89

MAINTENANCE

Cooling System

Bleeding the Cooling System

Bleed the cooling system at the intervals outlined in the Periodic Main-
tenance Table beginning on page 72. Perform the bleeding procedure
when the engine is cold.

1. Remove the pressure cap and fill the coolant bottle with properly

mixed coolant to the maximum mark.

2. Elevate the front end of the machine slightly to aid in bleeding of

the heat exchangers.

3. Remove the bleed screw from the water outlet manifold and/or the

thermostat housing. Allow the coolant to bleed through the system
until it runs out the bleed holes. Reinstall the bleed screw into the
manifold.

4. Add coolant to the coolant bottle to the maximum mark.

5. Start the engine and run at a fast idle for two to three minutes.

Loosen the bleed screw occasionally to purge any trapped air.

6. Stop the engine and check the coolant bottle level. Fill as required.

7. Feel the heat exchangers under the running boards. If the system is

bled properly, they'll be warm to the touch. If they're not, repeat step
5. Lift the front of the machine slightly to assist in the bleeding.

8. Replace the pressure cap and carefully lower the front end of the

machine.

90

MAINTENANCE

Drive Chain Tension

Check drive chain tension weekly
and before each long trip. To
obtain correct chain tension:

1. Rotate the driven clutch

counterclockwise to move all
chain slack to the tensioner
side. Lock the brake lever
lock, or have an assistant
hold the brake lever firmly.

2. Loosen the adjuster bolt jam

nut.

3. Finger tighten the adjuster

bolt until it can no longer be
adjusted by hand, then back
off 1/4 turn.

4. Tighten the jam nut while

holding the adjuster bolt.
Torque to 21 ft. lbs. (28 Nm).

5. Release the brake lever lock.

Adjuster

Bolt

Jam

Nut

91

MAINTENANCE

Brakes

n

Hydraulic Brake Inspection

Inspect the brake lever travel before each use of the snowmobile. See
page 51.

Brake pads must be replaced when the brake pad material becomes thin-
ner than the backing plate, approximately 1/16" (1.5mm). A kit is avail-
able for replacing brake pads. See your dealer.

WARNING

Brake failure during operation can result in serious injury or death. Properly

functioning brakes are vital to your safety. Be sure the brake pads do not

drag on the disc and that brake lever travel is not excessive.
Always replace brake pads when the brake pad material becomes thinner

than the backing plate, approximately 1/16" (1.5mm).

92

MAINTENANCE

Brakes

Brake Components

• Brake  Disc

• Bleed Screw

• Brake  Line

• Brake Caliper

• Brake Pad Material -

Replace when thickness is
less than 1/16" (1.5mm).

Excessive Lever Travel

Hydraulic brakes are self-
adjusting, but if excessive
brake pad clearance develops
(see page 91) bring the snow-
mobile to an authorized
Polaris dealer for inspection
and adjustment.

Brake Disc

Bleed Screw

Brake Pad

Material

Brake Line

Brake

Caliper
