_1: w_F 001:2B:11 r/m xmmreg1

xmmreglo to mem

C5: r_F 001:2B:11 r/m xmmreglo

ymmreg1 to mem

C4: rxb0_1: w_F 101:2B:11r/m ymmreg1

B-86

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

ymmreglo to mem

C5: r_F 101:2B:11r/m ymmreglo

VMOVSD — Move Scalar Double Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:10:11 xmmreg1 xmmreg3

mem to xmmreg1

C4: rxb0_1: w_F 011:10:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:10:11 xmmreg1 xmmreglo3

mem to xmmreg1

C5: r_F 011:10:mod xmmreg1 r/m

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:11:11 xmmreg1 xmmreg3

xmmreg1 to mem

C4: rxb0_1: w_F 011:11:mod r/m xmmreg1

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:11:11 xmmreg1 xmmreglo3

xmmreglo to mem

C5: r_F 011:11:mod r/m xmmreglo

VMOVUPD — Move Unaligned Packed Double Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:10:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:10:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:10:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:10:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:10:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 101:10:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 101:10:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:10:mod ymmreg1 r/m

xmmreg1 to xmmreg2

C4: rxb0_1: w_F 001:11:11 xmmreg2 xmmreg1

xmmreg1 to mem

C4: rxb0_1: w_F 001:11:mod r/m xmmreg1

xmmreg1 to xmmreglo

C5: r_F 001:11:11 xmmreglo xmmreg1

xmmreg1 to mem

C5: r_F 001:11:mod r/m xmmreg1

ymmreg1 to ymmreg2

C4: rxb0_1: w_F 101:11:11 ymmreg2 ymmreg1

ymmreg1 to mem

C4: rxb0_1: w_F 101:11:mod r/m ymmreg1

ymmreg1 to ymmreglo

C5: r_F 101:11:11 ymmreglo ymmreg1

ymmreg1 to mem

C5: r_F 101:11:mod r/m ymmreg1

VMULPD — Multiply Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:59:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:59:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:59:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:59:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:59:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:59:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:59:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:59:mod ymmreg1 r/m

VMULSD — Multiply Scalar Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:59:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:59:mod xmmreg1 r/m

Vol. 2D B-87

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:59:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:59:mod xmmreg1 r/m

VORPD — Bitwise Logical OR of Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:56:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:56:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:56:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:56:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:56:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:56:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:56:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:56:mod ymmreg1 r/m

VPACKSSWB— Pack with Signed Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:63:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:63:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:63:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:63:mod xmmreg1 r/m

VPACKSSDW— Pack with Signed Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:6B:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:6B:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:6B:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:6B:mod xmmreg1 r/m

VPACKUSWB— Pack with Unsigned Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:67:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:67:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:67:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:67:mod xmmreg1 r/m

VPADDB — Add Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:FC:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:FC:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:FC:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:FC:mod xmmreg1 r/m

VPADDW — Add Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:FD:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:FD:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:FD:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:FD:mod xmmreg1 r/m

VPADDD — Add Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:FE:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:FE:mod xmmreg1 r/m

B-88

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:FE:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:FE:mod xmmreg1 r/m

VPADDQ — Add Packed Quadword Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D4:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D4:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D4:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D4:mod xmmreg1 r/m

VPADDSB — Add Packed Signed Integers with Signed Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:EC:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:EC:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:EC:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:EC:mod xmmreg1 r/m

VPADDSW — Add Packed Signed Integers with Signed Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:ED:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:ED:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:ED:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:ED:mod xmmreg1 r/m

VPADDUSB — Add Packed Unsigned Integers with Unsigned Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:DC:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:DC:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:DC:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:DC:mod xmmreg1 r/m

VPADDUSW — Add Packed Unsigned Integers with Unsigned Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:DD:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:DD:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:DD:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:DD:mod xmmreg1 r/m

VPAND — Logical AND

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:DB:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:DB:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:DB:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:DB:mod xmmreg1 r/m

VPANDN — Logical AND NOT

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:DF:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:DF:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:DF:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:DF:mod xmmreg1 r/m

VPAVGB — Average Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E0:11 xmmreg1 xmmreg3

Vol. 2D B-89

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E0:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E0:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E0:mod xmmreg1 r/m

VPAVGW — Average Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E3:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E3:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E3:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E3:mod xmmreg1 r/m

VPCMPEQB — Compare Packed Data for Equal

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:74:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:74:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:74:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:74:mod xmmreg1 r/m

VPCMPEQW — Compare Packed Data for Equal

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:75:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:75:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:75:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:75:mod xmmreg1 r/m

VPCMPEQD — Compare Packed Data for Equal

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:76:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:76:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:76:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:76:mod xmmreg1 r/m

VPCMPGTB — Compare Packed Signed Integers for Greater Than

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:64:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:64:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:64:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:64:mod xmmreg1 r/m

VPCMPGTW — Compare Packed Signed Integers for Greater Than

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:65:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:65:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:65:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:65:mod xmmreg1 r/m

VPCMPGTD — Compare Packed Signed Integers for Greater Than

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:66:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:66:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:66:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:66:mod xmmreg1 r/m

VPEXTRW — Extract Word

B-90

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg1 to reg using imm

C4: rxb0_1: 0_F 001:C5:11 reg xmmreg1: imm

xmmreg1 to reg using imm

C5: r_F 001:C5:11 reg xmmreg1: imm

VPINSRW — Insert Word

xmmreg2 with reg to xmmreg1

C4: rxb0_1: 0 xmmreg2 001:C4:11 xmmreg1 reg: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_1: 0 xmmreg2 001:C4:mod xmmreg1 r/m: imm

xmmreglo2 with reglo to xmmreg1

C5: r_xmmreglo2 001:C4:11 xmmreg1 reglo: imm

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:C4:mod xmmreg1 r/m: imm

VPMADDWD — Multiply and Add Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F5:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F5:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F5:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F5:mod xmmreg1 r/m

VPMAXSW — Maximum of Packed Signed Word Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:EE:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:EE:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:EE:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:EE:mod xmmreg1 r/m

VPMAXUB — Maximum of Packed Unsigned Byte Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:DE:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:DE:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:DE:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:DE:mod xmmreg1 r/m

VPMINSW — Minimum of Packed Signed Word Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:EA:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:EA:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:EA:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:EA:mod xmmreg1 r/m

VPMINUB — Minimum of Packed Unsigned Byte Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:DA:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:DA:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:DA:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:DA:mod xmmreg1 r/m

VPMOVMSKB — Move Byte Mask

xmmreg1 to reg

C4: rxb0_1: w_F 001:D7:11 reg xmmreg1

xmmreg1 to reg

C5: r_F 001:D7:11 reg xmmreg1

VPMULHUW — Multiply Packed Unsigned Integers and Store High Result

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E4:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E4:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E4:11 xmmreg1 xmmreglo3

Vol. 2D B-91

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E4:mod xmmreg1 r/m

VPMULHW — Multiply Packed Signed Integers and Store High Result

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E5:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E5:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E5:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E5:mod xmmreg1 r/m

VPMULLW — Multiply Packed Signed Integers and Store Low Result

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D5:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D5:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D5:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D5:mod xmmreg1 r/m

VPMULUDQ — Multiply Packed Unsigned Doubleword Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F4:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F4:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F4:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F4:mod xmmreg1 r/m

VPOR — Bitwise Logical OR

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:EB:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:EB:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:EB:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:EB:mod xmmreg1 r/m

VPSADBW — Compute Sum of Absolute Differences

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F6:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F6:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F6:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F6:mod xmmreg1 r/m

VPSHUFD — Shuffle Packed Doublewords

xmmreg2 to xmmreg1 using imm

C4: rxb0_1: w_F 001:70:11 xmmreg1 xmmreg2: imm

mem to xmmreg1 using imm

C4: rxb0_1: w_F 001:70:mod xmmreg1 r/m: imm

xmmreglo to xmmreg1 using imm

C5: r_F 001:70:11 xmmreg1 xmmreglo: imm

mem to xmmreg1 using imm

C5: r_F 001:70:mod xmmreg1 r/m: imm

VPSHUFHW — Shuffle Packed High Words

xmmreg2 to xmmreg1 using imm

C4: rxb0_1: w_F 010:70:11 xmmreg1 xmmreg2: imm

mem to xmmreg1 using imm

C4: rxb0_1: w_F 010:70:mod xmmreg1 r/m: imm

xmmreglo to xmmreg1 using imm

C5: r_F 010:70:11 xmmreg1 xmmreglo: imm

mem to xmmreg1 using imm

C5: r_F 010:70:mod xmmreg1 r/m: imm

VPSHUFLW — Shuffle Packed Low Words

xmmreg2 to xmmreg1 using imm

C4: rxb0_1: w_F 011:70:11 xmmreg1 xmmreg2: imm

mem to xmmreg1 using imm

C4: rxb0_1: w_F 011:70:mod xmmreg1 r/m: imm

B-92

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo to xmmreg1 using imm

C5: r_F 011:70:11 xmmreg1 xmmreglo: imm

mem to xmmreg1 using imm

C5: r_F 011:70:mod xmmreg1 r/m: imm

VPSLLDQ — Shift Double Quadword Left Logical

xmmreg2 to xmmreg1 using imm

C4: rxb0_1: w_F 001:73:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm

C5: r_F 001:73:11 xmmreg1 xmmreglo: imm

VPSLLW — Shift Packed Data Left Logical

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F1:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F1:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F1:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F1:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:71:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:71:11 xmmreg1 xmmreglo: imm

VPSLLD — Shift Packed Data Left Logical

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F2:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F2:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F2:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F2:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:72:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:72:11 xmmreg1 xmmreglo: imm

VPSLLQ — Shift Packed Data Left Logical

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F3:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F3:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F3:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F3:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:73:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:73:11 xmmreg1 xmmreglo: imm

VPSRAW — Shift Packed Data Right Arithmetic

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E1:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E1:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E1:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E1:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:71:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:71:11 xmmreg1 xmmreglo: imm

VPSRAD — Shift Packed Data Right Arithmetic

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E2:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E2:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E2:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E2:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:72:11 xmmreg1 xmmreg2: imm

Vol. 2D B-93

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo to xmmreg1 using imm8

C5: r_F 001:72:11 xmmreg1 xmmreglo: imm

VPSRLDQ — Shift Double Quadword Right Logical

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:73:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:73:11 xmmreg1 xmmreglo: imm

VPSRLW — Shift Packed Data Right Logical

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D1:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D1:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D1:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D1:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:71:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:71:11 xmmreg1 xmmreglo: imm

VPSRLD — Shift Packed Data Right Logical

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D2:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D2:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D2:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D2:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:72:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:72:11 xmmreg1 xmmreglo: imm

VPSRLQ — Shift Packed Data Right Logical

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D3:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D3:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D3:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D3:mod xmmreg1 r/m

xmmreg2 to xmmreg1 using imm8

C4: rxb0_1: w_F 001:73:11 xmmreg1 xmmreg2: imm

xmmreglo to xmmreg1 using imm8

C5: r_F 001:73:11 xmmreg1 xmmreglo: imm

VPSUBB — Subtract Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F8:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F8:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F8:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:F8:mod xmmreg1 r/m

VPSUBW — Subtract Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:F9:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:F9:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:F9:11 xmmreg1 xmmreglo3

xmmrelog2 with mem to xmmreg1

C5: r_xmmreglo2 001:F9:mod xmmreg1 r/m

VPSUBD — Subtract Packed Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:FA:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:FA:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:FA:11 xmmreg1 xmmreglo3

B-94

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:FA:mod xmmreg1 r/m

VPSUBQ — Subtract Packed Quadword Integers

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:FB:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:FB:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:FB:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:FB:mod xmmreg1 r/m

VPSUBSB — Subtract Packed Signed Integers with Signed Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E8:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E8:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E8:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E8:mod xmmreg1 r/m

VPSUBSW — Subtract Packed Signed Integers with Signed Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:E9:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:E9:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:E9:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:E9:mod xmmreg1 r/m

VPSUBUSB — Subtract Packed Unsigned Integers with Unsigned Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D8:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D8:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D8:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D8:mod xmmreg1 r/m

VPSUBUSW — Subtract Packed Unsigned Integers with Unsigned Saturation

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:D9:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:D9:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:D9:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:D9:mod xmmreg1 r/m

VPUNPCKHBW — Unpack High Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:68:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:68:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:68:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:68:mod xmmreg1 r/m

VPUNPCKHWD — Unpack High Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:69:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:69:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:69:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:69:mod xmmreg1 r/m

VPUNPCKHDQ — Unpack High Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:6A:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:6A:mod xmmreg1 r/m

Vol. 2D B-95

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:6A:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:6A:mod xmmreg1 r/m

VPUNPCKHQDQ — Unpack High Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:6D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:6D:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:6D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:6D:mod xmmreg1 r/m

VPUNPCKLBW — Unpack Low Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:60:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:60:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:60:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:60:mod xmmreg1 r/m

VPUNPCKLWD — Unpack Low Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:61:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:61:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:61:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:61:mod xmmreg1 r/m

VPUNPCKLDQ — Unpack Low Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:62:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:62:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:62:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:62:mod xmmreg1 r/m

VPUNPCKLQDQ — Unpack Low Data

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:6C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:6C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:6C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:6C:mod xmmreg1 r/m

VPXOR — Logical Exclusive OR

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:EF:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:EF:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:EF:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:EF:mod xmmreg1 r/m

VSHUFPD — Shuffle Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1 using imm8

C4: rxb0_1: w xmmreg2 001:C6:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1 using imm8

C4: rxb0_1: w xmmreg2 001:C6:mod xmmreg1 r/m: imm

xmmreglo2 with xmmreglo3 to xmmreg1 using imm8

C5: r_xmmreglo2 001:C6:11 xmmreg1 xmmreglo3: imm

xmmreglo2 with mem to xmmreg1 using imm8

C5: r_xmmreglo2 001:C6:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 to ymmreg1 using imm8

C4: rxb0_1: w ymmreg2 101:C6:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1 using imm8

C4: rxb0_1: w ymmreg2 101:C6:mod ymmreg1 r/m: imm

B-96

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

ymmreglo2 with ymmreglo3 to ymmreg1 using imm8

C5: r_ymmreglo2 101:C6:11 ymmreg1 ymmreglo3: imm

ymmreglo2 with mem to ymmreg1 using imm8

C5: r_ymmreglo2 101:C6:mod ymmreg1 r/m: imm

VSQRTPD — Compute Square Roots of Packed Double Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 001:51:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 001:51:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 001:51:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 001:51:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 101:51:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 101:51:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 101:51:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 101:51:mod ymmreg1 r/m

VSQRTSD — Compute Square Root of Scalar Double Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:51:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:51:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:51:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:51:mod xmmreg1 r/m

VSUBPD — Subtract Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:5C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:5C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:5C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:5C:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:5C:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:5C:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:5C:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:5C:mod ymmreg1 r/m

VSUBSD — Subtract Scalar Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 011:5C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 011:5C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 011:5C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 011:5C:mod xmmreg1 r/m

VUCOMISD — Unordered Compare Scalar Double Precision Floating-Point Values and Set EFLAGS

xmmreg2 with xmmreg1, set EFLAGS

C4: rxb0_1: w_F xmmreg1 001:2E:11 xmmreg2

mem with xmmreg1, set EFLAGS

C4: rxb0_1: w_F xmmreg1 001:2E:mod r/m

xmmreglo with xmmreg1, set EFLAGS

C5: r_F xmmreg1 001:2E:11 xmmreglo

mem with xmmreg1, set EFLAGS

C5: r_F xmmreg1 001:2E:mod r/m

VUNPCKHPD — Unpack and Interleave High Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:15:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:15:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:15:11 xmmreg1 xmmreglo3

Vol. 2D B-97

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:15:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:15:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:15:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:15:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:15:mod ymmreg1 r/m

VUNPCKHPS — Unpack and Interleave High Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:15:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:15:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:15:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:15:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:15:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:15:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:15:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:15:mod ymmreg1 r/m

VUNPCKLPD — Unpack and Interleave Low Packed Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:14:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:14:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:14:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:14:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:14:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:14:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:14:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:14:mod ymmreg1 r/m

VUNPCKLPS — Unpack and Interleave Low Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:14:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:14:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:14:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:14:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:14:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:14:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:14:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:14:mod ymmreg1 r/m

VXORPD — Bitwise Logical XOR for Double Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 001:57:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 001:57:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 001:57:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 001:57:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 101:57:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 101:57:mod ymmreg1 r/m

B-98

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 101:57:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 101:57:mod ymmreg1 r/m

VADDPS — Add Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:58:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:58:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:58:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:58:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:58:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:58:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:58:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:58:mod ymmreg1 r/m

VADDSS — Add Scalar Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:58:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:58:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:58:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:58:mod xmmreg1 r/m

VANDPS — Bitwise Logical AND of Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:54:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:54:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:54:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:54:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:54:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:54:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:54:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:54:mod ymmreg1 r/m

VANDNPS — Bitwise Logical AND NOT of Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:55:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:55:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:55:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:55:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:55:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:55:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:55:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:55:mod ymmreg1 r/m

VCMPPS — Compare Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:C2:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:C2:mod xmmreg1 r/m: imm

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:C2:11 xmmreg1 xmmreglo3: imm

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:C2:mod xmmreg1 r/m: imm

Vol. 2D B-99

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:C2:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:C2:mod ymmreg1 r/m: imm

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:C2:11 ymmreg1 ymmreglo3: imm

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:C2:mod ymmreg1 r/m: imm

VCMPSS — Compare Scalar Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:C2:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:C2:mod xmmreg1 r/m: imm

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:C2:11 xmmreg1 xmmreglo3: imm

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:C2:mod xmmreg1 r/m: imm

VCOMISS — Compare Scalar Ordered Single Precision Floating-Point Values and Set EFLAGS

xmmreg2 with xmmreg1

C4: rxb0_1: w_F 000:2F:11 xmmreg1 xmmreg2

mem with xmmreg1

C4: rxb0_1: w_F 000:2F:mod xmmreg1 r/m

xmmreglo with xmmreg1

C5: r_F 000:2F:11 xmmreg1 xmmreglo

mem with xmmreg1

C5: r_F 000:2F:mod xmmreg1 r/m

VCVTSI2SS — Convert Dword Integer to Scalar Single Precision FP Value

xmmreg2 with reg to xmmreg1

C4: rxb0_1: 0 xmmreg2 010:2A:11 xmmreg1 reg

xmmreg2 with mem to xmmreg1

C4: rxb0_1: 0 xmmreg2 010:2A:mod xmmreg1 r/m

xmmreglo2 with reglo to xmmreg1

C5: r_xmmreglo2 010:2A:11 xmmreg1 reglo

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:2A:mod xmmreg1 r/m

xmmreg2 with reg to xmmreg1

C4: rxb0_1: 1 xmmreg2 010:2A:11 xmmreg1 reg

xmmreg2 with mem to xmmreg1

C4: rxb0_1: 1 xmmreg2 010:2A:mod xmmreg1 r/m

VCVTSS2SI — Convert Scalar Single Precision FP Value to Dword Integer

xmmreg1 to reg

C4: rxb0_1: 0_F 010:2D:11 reg xmmreg1

mem to reg

C4: rxb0_1: 0_F 010:2D:mod reg r/m

xmmreglo to reg

C5: r_F 010:2D:11 reg xmmreglo

mem to reg

C5: r_F 010:2D:mod reg r/m

xmmreg1 to reg

C4: rxb0_1: 1_F 010:2D:11 reg xmmreg1

mem to reg

C4: rxb0_1: 1_F 010:2D:mod reg r/m

VCVTTSS2SI — Convert with Truncation Scalar Single Precision FP Value to Dword Integer

xmmreg1 to reg

C4: rxb0_1: 0_F 010:2C:11 reg xmmreg1

mem to reg

C4: rxb0_1: 0_F 010:2C:mod reg r/m

xmmreglo to reg

C5: r_F 010:2C:11 reg xmmreglo

mem to reg

C5: r_F 010:2C:mod reg r/m

xmmreg1 to reg

C4: rxb0_1: 1_F 010:2C:11 reg xmmreg1

mem to reg

C4: rxb0_1: 1_F 010:2C:mod reg r/m

VDIVPS — Divide Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:5E:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:5E:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:5E:11 xmmreg1 xmmreglo3

B-100

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:5E:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:5E:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:5E:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:5E:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:5E:mod ymmreg1 r/m

VDIVSS — Divide Scalar Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:5E:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:5E:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:5E:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:5E:mod xmmreg1 r/m

VLDMXCSR — Load MXCSR Register

mem to MXCSR reg

C4: rxb0_1: w_F 000:AEmod 011 r/m

mem to MXCSR reg

C5: r_F 000:AEmod 011 r/m

VMAXPS — Return Maximum Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:5F:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:5F:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:5F:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:5F:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:5F:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:5F:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:5F:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:5F:mod ymmreg1 r/m

VMAXSS — Return Maximum Scalar Single Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:5F:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:5F:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:5F:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:5F:mod xmmreg1 r/m

VMINPS — Return Minimum Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:5D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:5D:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:5D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:5D:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:5D:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:5D:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:5D:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:5D:mod ymmreg1 r/m

VMINSS — Return Minimum Scalar Single Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:5D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:5D:mod xmmreg1 r/m

Vol. 2D B-101

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:5D:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:5D:mod xmmreg1 r/m

VMOVAPS— Move Aligned Packed Single Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:28:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:28:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:28:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:28:mod xmmreg1 r/m

xmmreg1 to xmmreg2

C4: rxb0_1: w_F 000:29:11 xmmreg2 xmmreg1

xmmreg1 to mem

C4: rxb0_1: w_F 000:29:mod r/m xmmreg1

xmmreg1 to xmmreglo

C5: r_F 000:29:11 xmmreglo xmmreg1

xmmreg1 to mem

C5: r_F 000:29:mod r/m xmmreg1

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:28:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:28:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:28:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:28:mod ymmreg1 r/m

ymmreg1 to ymmreg2

C4: rxb0_1: w_F 100:29:11 ymmreg2 ymmreg1

ymmreg1 to mem

C4: rxb0_1: w_F 100:29:mod r/m ymmreg1

ymmreg1 to ymmreglo

C5: r_F 100:29:11 ymmreglo ymmreg1

ymmreg1 to mem

C5: r_F 100:29:mod r/m ymmreg1

VMOVHPS — Move High Packed Single Precision Floating-Point Values

xmmreg1 with mem to xmmreg2

C4: rxb0_1: w xmmreg1 000:16:mod xmmreg2 r/m

xmmreg1 with mem to xmmreglo2

C5: r_xmmreg1 000:16:mod xmmreglo2 r/m

xmmreg1 to mem

C4: rxb0_1: w_F 000:17:mod r/m xmmreg1

xmmreglo to mem

C5: r_F 000:17:mod r/m xmmreglo

VMOVLHPS — Move Packed Single Precision Floating-Point Values Low to High

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:16:11 xmmreg1 xmmreg3

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:16:11 xmmreg1 xmmreglo3

VMOVLPS — Move Low Packed Single Precision Floating-Point Values

xmmreg1 with mem to xmmreg2

C4: rxb0_1: w xmmreg1 000:12:mod xmmreg2 r/m

xmmreg1 with mem to xmmreglo2

C5: r_xmmreg1 000:12:mod xmmreglo2 r/m

xmmreg1 to mem

C4: rxb0_1: w_F 000:13:mod r/m xmmreg1

xmmreglo to mem

C5: r_F 000:13:mod r/m xmmreglo

VMOVMSKPS — Extract Packed Single Precision Floating-Point Sign Mask

xmmreg2 to reg

C4: rxb0_1: w_F 000:50:11 reg xmmreg2

xmmreglo to reg

C5: r_F 000:50:11 reg xmmreglo

ymmreg2 to reg

C4: rxb0_1: w_F 100:50:11 reg ymmreg2

ymmreglo to reg

C5: r_F 100:50:11 reg ymmreglo

VMOVNTPS — Store Packed Single Precision Floating-Point Values Using Non-Temporal Hint

xmmreg1 to mem

C4: rxb0_1: w_F 000:2B:mod r/m xmmreg1

B-102

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo to mem

C5: r_F 000:2B:mod r/m xmmreglo

ymmreg1 to mem

C4: rxb0_1: w_F 100:2B:mod r/m ymmreg1

ymmreglo to mem

C5: r_F 100:2B:mod r/m ymmreglo

VMOVSS — Move Scalar Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:10:11 xmmreg1 xmmreg3

mem to xmmreg1

C4: rxb0_1: w_F 010:10:mod xmmreg1 r/m

xmmreg2 with xmmreg3 to xmmreg1

C5: r_xmmreg2 010:10:11 xmmreg1 xmmreg3

mem to xmmreg1

C5: r_F 010:10:mod xmmreg1 r/m

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:11:11 xmmreg1 xmmreg3

xmmreg1 to mem

C4: rxb0_1: w_F 010:11:mod r/m xmmreg1

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:11:11 xmmreg1 xmmreglo3

xmmreglo to mem

C5: r_F 010:11:mod r/m xmmreglo

VMOVUPS— Move Unaligned Packed Single Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:10:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:10:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:10:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:10:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:10:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:10:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:10:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:10:mod ymmreg1 r/m

xmmreg1 to xmmreg2

C4: rxb0_1: w_F 000:11:11 xmmreg2 xmmreg1

xmmreg1 to mem

C4: rxb0_1: w_F 000:11:mod r/m xmmreg1

xmmreg1 to xmmreglo

C5: r_F 000:11:11 xmmreglo xmmreg1

xmmreg1 to mem

C5: r_F 000:11:mod r/m xmmreg1

ymmreg1 to ymmreg2

C4: rxb0_1: w_F 100:11:11 ymmreg2 ymmreg1

ymmreg1 to mem

C4: rxb0_1: w_F 100:11:mod r/m ymmreg1

ymmreg1 to ymmreglo

C5: r_F 100:11:11 ymmreglo ymmreg1

ymmreg1 to mem

C5: r_F 100:11:mod r/m ymmreg1

VMULPS — Multiply Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:59:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:59:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:59:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:59:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:59:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:59:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:59:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:59:mod ymmreg1 r/m

VMULSS — Multiply Scalar Single Precision Floating-Point Values

Vol. 2D B-103

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:59:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:59:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:59:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:59:mod xmmreg1 r/m

VORPS — Bitwise Logical OR of Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:56:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:56:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:56:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:56:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:56:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:56:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:56:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:56:mod ymmreg1 r/m

VRCPPS — Compute Reciprocals of Packed Single Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:53:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:53:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:53:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:53:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:53:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:53:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:53:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:53:mod ymmreg1 r/m

VRCPSS — Compute Reciprocal of Scalar Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:53:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:53:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:53:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:53:mod xmmreg1 r/m

VRSQRTPS — Compute Reciprocals of Square Roots of Packed Single Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:52:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:52:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:52:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:52:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:52:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:52:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:52:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:52:mod ymmreg1 r/m

VRSQRTSS — Compute Reciprocal of Square Root of Scalar Single Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:52:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:52:mod xmmreg1 r/m

B-104

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:52:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:52:mod xmmreg1 r/m

VSHUFPS — Shuffle Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1, imm8

C4: rxb0_1: w xmmreg2 000:C6:11 xmmreg1 xmmreg3: imm

xmmreg2 with mem to xmmreg1, imm8

C4: rxb0_1: w xmmreg2 000:C6:mod xmmreg1 r/m: imm

xmmreglo2 with xmmreglo3 to xmmreg1, imm8

C5: r_xmmreglo2 000:C6:11 xmmreg1 xmmreglo3: imm

xmmreglo2 with mem to xmmreg1, imm8

C5: r_xmmreglo2 000:C6:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 to ymmreg1, imm8

C4: rxb0_1: w ymmreg2 100:C6:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1, imm8

C4: rxb0_1: w ymmreg2 100:C6:mod ymmreg1 r/m: imm

ymmreglo2 with ymmreglo3 to ymmreg1, imm8

C5: r_ymmreglo2 100:C6:11 ymmreg1 ymmreglo3: imm

ymmreglo2 with mem to ymmreg1, imm8

C5: r_ymmreglo2 100:C6:mod ymmreg1 r/m: imm

VSQRTPS — Compute Square Roots of Packed Single Precision Floating-Point Values

xmmreg2 to xmmreg1

C4: rxb0_1: w_F 000:51:11 xmmreg1 xmmreg2

mem to xmmreg1

C4: rxb0_1: w_F 000:51:mod xmmreg1 r/m

xmmreglo to xmmreg1

C5: r_F 000:51:11 xmmreg1 xmmreglo

mem to xmmreg1

C5: r_F 000:51:mod xmmreg1 r/m

ymmreg2 to ymmreg1

C4: rxb0_1: w_F 100:51:11 ymmreg1 ymmreg2

mem to ymmreg1

C4: rxb0_1: w_F 100:51:mod ymmreg1 r/m

ymmreglo to ymmreg1

C5: r_F 100:51:11 ymmreg1 ymmreglo

mem to ymmreg1

C5: r_F 100:51:mod ymmreg1 r/m

VSQRTSS — Compute Square Root of Scalar Single Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:51:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:51:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:51:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:51:mod xmmreg1 r/m

VSTMXCSR — Store MXCSR Register State

MXCSR to mem

C4: rxb0_1: w_F 000:AE:mod 011 r/m

MXCSR to mem

C5: r_F 000:AE:mod 011 r/m

VSUBPS — Subtract Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:5C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:5C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:5C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:5C:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:5C:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:5C:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:5C:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:5C:mod ymmreg1 r/m

VSUBSS — Subtract Scalar Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 010:5C:11 xmmreg1 xmmreg3

Vol. 2D B-105

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 010:5C:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 010:5C:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 010:5C:mod xmmreg1 r/m

VUCOMISS — Unordered Compare Scalar Single Precision Floating-Point Values and Set EFLAGS

xmmreg2 with xmmreg1

C4: rxb0_1: w_F 000:2E:11 xmmreg1 xmmreg2

mem with xmmreg1

C4: rxb0_1: w_F 000:2E:mod xmmreg1 r/m

xmmreglo with xmmreg1

C5: r_F 000:2E:11 xmmreg1 xmmreglo

mem with xmmreg1

C5: r_F 000:2E:mod xmmreg1 r/m

UNPCKHPS — Unpack and Interleave High Packed Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:15:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:15mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:15:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:15mod ymmreg1 r/m

UNPCKLPS — Unpack and Interleave Low Packed Single Precision Floating-Point Value

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:14:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:14mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:14:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:14mod ymmreg1 r/m

VXORPS — Bitwise Logical XOR for Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_1: w xmmreg2 000:57:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_1: w xmmreg2 000:57:mod xmmreg1 r/m

xmmreglo2 with xmmreglo3 to xmmreg1

C5: r_xmmreglo2 000:57:11 xmmreg1 xmmreglo3

xmmreglo2 with mem to xmmreg1

C5: r_xmmreglo2 000:57:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_1: w ymmreg2 100:57:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_1: w ymmreg2 100:57:mod ymmreg1 r/m

ymmreglo2 with ymmreglo3 to ymmreg1

C5: r_ymmreglo2 100:57:11 ymmreg1 ymmreglo3

ymmreglo2 with mem to ymmreg1

C5: r_ymmreglo2 100:57:mod ymmreg1 r/m

VBROADCAST —Load with Broadcast

mem to xmmreg1

C4: rxb0_2: 0_F 001:18:mod xmmreg1 r/m

mem to ymmreg1

C4: rxb0_2: 0_F 101:18:mod ymmreg1 r/m

mem to ymmreg1

C4: rxb0_2: 0_F 101:19:mod ymmreg1 r/m

mem to ymmreg1

C4: rxb0_2: 0_F 101:1A:mod ymmreg1 r/m

VEXTRACTF128 — Extract Packed Floating-Point Values

ymmreg2 to xmmreg1, imm8

C4: rxb0_3: 0_F 001:19:11 xmmreg1 ymmreg2: imm

ymmreg2 to mem, imm8

C4: rxb0_3: 0_F 001:19:mod r/m ymmreg2: imm

VINSERTF128 — Insert Packed Floating-Point Values

xmmreg3 and merge with ymmreg2 to ymmreg1, imm8

C4: rxb0_3: 0 ymmreg2101:18:11 ymmreg1 xmmreg3: imm

mem and merge with ymmreg2 to ymmreg1, imm8

C4: rxb0_3: 0 ymmreg2 101:18:mod ymmreg1 r/m: imm

VPERMILPD — Permute Double Precision Floating-Point Values

B-106

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Instruction and Format

Encoding

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: 0 xmmreg2 001:0D:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: 0 xmmreg2 001:0D:mod xmmreg1 r/m

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_2: 0 ymmreg2 101:0D:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_2: 0 ymmreg2 101:0D:mod ymmreg1 r/m

xmmreg2 to xmmreg1, imm

C4: rxb0_3: 0_F 001:05:11 xmmreg1 xmmreg2: imm

mem to xmmreg1, imm

C4: rxb0_3: 0_F 001:05:mod xmmreg1 r/m: imm

ymmreg2 to ymmreg1, imm

C4: rxb0_3: 0_F 101:05:11 ymmreg1 ymmreg2: imm

mem to ymmreg1, imm

C4: rxb0_3: 0_F 101:05:mod ymmreg1 r/m: imm

VPERMILPS — Permute Single Precision Floating-Point Values

xmmreg2 with xmmreg3 to xmmreg1

C4: rxb0_2: 0 xmmreg2 001:0C:11 xmmreg1 xmmreg3

xmmreg2 with mem to xmmreg1

C4: rxb0_2: 0 xmmreg2 001:0C:mod xmmreg1 r/m

xmmreg2 to xmmreg1, imm

C4: rxb0_3: 0_F 001:04:11 xmmreg1 xmmreg2: imm

mem to xmmreg1, imm

C4: rxb0_3: 0_F 001:04:mod xmmreg1 r/m: imm

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_2: 0 ymmreg2 101:0C:11 ymmreg1 ymmreg3

ymmreg2 with mem to ymmreg1

C4: rxb0_2: 0 ymmreg2 101:0C:mod ymmreg1 r/m

ymmreg2 to ymmreg1, imm

C4: rxb0_3: 0_F 101:04:11 ymmreg1 ymmreg2: imm

mem to ymmreg1, imm

C4: rxb0_3: 0_F 101:04:mod ymmreg1 r/m: imm

VPERM2F128 — Permute Floating-Point Values

ymmreg2 with ymmreg3 to ymmreg1

C4: rxb0_3: 0 ymmreg2 101:06:11 ymmreg1 ymmreg3: imm

ymmreg2 with mem to ymmreg1

C4: rxb0_3: 0 ymmreg2 101:06:mod ymmreg1 r/m: imm

VTESTPD/VTESTPS — Packed Bit Test

xmmreg2 to xmmreg1

C4: rxb0_2: 0_F 001:0E:11 xmmreg2 xmmreg1

mem to xmmreg1

C4: rxb0_2: 0_F 001:0E:mod xmmreg2 r/m

ymmreg2 to ymmreg1

C4: rxb0_2: 0_F 101:0E:11 ymmreg2 ymmreg1

mem to ymmreg1

C4: rxb0_2: 0_F 101:0E:mod ymmreg2 r/m

xmmreg2 to xmmreg1

C4: rxb0_2: 0_F 001:0F:11 xmmreg1 xmmreg2: imm

mem to xmmreg1

C4: rxb0_2: 0_F 001:0F:mod xmmreg1 r/m: imm

ymmreg2 to ymmreg1

C4: rxb0_2: 0_F 101:0F:11 ymmreg1 ymmreg2: imm

mem to ymmreg1

C4: rxb0_2: 0_F 101:0F:mod ymmreg1 r/m: imm

NOTES:

1. The term “lo” refers to the lower eight registers, 0-7

Vol. 2D B-107

INSTRUCTION FORMATS AND ENCODINGS

B.17 FLOATING-POINT INSTRUCTION FORMATS AND ENCODINGS

Table B-38 shows the five different formats used for floating-point instructions. In all cases, instructions are at

least two bytes long and begin with the bit pattern 11011.

Table B-38. General Floating-Point Instruction Formats

Instruction

First Byte

Second Byte

Optional Fields

1

11011

OPA

1

mod

1

OPB

r/m

s-i-b

disp

2

11011

MF

OPA

mod

OPB

r/m

s-i-b

disp

3

11011

d

P

OPA

1

1

OPB

R

ST(i)

4

11011

0

0

1

1

1

1

OP

5

11011

0

1

1

1

1

1

OP

15-11

10

9

8

7

6

5

4

3

2

1

0

MF = Memory Format

R XOR d = 0 — Destination OP Source

00 — 32-bit real

R XOR d = 1 — Source OP Destination

01 — 32-bit integer

10 — 64-bit real

ST(i) = Register stack element i

11 — 16-bit integer

000 = Stack Top

P = Pop

001 = Second stack element

0 — Do not pop stack

⋅

1 — Pop stack after operation

⋅

d = Destination

⋅

0 — Destination is ST(0)

111 = Eighth stack element

1 — Destination is ST(i)

The Mod and R/M fields of the ModR/M byte have the same interpretation as the corresponding fields of the integer

instructions. The SIB byte and disp (displacement) are optionally present in instructions that have Mod and R/M

fields. Their presence depends on the values of Mod and R/M, as for integer instructions.

Table B-39 shows the formats and encodings of the floating-point instructions.

Table B-39. Floating-Point Instruction Formats and Encodings

Instruction and Format

Encoding

F2XM1 - Compute 2^ST(0) - 1

11011 001 : 1111 0000

FABS - Absolute Value

11011 001 : 1110 0001

FADD - Add

ST(0) := ST(0) + 32-bit memory

11011 000 : mod 000 r/m

ST(0) := ST(0) + 64-bit memory

11011 100 : mod 000 r/m

ST(d) := ST(0) + ST(i)

11011 d00 : 11 000 ST(i)

FADDP - Add and Pop

ST(0) := ST(0) + ST(i)

11011 110 : 11 000 ST(i)

FBLD - Load Binary Coded Decimal

11011 111 : mod 100 r/m

FBSTP - Store Binary Coded Decimal and Pop

11011 111 : mod 110 r/m

FCHS - Change Sign

11011 001 : 1110 0000

FCLEX - Clear Exceptions

11011 011 : 1110 0010

FCOM - Compare Real

B-108

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-39. Floating-Point Instruction Formats and Encodings (Contd.)

Instruction and Format

Encoding

32-bit memory

11011 000 : mod 010 r/m

64-bit memory

11011 100 : mod 010 r/m

ST(i)

11011 000 : 11 010 ST(i)

FCOMP - Compare Real and Pop

32-bit memory

11011 000 : mod 011 r/m

64-bit memory

11011 100 : mod 011 r/m

ST(i)

11011 000 : 11 011 ST(i)

FCOMPP - Compare Real and Pop Twice

11011 110 : 11 011 001

FCOMIP - Compare Real, Set EFLAGS, and Pop

11011 111 : 11 110 ST(i)

FCOS - Cosine of ST(0)

11011 001 : 1111 1111

FDECSTP - Decrement Stack-Top Pointer

11011 001 : 1111 0110

FDIV - Divide

ST(0) := ST(0) ÷ 32-bit memory

11011 000 : mod 110 r/m

ST(0) := ST(0) ÷ 64-bit memory

11011 100 : mod 110 r/m

ST(d) := ST(0) ÷ ST(i)

11011 d00 : 1111 R ST(i)

FDIVP - Divide and Pop

ST(0) := ST(0) ÷ ST(i)

11011 110 : 1111 1 ST(i)

FDIVR - Reverse Divide

ST(0) := 32-bit memory ÷ ST(0)

11011 000 : mod 111 r/m

ST(0) := 64-bit memory ÷ ST(0)

11011 100 : mod 111 r/m

ST(d) := ST(i) ÷ ST(0)

11011 d00 : 1111 R ST(i)

FDIVRP - Reverse Divide and Pop

ST(0) := ST(i) ÷ ST(0)

11011 110 : 1111 0 ST(i)

FFREE - Free ST(i) Register

11011 101 : 1100 0 ST(i)

FIADD - Add Integer

ST(0) := ST(0) + 16-bit memory

11011 110 : mod 000 r/m

ST(0) := ST(0) + 32-bit memory

11011 010 : mod 000 r/m

FICOM - Compare Integer

16-bit memory

11011 110 : mod 010 r/m

32-bit memory

11011 010 : mod 010 r/m

FICOMP - Compare Integer and Pop

16-bit memory

11011 110 : mod 011 r/m

32-bit memory

11011 010 : mod 011 r/m

FIDIV - Divide

ST(0) := ST(0) ÷ 16-bit memory

11011 110 : mod 110 r/m

ST(0) := ST(0) ÷ 32-bit memory

11011 010 : mod 110 r/m

FIDIVR - Reverse Divide

ST(0) := 16-bit memory ÷ ST(0)

11011 110 : mod 111 r/m

Vol. 2D B-109

INSTRUCTION FORMATS AND ENCODINGS

Table B-39. Floating-Point Instruction Formats and Encodings (Contd.)

Instruction and Format

Encoding

ST(0) := 32-bit memory ÷ ST(0)

11011 010 : mod 111 r/m

FILD - Load Integer

16-bit memory

11011 111 : mod 000 r/m

32-bit memory

11011 011 : mod 000 r/m

64-bit memory

11011 111 : mod 101 r/m

FIMUL- Multiply

ST(0) := ST(0) × 16-bit memory

11011 110 : mod 001 r/m

ST(0) := ST(0) × 32-bit memory

11011 010 : mod 001 r/m

FINCSTP - Increment Stack Pointer

11011 001 : 1111 0111

FINIT - Initialize Floating-Point Unit

FIST - Store Integer

16-bit memory

11011 111 : mod 010 r/m

32-bit memory

11011 011 : mod 010 r/m

FISTP - Store Integer and Pop

16-bit memory

11011 111 : mod 011 r/m

32-bit memory

11011 011 : mod 011 r/m

64-bit memory

11011 111 : mod 111 r/m

FISUB - Subtract

ST(0) := ST(0) - 16-bit memory

11011 110 : mod 100 r/m

ST(0) := ST(0) - 32-bit memory

11011 010 : mod 100 r/m

FISUBR - Reverse Subtract

ST(0) := 16-bit memory − ST(0)

11011 110 : mod 101 r/m

ST(0) := 32-bit memory − ST(0)

11011 010 : mod 101 r/m

FLD - Load Real

32-bit memory

11011 001 : mod 000 r/m

64-bit memory

11011 101 : mod 000 r/m

80-bit memory

11011 011 : mod 101 r/m

ST(i)

11011 001 : 11 000 ST(i)

FLD1 - Load +1.0 into ST(0)

11011 001 : 1110 1000

FLDCW - Load Control Word

11011 001 : mod 101 r/m

FLDENV - Load FPU Environment

11011 001 : mod 100 r/m

FLDL2E - Load log₂(ε) into ST(0)

11011 001 : 1110 1010

FLDL2T - Load log₂(10) into ST(0)

11011 001 : 1110 1001

FLDLG2 - Load log₁₀(2) into ST(0)

11011 001 : 1110 1100

FLDLN2 - Load log_ε(2) into ST(0)

11011 001 : 1110 1101

FLDPI - Load π into ST(0)

11011 001 : 1110 1011

FLDZ - Load +0.0 into ST(0)

11011 001 : 1110 1110

FMUL - Multiply

B-110

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-39. Floating-Point Instruction Formats and Encodings (Contd.)

Instruction and Format

Encoding

ST(0) := ST(0) × 32-bit memory

11011 000 : mod 001 r/m

ST(0) := ST(0) × 64-bit memory

11011 100 : mod 001 r/m

ST(d) := ST(0) × ST(i)

11011 d00 : 1100 1 ST(i)

FMULP - Multiply

ST(i) := ST(0) × ST(i)

11011 110 : 1100 1 ST(i)

FNOP - No Operation

11011 001 : 1101 0000

FPATAN - Partial Arctangent

11011 001 : 1111 0011

FPREM - Partial Remainder

11011 001 : 1111 1000

FPREM1 - Partial Remainder (IEEE)

11011 001 : 1111 0101

FPTAN - Partial Tangent

11011 001 : 1111 0010

FRNDINT - Round to Integer

11011 001 : 1111 1100

FRSTOR - Restore FPU State

11011 101 : mod 100 r/m

FSAVE - Store FPU State

11011 101 : mod 110 r/m

FSCALE - Scale

11011 001 : 1111 1101

FSIN - Sine

11011 001 : 1111 1110

FSINCOS - Sine and Cosine

11011 001 : 1111 1011

FSQRT - Square Root

11011 001 : 1111 1010

FST - Store Real

32-bit memory

11011 001 : mod 010 r/m

64-bit memory

11011 101 : mod 010 r/m

ST(i)

11011 101 : 11 010 ST(i)

FSTCW - Store Control Word

11011 001 : mod 111 r/m

FSTENV - Store FPU Environment

11011 001 : mod 110 r/m

FSTP - Store Real and Pop

32-bit memory

11011 001 : mod 011 r/m

64-bit memory

11011 101 : mod 011 r/m

80-bit memory

11011 011 : mod 111 r/m

ST(i)

11011 101 : 11 011 ST(i)

FSTSW - Store Status Word into AX

11011 111 : 1110 0000

FSTSW - Store Status Word into Memory

11011 101 : mod 111 r/m

FSUB - Subtract

ST(0) := ST(0) - 32-bit memory

11011 000 : mod 100 r/m

ST(0) := ST(0) - 64-bit memory

11011 100 : mod 100 r/m

ST(d) := ST(0) - ST(i)

11011 d00 : 1110 R ST(i)

FSUBP - Subtract and Pop

ST(0) := ST(0) - ST(i)

11011 110 : 1110 1 ST(i)

FSUBR - Reverse Subtract

ST(0) := 32-bit memory - ST(0)

11011 000 : mod 101 r/m

Vol. 2D B-111

INSTRUCTION FORMATS AND ENCODINGS

Table B-39. Floating-Point Instruction Formats and Encodings (Contd.)

Instruction and Format

Encoding

ST(0) := 64-bit memory - ST(0)

11011 100 : mod 101 r/m

ST(d) := ST(i) - ST(0)

11011 d00 : 1110 R ST(i)

FSUBRP - Reverse Subtract and Pop

ST(i) := ST(i) - ST(0)

11011 110 : 1110 0 ST(i)

FTST - Test

11011 001 : 1110 0100

FUCOM - Unordered Compare Real

11011 101 : 1110 0 ST(i)

FUCOMP - Unordered Compare Real and Pop

11011 101 : 1110 1 ST(i)

FUCOMPP - Unordered Compare Real and Pop Twice

11011 010 : 1110 1001

FUCOMI - Unorderd Compare Real and Set EFLAGS

11011 011 : 11 101 ST(i)

FUCOMIP - Unorderd Compare Real, Set EFLAGS, and Pop

11011 111 : 11 101 ST(i)

FXAM - Examine

11011 001 : 1110 0101

FXCH - Exchange ST(0) and ST(i)

11011 001 : 1100 1 ST(i)

FXTRACT - Extract Exponent and Significand

11011 001 : 1111 0100

FYL2X - ST(1) × log₂(ST(0))

11011 001 : 1111 0001

FYL2XP1 - ST(1) × log₂(ST(0) + 1.0)

11011 001 : 1111 1001

FWAIT - Wait until FPU Ready

1001 1011 (same instruction as WAIT)

B.18 VMX INSTRUCTIONS

Table B-40 describes virtual-machine extensions (VMX).

Table B-40. Encodings for VMX Instructions

Instruction and Format

Encoding

INVEPT—Invalidate Cached EPT Mappings

Descriptor m128 according to reg

01100110 00001111 00111000 10000000: mod reg r/m

INVVPID—Invalidate Cached VPID Mappings

Descriptor m128 according to reg

01100110 00001111 00111000 10000001: mod reg r/m

VMCALL—Call to VM Monitor

Call VMM: causes VM exit

00001111 00000001 11000001

VMCLEAR—Clear Virtual-Machine Control Structure

mem32:VMCS_data_ptr

01100110 00001111 11000111: mod 110 r/m

mem64:VMCS_data_ptr

01100110 00001111 11000111: mod 110 r/m

VMFUNC—Invoke VM Function

Invoke VM function specified in EAX

00001111 00000001 11010100

VMLAUNCH—Launch Virtual Machine

Launch VM managed by Current_VMCS

00001111 00000001 11000010

VMRESUME—Resume Virtual Machine

Resume VM managed by Current_VMCS

00001111 00000001 11000011

VMPTRLD—Load Pointer to Virtual-Machine Control Structure

mem32 to Current_VMCS_ptr

00001111 11000111: mod 110 r/m

B-112

Vol. 2D

INSTRUCTION FORMATS AND ENCODINGS

Table B-40. Encodings for VMX Instructions

Instruction and Format

Encoding

mem64 to Current_VMCS_ptr

00001111 11000111: mod 110 r/m

VMPTRST—Store Pointer to Virtual-Machine Control Structure

Current_VMCS_ptr to mem32

00001111 11000111: mod 111 r/m

Current_VMCS_ptr to mem64

00001111 11000111: mod 111 r/m

VMREAD—Read Field from Virtual-Machine Control Structure

r32 (VMCS_fieldn) to r32

00001111 01111000: 11 reg2 reg1

r32 (VMCS_fieldn) to mem32

00001111 01111000: mod r32 r/m

r64 (VMCS_fieldn) to r64

00001111 01111000: 11 reg2 reg1

r64 (VMCS_fieldn) to mem64

00001111 01111000: mod r64 r/m

VMWRITE—Write Field to Virtual-Machine Control Structure

r32 to r32 (VMCS_fieldn)

00001111 01111001: 11 reg1 reg2

mem32 to r32 (VMCS_fieldn)

00001111 01111001: mod r32 r/m

r64 to r64 (VMCS_fieldn)

00001111 01111001: 11 reg1 reg2

mem64 to r64 (VMCS_fieldn)

00001111 01111001: mod r64 r/m

VMXOFF—Leave VMX Operation

Leave VMX.

00001111 00000001 11000100

VMXON—Enter VMX Operation

Enter VMX.

11110011 000011111 11000111: mod 110 r/m

B.19 SMX INSTRUCTIONS

Table B-38 describes Safer Mode extensions (VMX). GETSEC leaf functions are selected by a valid value in EAX on input.

Table B-41. Encodings for SMX Instructions

Instruction and Format

Encoding

GETSEC—GETSEC leaf functions are selected by the value in EAX on input

GETSEC[CAPABILITIES]

00001111 00110111 (EAX= 0)

GETSEC[ENTERACCS]

00001111 00110111 (EAX= 2)

GETSEC[EXITAC]

00001111 00110111 (EAX= 3)

GETSEC[SENTER]

00001111 00110111 (EAX= 4)

GETSEC[SEXIT]

00001111 00110111 (EAX= 5)

GETSEC[PARAMETERS]

00001111 00110111 (EAX= 6)

GETSEC[SMCTRL]

00001111 00110111 (EAX= 7)

GETSEC[WAKEUP]

00001111 00110111 (EAX= 8)

Vol. 2D B-113

APPENDIX C

INTEL® C/C++ COMPILER INTRINSICS AND FUNCTIONAL EQUIVALENTS

The two tables in this appendix itemize the Intel C/C++ compiler intrinsics and functional equivalents for the Intel

MMX technology, SSE, SSE2, SSE3, and SSSE3 instructions.

There may be additional intrinsics that do not have an instruction equivalent. It is strongly recommended that the

reader reference the compiler documentation for the complete list of supported intrinsics. Please refer to

http://www.intel.com/support/performancetools/.

Table C-1 presents simple intrinsics and Table C-2 presents composite intrinsics. Some intrinsics are “composites”

because they require more than one instruction to implement them.

Intel C/C++ Compiler intrinsic names reflect the following naming conventions:

_mm_<intrin_op>_<suffix>

where:

<intrin_op>

Indicates the intrinsics basic operation; for example, add for addition and sub for subtrac-

tion

<suffix>

Denotes the type of data operated on by the instruction. The first one or two letters of

each suffix denotes whether the data is packed (p), extended packed (ep), or scalar (s).

The remaining letters denote the type:

s

single-precision floating-point

d

double precision floating-point

i128

signed 128-bit integer

i64

signed 64-bit integer

u64

unsigned 64-bit integer

i32

signed 32-bit integer

u32

unsigned 32-bit integer

i16

signed 16-bit integer

u16

unsigned 16-bit integer

i8

signed 8-bit integer

u8

unsigned 8-bit integer

The variable r is generally used for the intrinsic's return value. A number appended to a variable name indicates the

element of a packed object. For example, r0 is the lowest word of r.

The packed values are represented in right-to-left order, with the lowest value being used for scalar operations.

Consider the following example operation:

double a[2] = {1.0, 2.0};

__m128d t = _mm_load_pd(a);

The result is the same as either of the following:

__m128d t = _mm_set_pd(2.0, 1.0);

__m128d t = _mm_setr_pd(1.0, 2.0);

In other words, the XMM register that holds the value t will look as follows:

2.0

1.0

127

6463

0

Vol. 2D C-1

INTEL® C/C++ COMPILER INTRINSICS AND FUNCTIONAL EQUIVALENTS

The “scalar” element is 1.0. Due to the nature of the instruction, some intrinsics require their arguments to be

immediates (constant integer literals).

To use an intrinsic in your code, insert a line with the following syntax:

data_type intrinsic_name (parameters)

Where:

data_type

Is the return data type, which can be either void, int, __m64, __m128, __m128d, or

__m128i. Only the _mm_empty intrinsic returns void.

intrinsic_name

Is the name of the intrinsic, which behaves like a function that you can use in your C/C++

code instead of in-lining the actual instruction.

parameters

Represents the parameters required by each intrinsic.

C.1

SIMPLE INTRINSICS

NOTE

For detailed descriptions of the intrinsics in Table C-1, see the corresponding mnemonic in Chapter

3, “Instruction Set Reference, A-L‚” of the Intel^® 64 and IA-32 Architectures Software Developer’s

Manual, Volume 2A; Chapter 4, “Instruction Set Reference, M-U‚” of the Intel^® 64 and IA-32 Archi-

tectures Software Developer’s Manual, Volume 2B; Chapter 5, “Instruction Set Reference, V,” of the

Intel^® 64 and IA-32 Architectures Software Developer’s Manual, Volume 2C; or Chapter 6,

“Instruction Set Reference, W-Z,” of the Intel^® 64 and IA-32 Architectures Software Developer’s

Manual, Volume 2D.

Table C-1. Simple Intrinsics

Mnemonic

Intrinsic

ADDPD

__m128d _mm_add_pd(__m128d a, __m128d b)

ADDPS

__m128 _mm_add_ps(__m128 a, __m128 b)

ADDSD

__m128d _mm_add_sd(__m128d a, __m128d b)

ADDSS

__m128 _mm_add_ss(__m128 a, __m128 b)

ADDSUBPD

__m128d _mm_addsub_pd(__m128d a, __m128d b)

ADDSUBPS

__m128 _mm_addsub_ps(__m128 a, __m128 b)

AESDEC

__m128i _mm_aesdec (__m128i, __m128i)

AESDECLAST

__m128i _mm_aesdeclast (__m128i, __m128i)

AESENC

__m128i _mm_aesenc (__m128i, __m128i)

AESENCLAST

__m128i _mm_aesenclast (__m128i, __m128i)

AESIMC

__m128i _mm_aesimc (__m128i)

AESKEYGENASSIST

__m128i _mm_aesimc (__m128i, const int)

ANDNPD

__m128d _mm_andnot_pd(__m128d a, __m128d b)

ANDNPS

__m128 _mm_andnot_ps(__m128 a, __m128 b)

ANDPD

__m128d _mm_and_pd(__m128d a, __m128d b)

ANDPS

__m128 _mm_and_ps(__m128 a, __m128 b)

BLENDPD

__m128d _mm_blend_pd(__m128d v1, __m128d v2, const int mask)

BLENDPS

__m128 _mm_blend_ps(__m128 v1, __m128 v2, const int mask)

BLENDVPD

__m128d _mm_blendv_pd(__m128d v1, __m128d v2, __m128d v3)

BLENDVPS

__m128 _mm_blendv_ps(__m128 v1, __m128 v2, __m128 v3)

CLFLUSH

void _mm_clflush(void const *p)

C-2

Vol. 2D

Content      ..     123      124      125      126     ..
