15. MULTI-TASKING
Server Task
--KAREL
POST_SEMA (4)
WHILE TRUE DO
PEND_SEMA(5,max_time,time_out)
IF rqst_param=10 THEN
do_something
ENDIF
POST_SEMA(4)
POST_SEMA(6)
ENDWHILE
Example: The program example in Semaphore and Task Synchronization Program Example - MAIN
TASK thru Semaphore and Task Synchronization Program Example - TASK B shows how semaphores
and tasks can be used together for synchronization. MAIN_TASK.KL is used to initialize the semaphore
(MOTION_CTRL) and then runs both TASK_A.KL and TASK_B.KL. MAIN_TASK.KL then waits for
TASK_A and TASK_B to abort before completing. TASK_A waits until you press F1 and then moves the
robot to the HOME position. TASK_B waits until you press F2 and then moves the robot along a path.
Semaphore and Task Synchronization Program Example - MAIN TASK
PROGRAM main_task
%nolockgroup
VAR
motion_ctrl: INTEGER
tsk_a_done : BOOLEAN
tsk_b_done : BOOLEAN
tmr
: INTEGER
status
: INTEGER
------------------------------------------------
--
--
-- INIT_LOCK: Initialize the semaphore
--
--
to make sure its count is at
--
--
zero before using it. Then
--
--
post this semaphore which will--
--
allow the first pend to the
--
--
semaphore to continue
--
--
execution.
--
------------------------------------------------
ROUTINE init_lock
BEGIN
CLEAR_SEMA (motion_ctrl)
-- makes sure semaphore is zero before using
it.
POST_SEMA
(motion_ctrl)
-- makes motion_ctrl available immediately
END init_lock
------------------------------------------------
15-11
15. MULTI-TASKING
MARRC75KR07091E Rev D
--
--
-- IS_TSK_DONE : Find out if the specified
--
--
task is running or not.
--
--
If the task is aborted then --
--
return TRUE otherwise FALSE.--
------------------------------------------------
ROUTINE is_tsk_done (task_name:STRING): BOOLEAN
VAR
status
: INTEGER
-- The status of the operation of GET_TSK_INFO
task_no : INTEGER
-- Receives the current task number for task_name
attr_out: INTEGER
-- Receives the TSK_STATUS output
dummy
: STRING[2]
-- Does not receive any information
BEGIN
GET_TSK_INFO (task_name, task_no, TSK_STATUS, attr_out, dummy, status)
IF (attr_out = PG_ABORTED) THEN
RETURN (TRUE)
-- If task is aborted then return TRUE
ENDIF
RETURN(FALSE)
-- otherwise task is not aborted and return
FALSE
END is_tsk_done
BEGIN
motion_ctrl = 1
-- Semaphore to allow motion control
init_lock
-- Make sure this is done just once
FORCE_SPMENU ( tp_panel, spi_tpuser, 1)
-- Force the Teach Pendant
-- user screen to be seen
RUN_TASK(’task_a’, 1, FALSE, FALSE, 1, status)
-- Run task_a
RUN_TASK(’task_b’, 1, FALSE, FALSE, 1, status)
-- Run task_b
REPEAT
tsk_a_done = is_tsk_done (’task_a’)
tsk_b_done = is_tsk_done (’task_b’)
delay (100)
UNTIL (tsk_a_done and tsk_b_done)
-- Repeat until both task_a
END main_task
-- and task_b are aborted
Semaphore and Task Synchronization Program Example - TASK A
PROGRAM task_a
%nolockgroup
VAR
motion_ctrl FROM main_task: INTEGER
home_pos
: XYZWPR
status
: INTEGER
------------------------------------------------
--
--
-- RUN_HOME
: Lock the robot motion
--
--
control. This task is
--
15-12
MARRC75KR07091E Rev D
15. MULTI-TASKING
--
moving the robot and must
--
--
have control.
--
--
--
------------------------------------------------
ROUTINE run_home
VAR
time_out: BOOLEAN
BEGIN
PEND_SEMA(motion_ctrl,-1,time_out)-- lock motion_ctrl from other tasks
-- keep other tasks from moving robot
LOCK_GROUP (1, status)
SET_POS_REG(1, home_pos, status)
do_move
-- call TP program to move to the home position
UNLOCK_GROUP (1, status)
POST_SEMA(motion_ctrl)
-- unlock motion_ctrl
-- allow other task to move robot
END run_home
BEGIN
set_cursor (tpfunc, 1, 4, status)
write tpfunc (’HOME’,CR)
wait for TPIN[129]+
-- wait for F1 to be pressed
run_home
END task_a
Semaphore and Task Synchronization Program Example - TASK B
PROGRAM task_b
%nolockgroup
VAR
motion_ctrl FROM main_task : INTEGER
work_path
: PATH
move_pos
: XYZWPR
status
: INTEGER
------------------------------------------------
--
--
-- do_work
: Lock the robot from other
--
--
tasks and do work. This
--
--
task is doing motion and
--
--
must lock motion control so --
--
that another task does not
--
--
try to do motion at the
--
--
same time.
--
------------------------------------------------
ROUTINE do_work
VAR
time_out: BOOLEAN
15-13
15. MULTI-TASKING
MARRC75KR07091E Rev D
BEGIN
PEND_SEMA (motion_ctrl,-1,time_out) -- lock motion_ctrl from other
-- tasks keep other tasks from
-- moving robot
LOCK_GROUP (1, status)
FOR i=1 to PATH_LEN(work_path) DO
move_pos = work_path[i]
SET_POS_REG(1, move_pos, status)
do_move
-- call TP program to move to path node
ENDFOR
UNLOCK_GROUP (1, status)
POST_SEMA(motion_ctrl)
-- unlock motion_ctrl allow
-- other task to move robot
END do_work
BEGIN
set_cursor(tpfunc, 1, 10, status)
write tpfunc(’WORK’,CR)
wait for TPIN[131]+
-- wait until F2 is pressed
do_work
END task_b
15.8
USING QUEUES FOR TASK COMMUNICATIONS
Queues are supported only in KAREL. A queue is a first-in/first-out list of integers. They are
used to pass information to another task sequentially. A queue consists of a user variable of type
QUEUE_TYPE and an ARRAY OF INTEGER. The maximum number of entries in the queue is
determined by the size of the array.
The following operations are supported on queues:
• INIT_QUEUE initializes a queue and sets it to empty.
• APPEND_QUEUE adds an integer to the list of entries in the queue.
• GET_QUEUE: reads the oldest (top) entry from the queue and deletes it.
These, and other built-ins related to queues ( DELETE_QUEUE, INSERT_QUEUE, COPY_QUEUE)
are described in Appendix A .
A QUEUE_TYPE Data Type has one user accessible element, n_entries . This is the number of
entries that have been added to the queue and not read out. The array of integer used with a queue, is
used by the queue built-ins and should not be referenced by the KAREL program.
Example: The following example illustrates a more powerful request server, in which more than one
task is posting requests and the requester does not wait for completion of the request.
15-14
MARRC75KR07091E Rev D
15. MULTI-TASKING
The requester would contain the following code:
Requester
--declarations
VAR
rqst_queue FROM server: QUEUE_TYPE
rqst_data FROM server: ARRAY[100] OF INTEGER
status: INTEGER
seq_no: INTEGER
-- posting to the queue --
APPEND_QUEUE (req_code, rqst_queue, rqst_data, seq_no, status)
The server task would contain the following code:
Server
PROGRAM server
VAR
rqst_queue: QUEUE_TYPE
rqst_data : ARRAY[100] OF INTEGER
status
: INTEGER
seq_no
: INTEGER
rqst_code : INTEGER
BEGIN
INIT_QUEUE(rqst_queue)
--initialization
WHILE TRUE DO
--serving loop
WAIT FOR rqst_code.n_entries > 0
GET_QUEUE (rqst_queue, rqst_data, rqst_code, seq_no, status)
SELECT rqst_code OF
CASE (1): do_something
ENDSELECT
ENDWHILE
END server
15-15
