Polaris TRACTOR Sportsman 570 6X6 (2018 year). Manual - part 30

123

MAINTENANCE

Vehicle Immersion

4. Turn the ignition key past the

PARKING LIGHTS position to

engage the starter. Engage the

starter for only 2-3 seconds.

5. Dry the spark plug. Reinstall the

plug or install a new plug.

6. Torque to specification. See page

120.

7. Attempt to start the engine. If

necessary, repeat the drying

procedure.

8. Have the vehicle serviced

promptly, whether you succeed

in starting it or not. Your

POLARIS dealer can assist.

9. If water has been ingested into the PVT, follow the procedure on

page 127 for drying out the PVT.

124

MAINTENANCE

Spark Arrester

Failure to heed the following warnings while servicing the spark arrester could

result in serious injury or death. Never run the engine in an enclosed area.

Remove any combustible materials from the area. Wear eye protection and

leather work gloves. Do not stand behind or in front of the vehicle while purging.

Never go under the vehicle while it's inclined.
The exhaust system can get extremely hot. Do not perform service on the spark

arrester while the system is hot. Allow components to cool sufficiently before

proceeding.

Occasionally, the spark arrester may accumulate carbon, which can

restrict the exhaust if left unattended. Purge the spark arrester.
1. Position the vehicle on a level surface.
2. Place the transmission in PARK.

3. Remove the arrester

clean-out plug from the

bottom of the muffler.

4. Start the engine.
5. Quickly squeeze and

release the throttle lever

several times to purge

carbon from the system.

125

MAINTENANCE

Spark Arrester

6. If carbon comes out of the

exhaust, cover or plug the

exhaust outlet. Wear protective

gloves.

7. Lightly tap on the exhaust pipe

with a rubber mallet while

repeating step 5.

8. If particles are still suspected to

be in the muffler, elevate the

rear of the vehicle 30 cm higher

than the front. See page 85. Block the front wheels to prevent

rolling.

9. Place the transmission in PARK. Repeat steps 5 to 7 until no more

particles are expelled.

10. Stop the engine. Allow the arrester to cool.
11. Reinstall the arrester plug and remove the exhaust outlet cover or

plug.

126

MAINTENANCE

PVT System

Do not modify any component of the PVT system. Doing so may reduce its

strength so that a failure may occur at a high speed. The PVT system has been

precision balanced. Any modification will cause the system to be out of balance,

creating vibration and additional loads on components.
The PVT system rotates at high speeds, creating large amounts of force on

clutch components. Extensive engineering and testing has been conducted to

ensure the safety of this product. However, as the owner, you have the following

responsibilities to make sure this system remains safe:
• Always follow all recommended maintenance procedures. Always look for

and remove debris inside and around the clutch and vent system when

replacing the belt.

• Perform service as outlined in the owner's manual. Your POLARIS dealer can

assist.

• This PVT system is intended for use on POLARIS products only. Do not

install it in any other product.

• Always make sure the PVT housing is securely in place during operation.
