1.14
Model Specifications
2007 600 HO IQ Touring CFI
Model Number: S07PT6HS / S07PT6HE
Engine
Engine Type
Liberty Liquid-Cooled /
Case Reed Induction
Model Number
S3206-6044-PF6H
Displacement / # Cylinders
599cc / 2
Bore (inches/mm)
3.04 / 77.25
Stroke (inches/mm)
2.52 / 64
Piston to Cylinder Clearance
(inches/mm)
.004 - .006 / .105 - .159
Installed Ring Gap
(inches / mm)
.014 - .020 / .356 - .508
Operating RPM ±200
8250
Idle RPM
1700
Engagement RPM ±200
3800
Exhaust Valve Spring
Purple
Fuel Delivery
Type
Cleanfire Direct Injection
Throttle Body Marking
1203213
Throttle Body Bore
46mm
TPS Voltage @ Idle
0.95 +/- 0.01 Vdc
Fuel Pressure - PSI (bar)
58 (4.0)
Recommended Fuel Octane
(R+M/2)
91 Non-Oxygenated
Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH
DRIVEN CLUTCH
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-62
BLK / GRN
(120 / 340)
(7042083)
RED/BLK
(140 / 240)
(7043058)
64/42.36
LW ER
22:43-78
600-1200
(2000-4000)
10-60
56/42 - .36
LW ER
1200-1800
(4000-6000)
10-58
1800-2400
(6000-8000)
10-56
21:44-78
2400-3000
(8000-10000)
10-54
3000-3600
(10000-12000)
10-AL
Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)
General
Width (in/cm)
48 / 121.9
Length (in/cm)
129 / 327.7
Height (in/cm)
53 / 134.6
Estimated Dry Weight
(lb/kg)
574 / 260.6
Fuel (Gallons / Liters)
11.7 / 44.3
Oil (Quarts / Liters)
3.4 / 3.2
Cooling System Capacity
(Quarts / Liters)
6.3 / 6
Brake Fluid
DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211080
1.438 / 3.65
28_
46.625 / 118.4
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
22
43
78
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
400
Ignition Timing
18_ @1700 RPM
Coolant Temp = 120_F (49_C)
Spark Plug Gap in.(mm)
.027 (.70)
Spark Plug
Champion RN57YCC
Track
Width - Inches (cm)
15 (38)
Length - Inches (cm)
136 (345)
Lug Height - Inches (cm)
1 (2.5)
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft
3/4
″
- 1.0
″
(1.9 - 2.5cm)
