Maserati Ghibli (Maserati Touch Control). Service Manual - part 6





(Continued)

7. If your phone does not support

phonebook download or call log
download over Bluetooth

®

than

these commands will return a
response that the contact does
not exist in the phonebook.

8. Available Voice Commands are

shown in bold face and
underlined in the gray shaded
boxes.

Managing text messages with

MTC System

The commands can be imparted from
any screenshot after pushing the MTC
Phone button

on the steering

wheel.
Send a message to 248 555 1212

• Insert message from the preset list of

the MTC or impart “List” to listen all
18 preset messages.

• Say “Yes” to send the selected

message.

• The message is sent to the number

linked to the receiver (see Note 4, 5).

Send a message to John Smith Mobile

• Insert the message from the MTC

system preset list or impart “List” to
listen all 18 preset messages.

• Say “Yes” to send selected message.
• The message is sent to the number

linked to the receiver (see Note 1, 2,
5, 8, 9).

Show Messages
Displays box of incoming messages
downloaded from your phone (see
Note 4, 6).
• Say “Listen to number 4”.
• The MTC system reads the message

by using the car's audio system.

• After reading the message the

following commands are
automatically available:

• Read (reads the message by using

the car's audio system). After
reading the message it is possible
to read, reply or forward the
message.

• Send a Reply (insert the message

from the MTC System or impart
”List” to listen all 18 preset
messages).

• Forward (insert receiver name and

phone type imparting
subsequently “Yes” to send the
selected message. The message is

sent to the number linked to the
receiver name.

• Call (dials the number linked to

the message).

or

• Say “View number 4”.
• The MTC System displays the

message on the screen.

• While displaying the message,

following commands will be
available after pressing the

soft-key:

• Read (reads the message using the

car’s audio system. After reading
the message it is possible to read
again, reply or forward the
message).

• Send a Reply (insert the message

from the MTC System or impart
”List” to listen all 18 preset
messages).

• Forward (insert receiver name and

phone type imparting “Yes” to
send the selected message. The
message is sent to the number
linked to the receiver name).

• Call (dials the number linked to

the message).

MTC System Phone

8

91

-------------------------------------------------------------------------------------------------------------------------------------------------------------

NOTE:

1. You can replace “John Smith”

with any name in your mobile or
favorite phone book. You can
also say “Send a message to John
Smith” and the system will ask
you which phone number you
want to send a message to for
John Smith.

2. You can replace “Mobile” with

“Home”, “Work” or “Other”.

3. You can replace “Incoming Calls”

with “Outgoing Calls” or “Missed
Calls”.

4. Messaging commands only work

if the MTC System is equipped
with this feature and the mobile
phone supports messaging over
Bluetooth

®

.

5. You can replace “248 555 1212”

with any phone number
supported by your Mobile phone.

6. You can replace “4” with any

message number shown on the
screen.

(Continued)

(Continued)

7. If your phone does not support

phonebook download or call log
download over Bluetooth

®

than

these commands will return a
response that the contact does
not exist in the phonebook.

8. Available Voice Commands are

shown in bold face and
underlined in the gray shaded
boxes.

General information

The current device complies with Part
15 of FCC rules and RSS 210 of Canada
Industry. The device functioning is
subject to following conditions:
• changes or modifications not

expressly approved by the authority
relevant for conformity could void
the possibility of use of the
equipment by the user;

• the device may not cause harmful

interference;

• must beat any interference, including

interference that can cause its
malfunction.

MTC System Phone

8

92

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Settings Main Menu

Touch the Settings soft-key to display
the list of available settings fig. 34.

• Display
• Clock & Date
• Safety & Driving Assistance
• Lights
• Doors & Locks
• Auto-On Comfort & Remote Start
• Engine Off Options
• Audio
• Phone/Bluetooth
• Radio Setup or SIRIUS Setup (where

available)

Display

Your MTC System display can be
customized by following the steps:

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Display soft-key to

enter the Display Menu fig. 35.

3. The Display Menu shows the

following options for you to
customize your display.
• Display Mode
• Display Brightness with

Headlights On

• Display Brightness with

Headlights Off

• Set Language
• Units
• Voice Response Length
• Touchscreen Beep
• Control Screen Time-Out
• Navigation Turn-by-Turn

Displayed on Cluster

4. Touch the + or – soft-key to

change the Brightness. Or touch
the check mark or empty box to
change a selection.

NOTE:

The check-mark indicates the current
selection is active.

5.

Touch the left arrow soft-key
to return to the Display Menu.

6.

Touch the X soft-key to exit
from the Display Menu and
Settings.

fig. 34

fig. 35

Settings

9

94

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Display Mode
The display lighting can be set in Day,
Night, or Auto mode (automatic
switching from Day to Night).
Display Brightness with Headlights On
This mode allows you to adjust display
brightness by headlights on.
Display Brightness with Headlights

Off
This mode allows you to adjust display
brightness by headlights off.
Set Language
This mode allows to select the display
language fig. 36.

The available languages are:
• English
• Français
• Espaňa

• Deutsch
• Italiano
• Nederlands
Units
This mode allows you to select the
measurement units:
• US
• Metric
Voice Response Length
This mode allows you to select the
voice response length:
• Brief
• Detailed
Touchscreen Beep
This mode allows you to select
whether to enable or disable the Beep
sound every time you operate a
soft-key on the touch screen.
Control Screen Time-Out
This mode allows you to enable or
disable the delay of the monitor
screen display.
Navigation Turn-by-Turn displayed on

Cluster
This mode allows you to turn on or
off, turn-by-turn pictograms on the
instrument panel during navigation.

Clock & Date

1. Press the Settings soft-key on the

bottom of the screen.

NOTE:

The Clock Setting Menu can also be
accessed by touching the time as it is
displayed on the screen.

2. Press the Clock soft-key to enter

the Clock Menu fig. 37.

fig. 36

fig. 37

Settings

9

95

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3. In the Set Time screen, press the

+ or – soft-keys to adjust the
hours or minutes.

4. Other options available:

• Sync Time with GPS Time,

Radio Time or Off.

• Time Format (12 or 24 hours).
• Set Date in Cluster

(DD/MM/YY).

5. Touch the check mark or empty

box to change a selection.

NOTE:

The check-mark indicates the current
selection is active.

6. Touch the left arrow soft-key to

return to the Main Menu.

7. Touch the X soft-key to exit from

the Clock Menu and Settings.

Safety & Driving Assistance

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Safety & Driving

Assistance soft-key to enter the
Menu.

3. The available options are:

• Park Assist (Off, Sound or

Sound + Display).

• Tilt Side Mirrors in Reverse (On

or Off).

• Parkview Backup Camera (On

or Off).

• Rain Sensing Auto Wipers (On

or Off).

4. Touch the check mark or empty

box to change a selection.

NOTE:

The check-mark indicates the current
selection is active.

5. Touch the left arrow soft-key to

return to the Main Menu.

6. Touch the X soft-key to exit from

the Safety & Driving Assistance
Menu and Settings.

Lights

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Lights soft-key to enter

the Menu.

3. The options available are:

• Headlight Off Delay.
• Headlight Illumination on

Approach.

• Headlights with Wipers.
• Auto Dim High Beams.
• Steering Directed Headlights.
• Headlight Dip (Traffic

Changeover) (condition
responsive automatically
adjusted headlamp beam).

• Flash Lamps with Lock.

4. Press the + or – soft-keys to

adjust the time in seconds.

5. Touch the check mark or empty

box to change a selection.

NOTE:

The check-mark indicates the current
selection is active.

Settings

9

96

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6. Touch the left arrow soft-key to

return to the Main Menu.

7. Touch the X soft-key to exit from

the Lights Menu and Settings.

Doors & Locks

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Doors & Locks soft-key

to enter the Menu.

3. The options available are:

• Auto Door Locks.
• Auto Unlock on Exit.
• Flash Lamps with Lock.
• 1

st

Press of Key Fob Unlocks

(Driver Door only or All
Doors).

• Passive Entry.
• Personal Settings Linked to

Key Fob.

4. Touch the check mark or empty

box to change a selection.

NOTE:

The check-mark indicates the current
selection is active.

5. Touch the left arrow soft-key to

return to the Main Menu.

6. Touch the X soft-key to exit from

the Doors & Locks Menu and
Settings.

Auto-On Comfort & Remote

Start

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Auto-On Comfort &

Remote Start soft-key to enter
the Menu:
• Auto-on Driver Heated/Vented

Seat & Steering Wheel with
Vehicle Start (On or Off).

3. Touch the check mark or empty

box to change the selection.

NOTE:

The check-mark indicates the selection
is active.

4. Touch the left arrow soft-key to

return to the Main Menu.

5. Touch the X soft-key to exit from

the Auto-On Comfort & Remote
Start Menu and Settings.

Engine Off Options

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Engine Off Options

soft-key to enter the Menu.

3. The options available are:

• Easy Exit Seat
• Engine Off Power Delay
• Headlight Off Delay

4. Press the + or – soft-keys to

adjust the time in seconds.

5. Touch the check mark or empty

box to change a selection.

NOTE:

The check-mark indicates the current
selection is active.

Settings

9

97

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6. Touch the left arrow soft-key to

return to the Main Menu.

7. Touch the X soft-key to exit from

the Engine Off Options Menu
and Settings.

Audio

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Audio soft-key to enter

the audio setting Menu.

Refer to Audio in Radio Mode section
for adjusting the audio settings.

Phone/Bluetooth

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Phone/Bluetooth

soft-key to enter the Menu.

Refer to MTC System Phone section in
this manual for the Phone/Bluetooth
settings.

Radio Setup

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the Radio Setup soft-key to

enter the Menu:
• FM
• DAB

3. Press the FM soft-key to enter the

options available:
• Traffic Announcement
• Alternative Frequency
• Regional

4. Press the DAB soft-key to enter

the option available:
• Alternative Frequency

5. Touch the check mark or empty

box to change a selection.

NOTE:

The check-mark indicates the current
selection is active.

6. Touch the left arrow soft-key to

return to the Main Menu.

7. Touch the X soft-key to exit from

the Radio Setup Menu and
Settings.

SIRIUS Setup (where available)

1. Press the Settings soft-key on the

bottom of the screen.

2. Press the SIRIUS Setup soft-key to

enter the following Menu.

Channel Skip
SIRIUS can be programmed to
designate a group of channels that are
the most desirable lo listen to or to
exclude undesirable channels while
scanning. To make your selection,
touch the Channel Skip soft-key, select
the channels you would like to skip
followed by pressing the ◄ arrow
soft-key.
Subscription Information
New vehicle purchasers or lessees will
receive a free limited time subscription
to SIRIUS Satellite Radio with your
radio. Following the expiration of the
free services, it will be necessary to
access the information on the
Subscription Information screen in
order to re-subscribe.
Touch the Subscription Info soft-key to
access the Subscription Information
screen.
Write down the SIRIUS ID numbers for
your receiver. To reactivate your

Settings

9

98

-------------------------------------------------------------------------------------------------------------------------------------------------------------

service, either call the number listed
on the screen or visit the provider
online.

NOTE:

SIRIUS Travel Link is a separate
subscription.

Settings

9

99

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Antenna

GPS Navigation Antenna . . . . . . . .9
Satellite Radio Antenna . . . . . . . .9

Assistance

Emergency and Towing
Assistance . . . . . . . . . . . . . . . . .82
Safety and Driving Assistance . . . .96

Audio. . . . . . . . . . . . . . . . . . . . . .24
Auto-On Comfort and Remote Start .97
Aux Mode. . . . . . . . . . . . . . . . . . .36

Bluetooth . . . . . . . . . . . . . . . . . . .37

Bluetooth Communication link . . .89
Pair a Bluetooth Streaming Audio
Device. . . . . . . . . . . . . . . . . . . .79
Phone/Bluetooth . . . . . . . . . . . .98

Bluetooth Mode . . . . . . . . . . . . . .37

Care, System . . . . . . . . . . . . . . . . . .8
Climate Mode . . . . . . . . . . . . . . . . .3

Front Climate . . . . . . . . . . . . . . .46
RearClimate . . . . . . . . . . . . . . . .47

Clock . . . . . . . . . . . . . . . . . . . . . .95
Controls Mode . . . . . . . . . . . . . . . .3

Devices, Controls, Buttons. . . . . . . . .3
Doors and Locks. . . . . . . . . . . . . . .97

Emergency and Towing Assistance . .82
Engine Off Options . . . . . . . . . . . .97

GPS Satellite Signals . . . . . . . . . . . .63

Gracenote . . . . . . . . . . . . . . . . . . .9

Lights . . . . . . . . . . . . . . . . . . . . . .96

MTC System Phone . . . . . . . . . . . . .3

Bluetooth Communication link . . .89
Emergency and Towing
Assistance . . . . . . . . . . . . . . . . .82
Hands-Free Calling . . . . . . . . . . .90
Managing Text Messages with MTC
System . . . . . . . . . . . . . . . . . . .91
MTC System Voice Command
Button . . . . . . . . . . . . . . . . . . .77
MTC Sytstem Phone Button . . . . .77
Pair a Bluetooth Streaming Audio
Device. . . . . . . . . . . . . . . . . . . .79
Pair (Link) MTC System Phone to a
Mobile Phone . . . . . . . . . . . . . .78
Phonebook Download - Automatic
Phonebook Transfer From Mobile
Phone . . . . . . . . . . . . . . . . . . . .81
Phone Call Features . . . . . . . . . .82
Screen Activated Features . . . . . .76
Sms Function . . . . . . . . . . . . . . .88
Transfer Call to and from Mobile
Phone . . . . . . . . . . . . . . . . . . . .87
Voice Command Mode . . . . . . . .87
Voice Mail Call . . . . . . . . . . . . . .85

MTC System Voice Command

Button . . . . . . . . . . . . . . . . . . . .25

MTC Sytstem Phone Button . . . . . . .77

Navigation Mode. . . . . . . . . . . . . . .3

About GPS Satellite Signals . . . . .63
Custom POI (Points Of Interest). . .64
Main Menu . . . . . . . . . . . . . . . .51
Navigation System Safety . . . . . . .7
Settings. . . . . . . . . . . . . . . . . . .59
Updating the Map Data. . . . . . . .63
Using the Tools. . . . . . . . . . . . . .58
Viewing the map pages . . . . . . . .56
Voice Commands . . . . . . . . . . . .61
Where To? (Finding Location). . . .52

Pair a Bluetooth Streaming Audio

Device . . . . . . . . . . . . . . . . . . . .79

Pair (Link) MTC System Phone to a

Mobile Phone . . . . . . . . . . . . . . .78

Phone/Bluetooth . . . . . . . . . . . . . .98
Phone Call Features . . . . . . . . . . . .82
Player Mode . . . . . . . . . . . . . . . . . .3

Aux Mode . . . . . . . . . . . . . . . . .36
Bluetooth Mode . . . . . . . . . . . . .37
Disc Mode . . . . . . . . . . . . . . . . .30
SD Card Mode . . . . . . . . . . . . . .34
USB/iPod Mode . . . . . . . . . . . . .32

Radio Mode . . . . . . . . . . . . . . . . . .3

Audio . . . . . . . . . . . . . . . . . . . .24
MTC System Voice Command
Button . . . . . . . . . . . . . . . . . . .25
Radio Functions . . . . . . . . . . . . .18
Radio Setup . . . . . . . . . . . . . . . .98
Setting Preset. . . . . . . . . . . . . . .20
Voice Commands . . . . . . . . . . . .27

Index

10

102

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety and Driving Assistance . . . . .96
Safety Guidelines . . . . . . . . . . . . . .6

CD/DVD Drive . . . . . . . . . . . . . . .9
GPS Navigation Antenna. . . . . . . .9
Gracenote. . . . . . . . . . . . . . . . . .9
Navigation System Safety . . . . . . .7
Other Electronic Devices . . . . . . . .9
Satellite Radio Antenna . . . . . . . .9
System Care . . . . . . . . . . . . . . . .8

SD Card Mode. . . . . . . . . . . . . . . .34
Settings . . . . . . . . . . . . . . . . . . . . .3

Audio . . . . . . . . . . . . . . . . . . . .98
Auto-On Comfort and Remote
Start. . . . . . . . . . . . . . . . . . . . .97
Clock . . . . . . . . . . . . . . . . . . . .95
Doors and Locks. . . . . . . . . . . . .97
Engine Off Options. . . . . . . . . . .97
Lights . . . . . . . . . . . . . . . . . . . .96
Phone/Bluetooth . . . . . . . . . . . .98
Radio Setup. . . . . . . . . . . . . . . .98
Safety and Driving Assistance. . . .96
Settings Main Menu . . . . . . . . . .94
SIRIUS Setup (where available) . . .98

SiriusXM™ Satellite Radio Mode . . .21
SiriusXM™ Travel Link (where

available) . . . . . . . . . . . . . . . . . .64

Sms/Text Messages

Managing Text Messages with MTC
System . . . . . . . . . . . . . . . . . . .91
Sms Function . . . . . . . . . . . . . . .88

USB/iPod Mode . . . . . . . . . . . . . . .32

Voice Commands . . . . . . . . . . . . . .27
Voice Mail Call . . . . . . . . . . . . . . .85

Index

10

103

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     4      5      6
