60

ADULT SECTION

Maintenance

Driveline Lubrication

NOTE:

Driveline noise is normal for this vehicle.

To ensure long life of the snowmobile's driveline, lubricate as follows:
• Lubricate Point A every 15 hours of operation with a small amount of

Polaris Premium All Season Grease.

• Lubricate Point B every 10 hours of operation with aerosol chain lube

or SAE 30 oil.

Carburetor

Track

Drive Shaft

Chain

Point B

Point A

Torque Converter

(Centrifugal Clutch)

Engine

61

ADULT SECTION

Maintenance

Engine Oil

Oil Recommendations

Polaris recommends the use of Performance Synthetic 4-Stroke oil (PS-

4 or PS-4 Plus) for this engine. PS-4 has been specially formulated for

use in Polaris 4-cycle snowmobile engines. It's a fully synthetic, high

performance, multi-viscosity oil designed to provide the ultimate in

lubrication performance and protection.
Always check and change the oil at the intervals outlined in the Periodic

Maintenance Chart beginning on page 50. Perform the break-in oil

change after 20 hours of operation. Always change the oil any time it's

contaminated with water, fuel or debris.

Oil Level

Maintain the oil level between the upper and lower marks on the dip-

stick.
1. Position the vehicle on a level

surface.

2. Stop the engine.
3. Remove the dipstick and wipe

it dry with a clean shop towel.

4. Insert the dipstick into the oil

fill hole completely, but do

not thread it.

5. Remove the dipstick and view

the oil level.

6. If the oil level is below the

lower mark on the dipstick,

add the recommended oil to

the upper mark.

CAUTION

Mixing brands or using a non-recommended oil may cause serious engine

damage. Always use the recommended oil. Never substitute or mix oil brands.

Upper

Mark

Dipstick

Lower

Mark

{

Safe

Range

62

ADULT SECTION

Maintenance

Engine Oil

Oil Change

1. Support the rear of the

snowmobile slightly off the

ground with an appropriate

snowmobile support.

2. Place a drain pan under the

drain plug.

NOTE:

The drain plug is located

under the bulkhead and

in front of the engine.

3. Remove the drain plug.
4. Remove the dipstick and

wipe it dry with a clean

shop towel.

NOTE:

The oil will drain faster with the dipstick removed.

5. Allow the oil to drain completely.
6. Reinstall the drain plug and sealing washer.
7. Using a long funnel, pour 20 oz. (.6 l) of the recommended oil into

the oil fill hole.

8. Insert the dipstick into the oil fill hole completely, but do not thread

it.

9. Remove the dipstick and view the oil level.
10. If the oil level is below the lower mark on the dipstick, add the rec-

ommended oil to the upper mark.

Dipstick

Drain Plug

63

ADULT SECTION

Maintenance

Track Tension

Track adjustment is critical for proper handling. Always maintain cor-

rect tension and alignment.
1. Operate the snow-

mobile to warm up

the track.

2. Stop the engine.
3. Support the rear of

the snowmobile

slightly off the

ground with an

appropriate snow-

mobile support.

4. Hang a 10-pound

(4.5 kg) weight 8

inches (20 cm) from

the center of the

rear idler wheel.

5. Measure the distance between wear surface of the track clip and the

plastic slider at the point where the weight is hanging. Deflection at

this point should be 3/4" (19 mm).

6. If the track tension needs adjustment, follow the procedure on page

64.

8" (20 cm)

10 lbs.

(4.5 kg)

Adjusting

Screw

Idler

Shaft

Bolt
