Model MA TOW Tractor. Manual - part 51
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-2
p. 89
25-25
----- ----------------
#6
hose clamp
Ref. As Req'd
25-26
246 d7tz-9350d
-----------------
fuel pump (without filter)
1
Note 7
127 6830
T6-1001-115
fuel pump (with filter)
1
"
127 cg20
T6-1201-211
filter cartridge, fuel pump
1
"
110 2641725
T6-1200-115
fuel pump, perkins diesel engine (use 2641728)
1
Note 4
256 c0149206500
-----------------
fuel pump, cummins/Onan Diesel engine
1
Note 5
388 40-2502653
-----------------
Fuel pump, electric, hercules diesel engine
Note 8
25-
----- ----------------
T6-9011-309
vent, fuel pump, Gasoline
1
As Req'd
25-27
246 d8te-9b27bac
T6-6005-103
fuel line, gasoline engine
1
Note 7
25-28
246 d7tz-9324e
-----------------
fuel line, gasoline engine
1
"
25-29
246 epgd7tz-9155e -----------------
fuel inlet filter, gasoline engine
1
"
----- ----------------
200x5
connector, gasoline engine
1
"
110 2656617
-----------------
fuel filter, perkins diesel engine
1
Note 4
110 26560017
-----------------
Cartridge kit, separator, pre-lift pump, perkins diesel engine
1
"
----- ----------------
T6-1207-101
fuel filter mounting plate, perkins diesel engine
1
"
256 c0149175500
-----------------
fuel filter, cummins/onan diesel engine
1
Note 5
256 c0149175400
-----------------
element, fuel filter, cummins/onan diesel engine
1
"
246 d8te-9827bac
T6-6005-103
Fuel Line, Pump to Carb
1
“
25-30
----- ----------------
T6-9003-509
fuel hose, gasoline engine
1
Note 7
25-31
144 r82873
T6-4027-115
collar
1
001 & Up
25-
390 62008
T6-7200-060
ether start kit
1
As Req'd
25-
----- ----------------
T6-7200-070
Fuel Return extension pipe
1
Note 8
25-
102 020-306
T6-7200-020
Low Fuel Switch
1
As Req'd
FUEL SYSTEMS ON TRACTORS PRIOR TO SERIAL NUMBER 024 MAY VARY SLIGHTLY.
4. Used on all tractors equipped with Perkins 4.236 diesel engine.
5. Used on all tractors equipped with Cummins/Onan diesel engine.
6. Used on all tractors equipped with Ford 300 C.I.D. gasoline engine.
7. Used as required on tractors equipped with Ford 300 C.I.D. gasoline engine.
8. Used on all tractors equipped with Hercules diesel engine.
Fig &
Co Vendor Part
Tug Part Number
Description
Qty
Effective
Ind#
de Number
