Page 6
Lotus Service Notes
Section BQ BQ.5 - BODY PANEL BONDING MATERIALS The materials used for bonding the body panels are manufactured by Dow Chemical, and in order to maintain the structural integrity of the vehicle, and in the case of the front crash structure, the safety, it is most important to use only the specified materials. The surface preparation and cleaning and priming operations are crucial to the performance of the adhesive, and must be followed in detail. The products to be used depend on the surface (substrate) onto which they are applied, and the following list identifies each application: Anodised aluminium (e.g. chassis and components) Cleaner: Betawipe VP 04604 Lotus part no. A082B6150V Primer: Betapnme 5404 Lotus part no. A082B6337V Adhesive: Betaseal 1701 Lotus part no. A082B6281F or Betamate E2400 Lotus part no. A082B8415V Unpainted or painted composite Cleaner: Betaclean 3900 Lotus part no. A100B6008V Primer: Betaprime 5404 Lotus part no. A082B6337V Adhesive: Betaseal 1701 Lotus part no. A082B6281F or Betamate E2400 Lotus part no. A082B8415V Zinc plated and passivated steel Cleaner: Beatclean 3900 Lotus part no. A100B6008V Primer: Betaprime VP 01706 A+B Lotus part no. A100B6070V Adhesive: Betaseal 1701 Lotus part no. A082B6281F Glass Cleaner: Betawipe VP 04604 Lotus part no. A082B6150V Primer: Betaprime 5001 Lotus part no. A100B6009V Adhesive: Betaseal 1701 Lotus part no. A082B6281F or Betamate E2400 Lotus part no. A082B8415V Uncoated Lexan/Perspex Cleaner: Abrasion & dry wipe Primer: Betapnme 5404 Lotus part no. A082B6337V Adhesive: Betaseal 1701 Lotus part no. A082B6281F or Betamate E2400 Lotus part no. A082B8415V
Residual adhesive (i.e. rebonding to surface after cutting off old panel) Cleaner, primer & re-activator: Betawipe 4000 Lotus part no. A082B6355V Adhesive: Betaseal 1701 Lotus part no. A082B6281 F or Betamate E2400 Lotus part no. A082B8415V Applicator Bottle An applicator bottle is available for use with some cleaners and primers, and has a disposable felt pad which should be changed regularly to minimise surface contamination: Applicator bottle: A000Z1071F Cap: A082B6353S Felt pad: A082B6354S Product Usage BETAWIPE VP 04604 (A082B6150V): Description: Activator and cleaning agent used to promote adhesion to the substrate surface. Supplied in a 250ml aluminium container with a YELLOW coloured cap. Application: - Wipe on/wipe off type.
- Pour Betawipe VP 04604 into applicator bottle, and immediately refit the yellow cap onto the container. sn_bq_cyclone.indd 6 03/03/2006 10:53:39 |
