20

SAFETY

Operator Safety

Windchill/Temperature Charts

The following information is provided to help you determine when tem-
peratures become dangerous for riding.

WINDCHILL CHART (°F)

WINDCHILL CHART (°C)

Wind

Speed

in

MPH

Actual Thermometer Reading (°F)

40

35

30

25

20

15

10

5

0

-5

-10 -15 -20 -25 -30 -35 -40 -45

Equivalent Temperature (°F)

Calm

40

35

30

25

20

15

10

5

0

-5

-10 -15 -20 -25 -30 -35 -40 -45

5

36

31

25

19

13

7

1

-5

-11 -16 -22 -28 -34 -40 -46 -52 -57 -63

10

34

27

21

15

9

3

-4

-10 -16 -22 -28 -35 -41 -47 -53 -59 -66 -72

15

32

25

19

13

6

0

-7

-13 -19 -26 -32 -39 -45 -51 -58 -64 -71 -77

20

30

24

17

11

4

-2

-9

-15 -22 -29 -35 -42 -48 -55 -61 -68 -74 -81

25

29

23

16

9

3

-4

-11

-17 -24 -31 -37 -44 -51 -58 -64 -71 -78 -84

30

28

22

15

8

1

-5

-12 -19 -26 -33 -39 -46 -53 -60 -67 -73 -80 -87

35

28

21

14

7

0

-7

-14 -21 -27 -34 -41 -48 -55 -62 -69 -76 -82 -89

40

27

20

13

6

-1

-8

-15 -22 -29 -36 -43 -50 -57 -64 -71 -78 -84 -91

45

26

19

12

5

-2

-9

-16 -23 -30 -37 -44 -51 -58 -65 -72 -79 -86 -93

50

26

19

12

4

-3

-10 -17 -24 -31 -38 -45 -52 -60 -67 -74 -81 -88 -95

55

25

18

11

4

-3

-11 -18 -25 -32 -39 -46 -54 -61 -68 -75 -82 -89 -97

60

25

17

10

3

-4

-11 -19 -26 -33 -40 -48 -55 -62 -69 -76 -84 -91 -98

Frostbite in >> 30 min.

10 min.

5 min.

Wind

Speed

in

Km/h

Actual Thermometer Reading (°C)

5

2

-1

-4

-7

-10 -13 -16 -19 -22 -25 -28 -31 -34 -37 -40 -43 -46

Equivalent Temperature (°C)

Calm

5

2

-1

-4

-7

-10 -13 -16 -19 -22 -25 -28 -31 -34 -37 -40 -43 -46

8

3

0

-4

-7

-11 -14 -18 -22 -25 -29 -32 -36 -39 -43 -46 -50 -53 -57

16

2

-2

-6

-10 -13 -17 -21 -24 -28 -32 -36 -39 -43 -47 -50 -54 -58 -62

24

1

-3

-7

-11

-15 -19 -22 -26 -30 -34 -38 -42 -45 -49 -53 -57 -61 -65

32

0

-4

-8

-12 -16 -20 -24 -28 -32 -36 -39 -43 -47 -51 -55 -59 -63 -67

40

-1

-5

-9

-13 -17 -21 -25 -29 -33 -37 -41 -45 -49 -53 -57 -61 -65 -69

48

-1

-5

-9

-13 -18 -22 -26 -30 -34 -38 -42 -46 -50 -54 -58 -62 -66 -70

56

-2

-6

-10 -14 -18 -22 -26 -31 -35 -39 -43 -47 -51 -55 -59 -64 -68 -72

64

-2

-6

-10 -15 -19 -23 -27 -31 -35 -40 -44 -48 -52 -56 -61 -65 -69 -73

72

-2

-7

-11

-15 -19 -23 -28 -32 -36 -40 -45 -49 -53 -57 -61 -66 -70 -74

80

-3

-7

-11

-15 -20 -24 -28 -33 -37 -41 -45 -50 -54 -58 -62 -67 -71 -75

88

-3

-7

-12 -16 -20 -24 -29 -33 -37 -42 -46 -50 -55 -59 -63 -67 -72 -76

96

-3

-8

-12 -16 -21 -25 -29 -34 -38 -42 -47 -51 -55 -60 -64 -68 -73 -77

Frostbite in >> 30 min.

10 min.

5 min.

21

SAFETY

Safety Labels and Locations

Warning labels have been placed on the snowmobile for your protection.
Read and follow the instructions of the labels and other warnings on the
snowmobile carefully. If any of the labels depicted in this manual differ
from the labels on your snowmobile, always read and follow the instruc-
tions of the labels on the snowmobile.

If any label becomes illegible or comes off, contact your POLARIS
dealer to purchase a replacement. Replacement safety labels are pro-
vided by POLARIS at no charge. The part number is printed on the
label.

Clutch Warning

This warning label is found on the oil bottle:

WARNING

Do not operate engine with hood or side panels open.

Do not attempt adjustment with engine running.

Do not operate engine with the clutch guard removed.

Never run engine with drive belt removed.

Never service clutches yourself. See your dealer.

Pressure Cap Warning

This warning label is found on the pressure cap of applicable liquid
cooled models:

WARNING

Do not open hot. Test or replace when changing coolant. Press
down and turn to release cap. 13 PSI

22

SAFETY

Safety Labels and Locations

Track Warning

WARNING

Stay clear of track. Do not sit
on seat back. Entanglement
with the track or a fall from
seat back may result in
severe injury or death.

No Passenger Warning/Fuel Recommendation Label

WARNING

This vehicle is designed for operator only. NO PASSENGER.

Reverse Warning

WARNING

Reverse operation, even at low
speeds, can cause loss of control
resulting in serious injury or
death. To avoid loss of control,
always:

• Look behind before and while

backing up.

• Avoid sharp turns.

• Shift to or from reverse only

when stopped.

• Apply throttle slowly.

NOTE: For more information, see
Owner's Manual.

If electric reverse:

• Machine stopped and engine at

idle, push yellow button on LH
control to reverse. Flashing
light on dash indicates reverse operation.

• Push button again to return to forward.

Track

Warning

Reverse Warning

No Passenger Warning/Fuel

Recommendation Label

23

SAFETY

Safety Labels and Locations

Operation Warning

WARNING

• To avoid serious injury or death,

read and understand all warn-
ings and the Owner's Manual
before operation. If manual is
missing, contact a POLARIS
dealer for a replacement.

• This vehicle is capable of high

speeds. Buried objects or uneven
terrain can cause loss of control.
Reduce speed and use extreme
caution when operating in unfa-
miliar terrain.

• Excessive speed, especially at night or with limited visibility, can

result in insufficient time for you to react to terrain changes, to
avoid unexpected obstacles, or to stop safely.

• Never consume alcohol or drugs before or while operating this vehi-

cle.

• In an emergency, push down the Auxiliary Shut-Off Switch, located

on the top of the throttle control assembly, to stop the engine. Then
pull the brake lever to stop.

• Always wear an approved helmet, eye protection, and adequate

clothing while operating this vehicle.

• This vehicle is designed for adult use only. Check local laws for age

requirements.

• When operating with a passenger (on approved models only)

reduce speed and allow extra space for steering and stopping. A
passenger reduces your ability to control the vehicle.

• When operating on hard-packed snow, ice, or when crossing roads,

steering and braking ability are greatly reduced. Reduce speed and
allow extra space to turn or stop.

• To maintain vehicle control on ice or hard-packed surfaces, you

should have a proper balance of ski carbides to track studs. See
Owner's Manual for proper use of traction products.

• Repeated stops from high speed may cause fading or sudden loss

of braking ability.

• Parking brake may relax when used for long periods. Do not leave

brake engaged for more than five minutes.

• Before starting engine, check throttle, brake, and steering for proper

operation. Make sure hood and side panels are latched. Be seated
and in position to control the vehicle.

Oil injection system: Use unmixed fuel only. Check oil level when
refueling.

Operation

Warning
