290
Technical data
(ctd.)
Tyre pressure
Tyre pressure for full
Tyre pressure in psi/bar
for load of up to
load
4 people
Engine1)
Tyres
Front
Rear
Front
Rear
Z 28 NEL,
215/55 R 162)
36/2.5
33/2.3
39/2.7
46/3.2
Z 28 NET
215/50 R 172),
39/2.7
35/2.4
42/2.9
49/3.4
225/45 R 172),
225/45 R 182)
215/55 R 163)
38/2.6
35/2.4
41/2.8
48/3.3
215/50 R 173),
41/2.8
36/2.5
44/3.0
51/3.5
225/45 R 173),
225/45 R 183)
all
T 115/70 R 16
61/4.2
61/4.2
61/4.2
61/4.2
(temporary spare)4)
1) Sales designation - see pages 280, 281.
2) Version with manual transmission.
3) Version with automatic transmission.
4) For notes on the temporary spare wheel - see page 217.
Technical data
291
(ctd.)
Tyre pressure
Tyre pressure
Tyre pressure for
Tyre pressure in psi/bar
for load of up to
ECO1) loaded with
full load
4 people
up to 4 people
Engine2)
Tyres
Front
Rear
Front
Rear
Front
Rear
Z 19 DT
195/65 R 153)
33/2.3
33/2.3
-
-
35/2.4
42/2.9
205/55 R 16
215/55 R 16,
32/2.2
32/2.2
36/2.5
36/2.5
32/2.2
39/2.7
215/50 R 17,
225/45 R 17,
225/45 R 18
Z 19 DTL,
195/65 R 153)
35/2.4
35/2.4
-
-
38/2.6
45/3.1
Z 19 DTH
205/55 R 16
215/55 R 16,
33/2.3
33/2.3
38/2.6
38/2.6
36/2.5
44/3.0
215/50 R 17,
225/45 R 17,
225/45 R 18
Z 30 DT
215/55 R 16
36/2.5
33/2.3
-
-
39/2.7
46/3.2
215/50 R 17,
38/2.6
35/2.4
-
-
41/2.8
48/3.3
225/45 R 18
225/45 R 17
39/2.7
35/2.4
-
-
42/2.9
49/3.4
all
T 115/70 R 16
61/4.2
61/4.2
-
-
61/4.2
61/4.2
4)
(temporary spare)
1) To reduce fuel consumption as much as possible.
2) Sales designation - see pages 280, 281.
3) Only permitted as winter tyres.
4) For notes on the temporary spare wheel - see page 234.
292
Technical data
(ctd.)
Vehicles with 19-inch wheels
Tyre pressure
Tyre pressure for full
Tyre pressure in psi/bar
for load of up to
load
4 people
Engine1)
Tyres
Front
Rear
Front
Rear
Z 18 XE,
235/35 R 19
39/2.7
35/2.4
41/2.8
48/3.3
Z 18 XER,
Z 22 YH
215/55 R 162),
33/2.3
33/2.3
36/2.5
44/3.0
225/45 R 172),
205/50 R 172)
Z 20 NET,
235/35 R 19
39/2.7
35/2.4
41/2.8
48/3.3
Z 19 DTL,
Z 19 DTH
215/55 R 162),
33/2.3
33/2.3
36/2.5
44/3.0
225/45 R 172)
205/50 R 172)
39/2.7
35/2.4
41/2.8
48/3.3
Z 28 NEL,
235/35 R 19
42/2.9
38/2.6
45/3.1
51/3.5
Z 28 NET
215/55 R 162),
41/2.8
36/2.5
44/3.0
51/3.5
225/45 R 172)
205/50 R 172)
42/2.9
38/2.6
45/3.1
51/3.5
Z 30 DT
235/35 R 19
42/2.9
38/2.6
45/3.1
51/3.5
215/55 R 162),
39/2.7
36/2.5
42/2.9
49/3.4
225/45 R 172)
205/50 R 172)
42/2.9
38/2.6
45/3.1
54/3.5
all
T 115/70 R 163)
61/4.2
61/4.2
61/4.2
61/4.2
1) Sales designation, see pages 280, 281.
2) Only permitted as winter tyres.
3) For notes on the temporary spare wheel, see page 234.
Technical data
293
Electrical system
Battery
Voltage
12 Volt
Amp hours
55 Ah / 60 Ah 3 / 66 Ah 3 / 70 Ah 3 /
72 Ah 3 / 85 Ah 3
Battery for remote control of central
locking system
CR 20 32
Battery for remote control of the auxiliary
heating/auxiliary ventilation
AAA LR 03
294
Technical data
Capacities
(approx. litre)
Engine1)
Z 18 XE
Z 18 XER
Z 20 NET
Z 22 YH
Z 28 NEL
Z 28 NET
Fuel tank (nominal content)
60
60
60
60
60
60
Engine oil with filter change
4.25
4.5
6.0
5.0
6.0
6.0
between MIN and MAX on dipstick
1.0
1.0
1.0
1.0
1.0
1.0
Windscreen wash reservoir
2.9
2.9
2.9
2.9
2.9
2.9
with headlight wash system
5.6
5.6
5.6
5.6
5.6
5.6
1) Sales designation - see pages 280, 281.
Technical data
295
Capacities
(approx. litre)
Engine1)
Z 19 DTL
Z 19 DT
Z 19 DTH
Z 30 DT
Fuel tank (nominal content)
60
60
60
60
Engine oil with filter change
4.3
4.3
4.3
7.5
between MIN and MAX on dipstick
1.0
1.0
1.0
1.0
Windscreen wash reservoir
2.9
2.9
2.9
2.9
with headlight wash system
5.6
5.6
5.6
5.6
1) Sales designation - see pages 280, 281.
296
Technical data
Dimensions
(approx. mm)
Signum
Overall length
46511)
Overall width
1798
Width with two exterior mirrors
2036
Overall height2)
1466
Length of luggage compartment
929
floor
Luggage compartment width
maximum
1054
between the wheel arches
978
Height of luggage compartment
727
opening
Wheelbase
2830
Turning circle diameter3)
11.92
1) Version with body kit.
2) At kerb weight with driver.
3) In metres.
Technical data
297
Installation dimensions of trailer
towing equipment
with removable coupling ball bar
All dimensions refer to factory-fitted
towing equipment.
Dimension
mm
A
602
B
540
C
380
D
998
E
495
F
492.5
G
486.5
H
238
9 Warning
Only use towing equipment approved for
your vehicle. We recommend entrusting
retrofitting of towing equipment to a
workshop.
298
