120

MAINTENANCE

Vehicle Immersion

NOTICE: If your vehicle becomes immersed, major engine damage can result

if the machine is not thoroughly inspected. Take the vehicle to your

POLARIS dealer before starting the engine.

If it's impossible to take your vehicle to a dealer before starting it,

follow the steps outlined below.
1. Move the vehicle to dry land.
2. Check the air box. If water is present, dry the air box and replace the

filter with a new filter.

3. Remove the spark plug.
4. Turn the engine over several times.
5. Dry the spark plug and reinstall it, or install a new plug.
6. Attempt to start the engine. If necessary, repeat the drying

procedure.

7. Take the vehicle to your POLARIS dealer for service as soon as

possible, whether you succeed in starting it or not.

8. If water has been ingested into the PVT follow the procedure on

page 107 for drying.

121

MAINTENANCE

Battery

Battery electrolyte is poisonous. It contains sulfuric acid. Serious burns can

result from contact with skin, eyes or clothing.
Antidote:
External: Flush with water.
Internal: Drink large quantities of water or milk. Follow with milk of magnesia,

beaten egg, or vegetable oil. Call physician immediately.
Eyes: Flush with water for 15 minutes and get prompt medical attention.
Batteries produce explosive gases. Keep sparks, flame, cigarettes, etc. away.

Ventilate when charging or using in an enclosed space. Always shield eyes

when working near batteries. KEEP OUT OF REACH OF CHILDREN.

Your vehicle may have either a sealed battery, which requires little

maintenance, or a conventional battery. A sealed battery can be

identified by its flat covers on the top of the battery. A conventional

battery has six filler caps on the top of the battery.
Always keep battery terminals and connections free of corrosion. If

cleaning is necessary, remove the corrosion with a stiff wire brush.

Wash with a solution of one tablespoon baking soda and one cup water.

Rinse well with tap water and dry off with clean shop towels. Coat the

terminals with dielectric grease or petroleum jelly. Be careful not to

allow cleaning solution or tap water into a conventional battery.

WARNING

122

MAINTENANCE

Battery

Improperly connecting or disconnecting battery cables can result in an explosion

and cause serious injury or death. When removing the battery, always

disconnect the negative (black) cable first. When reinstalling the battery, always

connect the negative (black) cable last.

Battery Removal

1. Remove the seat. See page 29.
2. Remove the three (3) bolts securing the cup holder panel to the

frame. Lift the panel to access the battery.

3. Remove the battery hold-down strap screws and remove the strap.
4. On conventional batteries, remove the battery vent tube.
5. Disconnect the black (negative) battery cable first.
6. Disconnect the red (positive) battery cable last.
7. Lift the battery out of the vehicle. Be careful not to tip a

conventional battery sideways, which could spill electrolyte.

NOTICE: If electrolyte spills, immediately wash it off with a solution of one

tablespoon baking soda and one cup water to prevent damage to the
vehicle.

WARNING

Battery

Battery Hold-Down Strap

Cup Holder Panel Bolts

123

MAINTENANCE

Battery

Battery Installation

Using a new battery that has not been fully charged can damage the

battery and result in a shorter life. It can also hinder vehicle

performance. Follow the battery charging instructions on page 125

before installing the battery.
An optional extreme use battery may be available for your model. If the

performance of the factory-installed battery is inadequate due to

operation in extreme cold or due to extended use of multiple electrical

accessories, please see your POLARIS dealer. Ask your dealer to

provide any installation procedures that may differ for an extreme use

battery.
1. Ensure that the battery is fully charged.
2. Place the battery in the battery holder.
3. On conventional batteries, install the battery vent tube (sealed

batteries do not have a vent tube). The vent tube must be free of

obstructions and securely installed. Route the tube away from the

frame and vehicle body to prevent contact with electrolyte.

WARNING! Battery gases could accumulate in an improperly installed vent tube

and cause an explosion, resulting in serious injury or death. Always ensure that

the vent tube is free of obstructions and is securely installed as recommended.

4. Coat the terminals with dielectric grease or petroleum jelly.
5. Connect and tighten the red (positive) cable first.
6. Connect and tighten the black (negative) cable last.
7. Install the battery hold-down strap and tighten the screws.
8. Verify that cables are properly routed.
9. Reinstall the cup holder panel. Tighten the bolts.
10. Reinstall the seat.
