Polaris ACE 570 (2018 year). Manual - part 22

92

MAINTENANCE

Engine Oil

Always check and change the oil at the intervals outlined in the Periodic

Maintenance Chart beginning on page 85. Always use the recommended

engine oil. See page 91.

Oil Check

The oil dipstick and fill tube is located on

the engine, behind the passenger seat.

Access the dipstick through the right rear

wheel well.
1. Position the vehicle on a level surface.
2. Place the transmission in PARK.
3. Always clean away all dirt and debris

from the dipstick area before removing

the dipstick. Remove the dipstick.

Wipe it dry with a clean cloth.

4. Reinstall and tighten the dipstick.
5. Remove the dipstick and

check the oil level.

6. Add the recommended fluid as

needed. Maintain the oil level

in the safe range between the

FULL and ADD marks. Do

not overfill.

7. Reinstall and tighten the

dipstick.

Dipstick

Full

Add

93

MAINTENANCE

Engine Oil

Oil and Filter Change

Always check and change the oil at the intervals outlined in the Periodic

Maintenance Chart beginning on page 85. Always change the oil filter

whenever changing oil.
The engine drain plug is located on the

bottom of the crankcase.
1. Position the vehicle on a level surface.

Place the transmission in PARK.

Apply the brakes.

2. Start the engine. Allow it to idle for

two to three minutes. Stop the engine.

3. Clean the area around the drain plug.

CAUTION! Hot oil can cause burns to skin. Do

not allow hot oil to contact skin.

4. Place a drain pan beneath engine

crankcase and remove the drain plug.

5. Allow the oil to drain completely.
6. Reinstall the sealing washer on the drain plug.

Tip: The sealing surfaces on drain plug and crankcase should be clean and free

of burrs, nicks or scratches.

7. Reinstall the drain plug. Torque to 12 ft. lbs. (16 Nm).

Drain Plug Access

94

MAINTENANCE

Engine Oil

Oil and Filter Change

8. Using a cap-style oil filter

wrench, turn the filter

counter-clockwise to remove

it.

9. Using a clean dry cloth, clean

the filter sealing surface on

the crankcase. Make sure the

old filter o-ring is completely

removed.

10. Lubricate the o-ring on the

new filter with a film of fresh

engine oil. Check to make

sure the o-ring is in good

condition.

11. Install the new filter and turn by hand until the filter gasket contacts

the sealing surface, then turn and additional 1/2 turn.

12. Always clean away all dirt and debris from the dipstick area before

removing the dipstick. Remove the dipstick and fill the sump with

two quarts (1.9 l) of recommended oil.

13. Reinstall and tighten the dipstick.
14. Make sure the transmission is in PARK. Apply the brakes.
15. Start the engine. Allow it to idle for one to two minutes.
16. Stop the engine. Inspect for leaks.
17. Re-check the oil level on the dipstick and add oil as necessary to

bring the level to the upper mark on the dipstick.

18. Dispose of used filter and oil properly.

Oil Filter

95

MAINTENANCE

Gearcases

Demand Drive Unit (Front Gearcase)

Always check and change the fluid at the intervals outlined in the

Periodic Maintenance Chart beginning on page 85. Refer to the

Gearcase Specifications Chart on page 98 for recommended lubricants,

capacities and torque specifications.

Fluid Check
The fill plug is located on the

bottom right side of the

demand drive unit. Access the

fill plug through the right front

wheel well. Maintain the fluid

level even with the bottom

thread of the fill plug hole.
1. Position the vehicle on a

level surface.

2. Remove the fill plug.

Check the fluid level.

3. Add the recommended

fluid to the bottom thread

of the fill plug hole.

4. Reinstall the fill plug.

Torque to specification.

Fill Level

Fill Plug

Drain Plug
