FEATURES

1. Fuel Filler Cap
2. Brake Lever
3. MFD Gauge
4. Ignition Switch
5. Engine Stop Switch
6. Throttle Control
7. Recoil Starter Handle
8. Parking Brake Lock
9. Handlebar Grip Warmer Switch
10. Thumbwarmer Switch
11. Electronic Reverse Button
12. Mode Switch
13. Headlight Dimmer Switch

FEATURES

Storage Bag/Tool Kit

A storage bag is located under the seat. The left portion of the bag is

designed to store the tool kit. The tool kit includes tools and a foam tool

holder. The right side of the bag can be used to stow other items.

Adjustable Headlights

Move the headlight adjuster to the

left to adjust the headlight beam

upward. Move the adjuster to the

right to adjust the beam downward.

Right

Compartment

(Storage)

Left

Compartment

(Tool Kit)

Fastener

Straps

Belt

Removal

Tool

Spare

Plugs

Fuel

Resistor

Spark Plug

Wrench

Spare

Wrench

Foam Tool

Holder

Suspension

Gauge

Down

FEATURES

Detonation Elimination Technology (DET)

The DET system prevents damage to the engine from detonation by

going into an engine protection mode whenever the DET system is

active. Depending on the level of detonation encountered, the check

engine light could be solid, it could flicker or it could flash steadily.

When excessive detonation is detected,

the check engine light will come on solid,

or it may flicker, and you may notice

decreased engine performance and RPM

when the DET system is activated. In

most cases this is temporary and the oper-

ator does not need to take any action. The

engine will return to its normal perfor-

mance automatically.
If severe detonation occurs, the check engine light will begin to flash

steadily and the gauge indicator will read “dET” (see illustration). The

engine will enter a limp home mode and RPM will be limited to 6500

RPM. The engine will remain in this mode until it is shut down and

restarted.
The most likely causes of severe detonation are outlined in the trouble-

shooting table below.

DET Troubleshooting

Check Engine Light

Indicates

Off

Mild detonation may be detected

Solid or Flickering

Excessive detonation detected

Steady Flashing

Severe detonation detected, RPM will be limited

Cause of DET Activation

Solution

Poor quality fuel

Replace with higher quality fuel

Incorrect ethanol/non-ethanol fuel

resistor installed

Verify correct fuel resistor for fuel type

in tank

Low fuel/no fuel in tank

Refuel with recommended fuel

Water in fuel

Replace with recommended fuel

Plugged fuel filter

See your Polaris dealer for service

Alcohol-based fuel additive used with

Ethanol fuel

Do not add deicers or additives that

contain any form of alcohol while

using up to 10% ethanol fuel

Improper engine modifications

Do not modify the engine

FEATURES

Instrument Cluster

The instrument cluster contains

indicator lights and the rider infor-

mation center. The information cen-

ter can be controlled by either the

MODE and SELECT buttons on the

instrument cluster or by the MODE/

SET switch on the left handlebar.

NOTICE: Certain products will damage

the lens and other plastic sur-

faces. Do not use alcohol to

clean the instrument cluster.

Immediately clean off any

gasoline that splashes on the

instrument cluster.

Rider Information

Center

Check Engine

Indicator

High Beam

Indicator

Low Oil

Indicator

Over-

Temperature

Indicator

Park Brake

Indicator

Reverse

Indicator

MODE

Button

SELECT

Button

Mode/Set

Switch

SET

MOD
