29

FEATURES

Fuel Resistor

This snowmobile is equipped with a feature that allows the engine con-
troller to select the proper operating software based on the type of fuel
being used. See pages 59-60 for fuel information and recommendations.

The ECU fuel designation connector must have the “NON-ETHANOL
160 OHM” resistor installed when using non-ethanol gasoline.

When using ethanol, MTBE, or other forms of oxygenated gasoline, the
“10% ETHANOL 24 OHM” resistor must be connected.

Whenever in doubt of your fuel purchase, use the “10% ETHANOL 24
OHM” resistor as a safeguard.

The resistor is installed into the wiring harness on the left side of the
snowmobile just above the top of the oil bottle (see photo).

NOTICE: Engine damage may occur if ethanol fuel is used while the non-etha-

nol fuel resistor is installed. The check engine light may also display in
this condition as this could cause detonation.

10

%

   ETHANOL

24  OHM

NON-ETHANOL

160  OHM

Resistor

NON-ETHANOL GASOLINE

91+ OCTANE

(Maximum Performance)

ETHANOL, MTBE, OR OTHER

OXYGENATED GASOLINE

(Factory Delivery)

ANY FUEL WITH ETHANOL

or LESS THAN 91 OCTANE

(87 Octane Minimum)

30

FEATURES

Detonation Elimination Technology (DET)

The DET system prevents damage to the engine from detonation by
going into an engine protection mode whenever the DET system is
active.

When excessive detonation is detected,
the check engine light will illuminate
and you may notice decreased engine
performance and RPM when the DET
system is activated. In most cases this
is temporary and the operator does not
need to take any action. The engine
will return to its normal performance
automatically.

If severe detonation occurs, the check engine light will begin to flash
steadily and the gauge indicator will read “dET” (see illustration). The
engine will enter a limp home mode and RPM will be limited to 6500
RPM. The engine will remain in this mode until it is shut down and
restarted.

Check Engine Light

Indicates

Solid or Flickering

Excessive detonation detected

Steady Flashing

Severe detonation detected, RPM will be limited

31

FEATURES

Detonation Elimination Technology (DET)

The most likely causes of severe detonation are outlined in the trouble-
shooting table below.

DET Troubleshooting

Cause of DET Activation

Solution

Poor quality fuel

Replace with higher quality fuel

Incorrect ethanol/non-ethanol fuel

resistor installed

Verify correct fuel resistor for fuel type

in tank

Low fuel/no fuel in tank

Refuel with recommended fuel

Water in fuel

Replace with recommended fuel

Plugged fuel filter or tank pick-up sock See your POLARIS dealer for service

Alcohol-based fuel additive used with

Ethanol fuel

Do not add deicers or additives that
contain any form of alcohol while
using up to 10% Ethanol fuel

Improper engine modifications

Do not modify the engine

32

FEATURES

Instrument Cluster

The instrument cluster contains
indicator lights and the rider infor-
mation center. The information cen-
ter can be controlled by either the
MODE and SELECT buttons on the
instrument cluster or by the MODE/
SET switch on the left handlebar or
console.

NOTICE: Certain products will damage

the lens and other plastic sur-
faces. Do not use alcohol to
clean the instrument cluster.
Immediately clean off any
gasoline that splashes on the
instrument cluster.

Rider Information

Center

Check Engine

Indicator

High Beam

Indicator

Low Oil

Indicator

Over-

Temperature

Indicator

Park Brake

Indicator

Reverse

Indicator

MODE

Button

SELECT

Button

Mode/Set Switch

(RMK)

SET

MODE

Mode/Set Switch

(PRO-RMK/ASSAULT)
