Scion xD. Service Manual - part 13

196

3-2. Using the audio system

Scion_xD_OM_OM52E36U_(U)

Using the microphone

The microphone can be used for the voice command in the

Bluetooth

®

 audio system or the hands-free phone system.

For more information, please refer to the “SCION Audio System

Owner’s Manual” or “SCION Navigation System Owner’s Manual”.

197

3

Interior features

Scion_xD_OM_OM52E36U_(U)

3-3. Using the interior lights

Interior lights list

Interior light (

P. 198)

Personal lights (

P. 198)

198

3-3. Using the interior lights

Scion_xD_OM_OM52E36U_(U)

Interior light

“DOOR”

The interior light comes on when
any of the side doors is opened.
They turn off when all the side
doors are closed.

“OFF”

“ON”

Personal lights

On/off

■

Illuminated entry system

The lights automatically turn on/off according to the engine switch position,
whether the doors are locked/unlocked, and whether the doors are open/
closed.

■

To prevent the battery discharged

If the interior light remain on when the door is not fully closed and the interior
light switch is in the “DOOR” position, the lights will go off automatically after
20 minutes.

■

Customization

Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features:

P. 378)

Interior light and personal lights

199

3

Interior features

Scion_xD_OM_OM52E36U_(U)

3-4. Using the storage features

List of storage features

CAUTION

■

Items that should not be left in the storage spaces

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:

●

Glasses may be deformed by heat or cracked if they come into contact
with other stored items.

●

Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.

Auxiliary boxes

Glove boxes

Cup holders

Bottle holders

200

3-4. Using the storage features

Scion_xD_OM_OM52E36U_(U)

Glove boxes

Lower glove box

Pull up the lever to open the
glove box.

Upper glove box

Pull up the lever.

CAUTION

■

Caution while driving

Keep the glove boxes closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by the
open glove boxes or the items stored inside.

Glove boxes

201

3-4. Using the storage features

3

Interior features

Scion_xD_OM_OM52E36U_(U)

Cup holders

Front

Front passenger’s side

Pull on the lid.

Rear

Cup holders

202

3-4. Using the storage features

Scion_xD_OM_OM52E36U_(U)

CAUTION

■

Items unsuitable for the cup holders

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident,
sudden braking or sudden swerving, causing injury. If possible, cover hot
drinks to prevent burns.

■

When not in use (front passenger’s side cup holder only)

Keep the cup holder closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by the
open cup holder or the items stored inside.

NOTICE

■

To prevent damage to the front passenger’s side cup holder

Be careful not to subject the cup holder to an impact.
Failure to do so may unfix the cup holder. Reattach them if they are unfixed.

Cup holders

203

3-4. Using the storage features

3

Interior features

Scion_xD_OM_OM52E36U_(U)

Auxiliary box

Press the knob then pull the lid
down.

CAUTION

■

Caution while driving

Keep the auxiliary box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by the
open auxiliary box or the items stored inside.

Auxiliary box

204

3-4. Using the storage features

Scion_xD_OM_OM52E36U_(U)

Bottle holders

Front

Rear

■

When using the holder as a bottle holder

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending on its size or shape.

NOTICE

■

Items that should not be stowed in the bottle holders

Do not place open bottles in the bottle holders, or glasses and paper cups
containing liquid. The contents may spill and glasses may break.

Bottle holders

205

3

Interior features

Scion_xD_OM_OM52E36U_(U)

3-5. Other interior features

Sun visors

Forward position:
Flip down.

Side position:
Flip down, unhook, and
swing to the side.

206

3-5. Other interior features

Scion_xD_OM_OM52E36U_(U)

Vanity mirrors

Slide the cover to open.

207

3-5. Other interior features

3

Interior features

Scion_xD_OM_OM52E36U_(U)

Clock

■

When disconnecting and reconnecting battery terminals

The time display will automatically be set to 1:00.

Adjusts the hour.

Adjusts the minutes.

Rounds to the nearest
hour.

*

*

: e.g. 1:00 to 1:29

 1:00

1:30 to 1:59

 2:00

STEP

1

208

3-5. Other interior features

Scion_xD_OM_OM52E36U_(U)

Power outlet

■

The power outlet can be used when

The engine switch is in the “ACC” or “ON” position.

NOTICE

■

To avoid damaging the power outlet

Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.

■

To prevent blown fuse

Do not use an accessory that uses more than 12 V 10 A.

■

To prevent battery discharge

Do not use the power outlet longer than necessary when the engine is not
running.

The power outlet can be used for 12 V accessories that run on less

than 10 A.

Open the lid.

209

3-5. Other interior features

3

Interior features

Scion_xD_OM_OM52E36U_(U)

Assist grips

CAUTION

■

Assist grip

Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.

NOTICE

■

To prevent damage of the assist grip

Do not hang any heavy object or put a heavy load on the assist grip.

An assist grip installed on the ceiling can be used to support your

body while sitting on the seat.

210

3-5. Other interior features

Scion_xD_OM_OM52E36U_(U)

Floor mat

Use only floor mats designed specifically for vehicles of the same

model and model year as your vehicle. Fix them securely in place

onto the carpet.

Insert the retaining hooks
(clips) into the floor mat eye-
lets.

Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.

*

: Always align the

 marks.

The shape of the retaining hooks (clips) may differ from that shown
in the illustration.

STEP

1

STEP

2

*

211

3-5. Other interior features

3

Interior features

Scion_xD_OM_OM52E36U_(U)

CAUTION

Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it may
become difficult to stop the vehicle, leading to a serious accident.

■

When installing the driver’s floor mat

●

Do not use floor mats designed for other models or different model year
vehicles, even if they are Scion Genuine floor mats.

●

Only use floor mats designed for the driver’s seat.

●

Always install the floor mat securely using the retaining hooks (clips) pro-
vided.

●

Do not use two or more floor mats on top of each other.

●

Do not place the floor mat bottom-side up or upside-down.

■

Before driving

●

Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks (clips). Be
especially careful to perform this check
after cleaning the floor.

●

With the engine stopped and the shift
lever in P (automatic transmission) or N
(manual transmission), fully depress
each pedal to the floor to make sure it
does not interfere with the floor mat.
