In brief

Vehicle unlocking

Unlocking with radio remote

In brief

control

Unlocking with key

Initial drive information

Press button Ä to unlock the

Turn the key in the driver's door lock

vehicle.

towards the front of the vehicle.

Press button Å to unlock the load

compartment only.

Open the doors by pulling the

handles. To open the tailgate, press

the button under the tailgate handle.

Radio remote control 3 20, Central

locking system 3 21, Load

compartment 3 25, Power windows

3 29.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Seat adjustment

Seat backrests

Seat height

Seat positioning

Turn handwheel. Do not lean on

Lever pumping motion

backrest when adjusting.

= higher

Pull handle, slide seat, release

Seat position 3 33, Seat adjustment

down = lower

handle.

3 33.

Operate lever and adjust body weight

Seat position 3 33, Seat adjustment

on seat to raise or lower it.

3 33.

Seat position 3 33, Seat adjustment

3 33.

9 Danger

Do not sit nearer than 25 cm from

the steering wheel, to permit safe

airbag deployment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Head restraint adjustment

Seat belt

Mirror adjustment

Interior mirror

Press release catch, adjust height,

Pull out the seat belt and engage in

engage.

belt buckle. The seat belt must not be

twisted and must fit close against the

Adjust the lever on the underside to

Head restraints 3 32.

body. The backrest must not be tilted

reduce dazzle.

back too far (maximum approx. 25 °).

Interior mirror 3 28.

To release belt, press red button on

belt buckle.

Seat position 3 33, Seat belts

3 38, Airbag system 3 41.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Exterior mirrors

Steering wheel adjustment

Select the relevant exterior mirror by

turning the control to left _ or right 6.

Swivel lever in required direction.

Then swivel the control to adjust the

Unlock the lever, adjust the steering

mirror.

wheel, then engage lever and ensure

it is fully locked.

In position o no mirror is selected.

Do not adjust steering wheel unless

Convex exterior mirrors 3 27,

vehicle is stationary and the steering

Electric adjustment 3 27, Folding

wheel lock has been released.

exterior mirrors 3 28, Heated

exterior mirrors 3 28.

Airbag system 3 41, Ignition

positions 3 102.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Instrument panel overview

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Fixed air vents

100

Rear fog light

Exterior lighting

Side air vents

Heated rear window

Light switch

Heated exterior mirrors

Turn and lane-change

Front passenger airbag

signals, headlight flash,

Glovebox

low beam and high beam

Climate control system

Instruments

Electronic climate control

Driver Information Centre

system

Windscreen wiper,

Selector lever, manual

windscreen washer

transmission

107

system, rear window

wiper/washer

Manual transmission

automated

108

Turn light switch:

Trip odometer reset

Ignition switch with

§ = off / daytime running lights

Centre air vents

steering wheel lock

102

9 = sidelights / headlights

Headlight range

Steering wheel controls

Lighting 3 88, Daytime running

adjustment

Horn

lights 3 89.

Driver Information Centre

controls

Driver airbag

Steering wheel adjustment . . 61

Trip computer

Cruise control

115

Instrument illumination

Fuse box

140

Hazard warning flashers

Bonnet release lever

127

Front fog lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Fog lights

Headlight flash, high beam and

Turn and lane-change signals

low beam

Press light switch:

lever up

= right turn signal

headlight flash

= pull lever

lever down

= left turn signal

> = front fog lights

r = rear fog light

high beam

= push lever

Turn and lane-change signals

low beam

= pull lever

3 90.

High beam 3 88, Headlight flash

3 88.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Hazard warning flashers

Horn

Washer and wiper systems

Windscreen wiper

Operated with the ¨ button.

Press j.

Hazard warning flashers 3 90.

Twist lever:

= off

= intermittent wiping

= slow

= fast

For a single wipe when the

windscreen wiper is off, move the

lever up.

Windscreen wiper 3 62, Wiper

blade replacement 3 131.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Windscreen and headlight

Rear window wiper and washer

Climate control

washer systems

systems

Heated rear window, heated

exterior mirrors

Pull lever.

Twist band to activate the rear

window wiper.

Windscreen and headlight washer

system 3 62, Washer fluid 3 129.

The rear window wiper comes on

The heating is operated by pressing

automatically when the windscreen

the Ü button.

wiper is switched on and reverse gear

Heated rear window 3 31.

is engaged.

Push lever: Washer fluid is sprayed

on the rear window and the wiper

wipes a few times.

Rear window wiper/washer 3 63.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Demisting and defrosting the

Electronic climate control system

Transmission

windows

Manual transmission

Air conditioning system

Press button Ê.

Temperature and air distribution are

set automatically and the fan runs at

Reverse: with the vehicle stationary,

Set the temperature control to

a high speed.

wait 3 seconds after depressing the

warmest level.

clutch pedal, pull up the collar on the

To return to automatic mode: press

Set fan speed to highest level.

selector lever and engage the gear.

button n or AUTO.

Set air distribution control to V.

If the gear does not engage, set the

Climate control system 3 95,

lever to neutral, release the clutch

Cooling n on.

Electronic climate control system

pedal and depress again; then repeat

3 97.

Heated rear window Ü on.

gear selection.

Manual transmission 3 107.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

Manual transmission automated

Starting off

Starting the engine

Check before starting-off

■ Tyre pressure and condition 3 143,

3 174.

■ Engine oil level and fluid levels

3 127.

■ All windows, mirrors, exterior

lighting and number plates are free

from dirt, snow and ice and are

operational.

■ Proper position of mirrors, seats,

and seat belts 3 27, 3 33,

neutral position

3 39.

■ Turn key to position MAR

drive position

■ Brake function at low speed,

■ move the steering wheel slightly to

higher gear

particularly if the brakes are wet.

release the steering wheel lock

lower gear

■ operate clutch and brake

A/M

switch between automatic

and manual mode

■ manual transmission automated:

reverse gear (with selector

operate brake, the transmission

lever lock)

automatically shifts to N (neutral)

■ do not operate accelerator pedal

Manual transmission automated

3 108.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

■ diesel engines: turn the key to

Stop-start system

Parking

position MAR for preheating and

■ Always apply the parking brake.

wait until control indicator ! goes

Activate the manual parking brake

out

without pressing the release button.

■ turn key to position AVV and

Apply as firmly as possible on a

release

downhill slope or uphill slope.

Starting the engine 3 102.

Depress foot brake at the same

time to reduce operating force.

■ Switch off the engine. Turn the

ignition key to position STOP and

remove it. Turn the steering wheel

until the steering wheel lock is felt

to engage.

If the vehicle is at a low speed or at a

■ If the vehicle is on a level surface or

standstill and certain conditions are

uphill slope, engage first gear

fulfilled, activate an Autostop as

before switching off the ignition. On

follows:

an uphill slope, turn the front

wheels away from the kerb.

■ Depress the clutch pedal

If the vehicle is on a downhill slope,

■ set the lever in neutral

engage reverse gear before

■ release the clutch pedal

switching off the ignition. Turn the

An Autostop is indicated when ^ is

front wheels towards the kerb.

displayed in the Driver Information

■ Lock the vehicle with button e on

Centre 3 79.

the radio remote control.

To restart the engine, depress the

clutch pedal again.

Stop-start system 3 103.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In brief

■ Do not park the vehicle on an easily

ignitable surface. The high

temperature of the exhaust system

could ignite the surface.

■ Close the windows.

■ The engine cooling fans may run

after the engine has been switched

off 3 126.

■ After running at high engine speeds

or with high engine loads, operate

the engine briefly at a low load or

run in neutral for

approx. 30 seconds before

switching off, in order to protect the

turbocharger.

Keys, locks 3 19, Laying the vehicle

up for a long period of time 3 125.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Key with foldaway key section

Keys, doors and

Keys, locks

windows

Keys

Replacement keys

Keys, locks

The key number is specified in the

Car Pass or on a detachable tag.

Doors

The key number must be quoted

Vehicle security

when ordering replacement keys as it

Exterior mirrors

is a component of the immobiliser

Interior mirrors

system.

Windows

Locks 3 155.

Lock cylinders

Press button to extend. To fold the

Designed to free-wheel if they are

key, first press the button.

forcefully rotated without the correct

key or if the correct key is not fully

Car Pass

inserted. To reset, turn cylinder with

the correct key until its slot is vertical,

The Car Pass contains security

remove key and then re-insert it. If the

related vehicle data and should

cylinder still free-wheels, turn the key

therefore be kept in a safe place.

through 180° and repeat operation.

When the vehicle is taken to a

workshop, this vehicle data is needed

in order to perform certain operations.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Radio remote control

Fault

If the central locking system cannot

be operated with the radio remote

control, it may be due to the following:

■ Range exceeded

■ Battery voltage too low

Batteries do not belong in household

■ Frequent, repeated operation of the

waste. They must be disposed of at

radio remote control while not in

an appropriate recycling collection

range

point.

■ Overload of the central locking

system by operating at frequent

Key with foldaway key section

intervals, the power supply is

interrupted for a short time

Used to operate:

■ Interference from higher-power

■ Central locking system 3 21

radio waves from other sources

■ Anti-theft locking system 3 26

Unlocking 3 21.

■ Power windows 3 29

Radio remote control battery

The radio remote control has a range

replacement

of up to 5 metres. It can be restricted

Replace the battery as soon as the

by external influences. The hazard

range reduces.

warning flashers confirm operation.

Handle with care, protect from

moisture and high temperatures and

Extend the key and remove the

avoid unnecessary operation.

battery holder by undoing the screw

with a suitable screwdriver. Remove

the battery holder from the key and
