TO THE OWNER

This instruction manual describes how to maintain your tractor in good condition and how to
operate it safely and correctly. Please read this manual carefully before using the tractor. Keep
this manual close to your tractor, after you have read through it. If you lose or damage this
manual, ask your YANMAR dealer for a new manual right away.

IMPROVEMENT
Sometimes parts are changed to improve or upgrade the features of the tractor, or for other
reasons. Therefore, the parts shown in this manual may not apply to your tractor.

Note:

  All data are subject to change without prior warning. Some illustrations and photographs

may show optional accessories.

  A Roll-over Protective Structure (ROPS) is optional.



SYMBOLS USED



1. Safety-alert Symbol

This is the safety-alert symbol.  When you see
this symbol on your tractor or in this manual, be
alert to the possibility of personal injury and
carefully read the messages that follow.





2. Signal Words

The signal words "DANGER" "WARNING"
"CAUTION" are used with the safety-alert symbol.

(1) "DANGER" indicates an imminently hazardous

situation which, if not avoided, will result in death
or serious injury.

(2) "WARNING" indicates a potentially hazardous

situation which, if not avoided, could result in
death or serious injury.

(3) "CAUTION" indicates a potentially hazardous

situation which, if not avoided, could result in
minor or moderate injury.

3. Service instructions



(1) This stop symbol indicates important proper

operation or service messages in this manual.
When you see this symbol, carefully read the
messages that follow.

IMPORTANT

(2) “NOTE” describes precautions to take while

working.



NOTE

4. Measurements





This tractor is of metric design.  All hardware are
therefore metric (ISO).  Make sure to use the
specified metric hardware when service becomes
necessary.





5. Direction

Right-hand and Left-hand sides of the tractor are
determined by facing in the direction of the tractor
forward travel.







EF494T OM

1





SAFETY INSTRUCTIONS

 DANGER



Read these instructions carefully.
Important instructions are given for the safe operation
and servicing of the tractor.
Failure to follow these instructions is likely to result in an
accident involving death or serious injury.








STUDY THE TRACTOR AND IMPLEMENTS


Do not permit anyone unfamiliar with the tractor or the
operations of its implements to use the machine.
The operator’s manual should be considered a
permanent part of the tractor and should remain with the
tractor.







Know the positions and functions of all controls and the
meaning of any identification symbols on your controls,
gauges, and indicators before attempting to operate the
tractor.

Know how to stop the engine in an emergency.





Make sure you understand the capabilities, operating
characteristics and limitations of the tractor and
implement, such as maximum ballast weight, hydraulic
lifting capacity, speed, turning radius, operating
clearances etc.

Do not add extra ballast weight to compensate for a load
that is too heavy.







EF494T OM

2

PROTECT OPERATOR SAFELY


Install an approved Roll-over Protective Structure
(ROPS) for safe operation. If a tractor rolls over without
a ROPS, death or serious injury is likely.

Always fasten the seat belt while operating the tractor
with Roll-over Protective Structure (ROPS) up.

Do not use the seat belt if the foldable Roll-over
Protective Structure (ROPS) is in the folded position or
the tractor does not have the Roll-over Protective
Structure (ROPS).








Extreme caution is required when operating a tractor
around trees or other overhead obstructions, such as
guy wires or power lines. Interference between the
ROPS and these obstructions may cause the tractor to
tip backwards.





Do not modify any structural portions of the ROPS by
welding, bending, grinding or cutting them. If any
component of the ROPS is damaged or involved in a
rollover incident, replace it with a complete new cage.
Do not attempt to repair the original one. Damaged or
modified structural parts impair the strength of the
ROPS and may lead to injury.





Avoid loose fitting or baggy clothing, torn clothing,
bulging pockets, frayed edges or heavy cuffs. Loose
frayed and bulky clothing can easily become entangled
in rotating parts. Wear work clothes and work shoes or
boots. Also you may need a: SAFETY HELMET,
SAFETY SHOES, EYE PROTECTION, HEAVY DUTY
GLOVES, HEARING PROTECTION, REFLECTIVE
CLOTHING, OR A RESPIRATOR/FILTER MASK.
Wear whatever safety gear and clothing is necessary for
the job.





Prolonged exposure to loud noise can cause impairment
or permanent loss of hearing. Wear a suitable hearing
protective device such as ear protectors or earplugs to
protect against objectionable or uncomfortable noise.






EF494T OM

3

BEFORE OPERATING

Do not operate the tractor when tired, sick, sleepy,
drunk, feeling overworked, taking medicine, pregnant,
suffering from mental disease or if other improper
conditions are present. These conditions impair a
person’s skill and judgment. When you begin feeling
tired while operating the tractor, take a 10-minute break
to stretch, walk about, lie down or snack. Do not
continue if you still feel tired after taking a break.







Remove oil, grease or mud from the hand rails, steps,
pedals, controls, and floor to avoid slips or loss of
control.

In winter, scrape off any ice or snow on the handrails,
steps, pedals, controls, and floor.





To attach or remove an implement, refer to the
implement and tractor manufacturer’s manuals for the
proper procedures.

To unhitch an implement, move to a level area, lower the
implement to the ground and then block the equipment
in position before unhitching. If an implement has
wheels, block them to prevent it from rolling.





Make sure

(1) The tractor and implements are in good condition

and properly adjusted.

(2) To check for loosened bolts, adequate lubricants,

damaged or under-inflated tires, safety shields and
devices, steering and braking linkages, hydraulic
leaks, etc. Refer to this manual for more detailed
information.

(3) That implements are properly attached and hooked

up. Check that the PTO U-joint yoke and locking
devices are securely latched on their shafts.

(4)

That the tractor’s PTO speed matches the

implement’s specifications.
