76

OPERATION

Carburetion

Proper carburetor adjustment is critical. A lean mixture (too much air,

too little fuel) may result in piston burning, bearing failure, or complete

engine failure.  A rich mixture (too much fuel, too little air) may foul

plugs and cause generally poor engine performance.

A lean mixture may be caused by things like fuel line restrictions, for-

eign matter in the carburetor or clogged fuel filters. A rich mixture may

be caused by snow build-up on the pre-filter in the air intake system.

Either condition may be caused by improper carburetor adjustment.

WARNING

Improper carburetor adjustments may result in operator safety hazards as

well as serious engine damage.  Always have your Polaris dealer perform

any carburetor adjustments.

77

OPERATION

Carburetion

Jetting Guidelines

Changes in altitude and temperature affect air density, which is the

amount of oxygen available for combustion.  In low elevations and cold

temperatures, the air has more oxygen.  In higher elevations and higher

temperatures, the air is less dense.

The carburetors are calibrated for an altitude of 0-2000 ft. (0-600 m) and

ambient temperatures between -10_ to +10_ F. (-23_ to -12_ C).  Carbu-

retors must be re-calibrated if the snowmobile is operated outside this

production temperature and/or altitude range.  The main jet installed in

production is not correct for all altitudes and/or temperatures. See page

96 for more information.

NOTE: It's the owner's responsibility to ensure that the correct jets are

installed in the machine for a geographical area.  Be very care-

ful when jetting down in warm weather.  As the weather turns

colder it will be necessary to re-jet upward to prevent engine

damage.  When selecting the proper main jet always use the

lowest elevation and temperature that is likely to be encoun-

tered.

CAUTION

A main jet that's too small will cause a lean operating condition and may

cause serious engine damage.  Jet the carburetors carefully for elevation and

temperature according to the jetting charts in your Owner's Manual Supple-

ment.

78

OPERATION

n

Engine Stop Switch

Push down on the engine

stop switch (

✪) to

ground out the ignition

and stop the engine

quickly. Pull the switch

up to the ON position to

allow restarting.

n

Throttle Safety Switch

The throttle safety switch is designed to stop the engine whenever all

pressure is removed from the throttle lever and the throttle cable or

valves do not return to the normal closed position.

Test the throttle safety switch

system daily before operation.

1. Sit on the seat.
2. Start the engine and allow it

to idle.

3. Hold the throttle lever pin

stationary by exerting pressure on the pivot pin in the direction

shown in the illustration.

4. Apply a slight amount of throttle.  A properly functioning switch

must shut down the engine.

WARNING

Operating the snowmobile with a faulty throttle safety switch can result in

serious injury or death in the event of an accident.  If the throttle safety switch

does not shut off the engine during a carburetor/throttle system malfunction,

immediately push down the engine stop switch.  Do not start the engine

again until the malfunction has been corrected by your dealer.

✪

79

OPERATION

Throttle Lever

If the engine stops abruptly when the throttle lever is released:

1. Turn the ignition switch to OFF.
2. Visually inspect the throttle cable and carburetor to determine what

caused the safety switch to activate.

3. Test the throttle lever by compressing and releasing it several times.

The lever and cable must return to the idle position quickly and

completely.

4. If the throttle lever operates properly, turn the ignition switch on and

go through normal starting procedures.

5. If the engine doesn't start, take the snowmobile to an authorized

Polaris dealer for service.

Excessive freeplay in the throttle cable may cause the safety switch to

activate, preventing the engine from starting.  If this occurs, return the

machine to an authorized Polaris dealer for service.

If an emergency exists and it's necessary to start the engine, the throttle

safety switch and engine stop switch may be disconnected from the wire

harness.  When these switches are disconnected, the ignition key switch

must be used to shut off the engine.  DO NOT continue to operate the

machine with the throttle safety switch disconnected.  Return the

machine to an authorized Polaris dealer for service as soon as possible.

WARNING

An improperly functioning throttle lever may cause erratic machine behavior

and loss of control, which could result in serious injury or death. If the throttle

lever does not work properly, DO NOT start the engine.
