Safety Instructions



13



















































































Put non-slipping blocks against wheels of the truck for loading/unloading
Turn off the engine, put the main shift lever to “1” or “R” position, and
lock the parking brake, and add non-slipping blocks against the wheels.

[If not]
The truck may slide, fall over and cause accident.

Safety

confirmation

The tire is fixed.



Arrange an assistant for loading/unloading
An assistant should be arranged and the surroundings be checked before loading/unloading.
Never allow the assistant to stand in front of or behind the machine.
Be sure to perform loading/unloading on an open and even ground.

[If not]
The machine may fall over.



Never change the direction of traveling on lamp boards.

[If not]
The machine may fall over.

Do not

change the

direction



Turn off the engine and lock the parking brake during transportation.



Be sure to turn off the engine and lock the parking brake of the combine during transportation by truck.

[If not]
The machine may fall off the truck and cause accident during transportation.

Safety Instructions



14






















6. Precautions for operation



























































Fix the machine on the truck with rope
Put a rope with sufficient strength on the rope hook of the
combine to fix it securely with the truck.

[If not]
The machine may fall off the truck and cause accident during
transportation.

Fix with

the rope

IMPORTANT



Pay attention to the power lines during operation or driving.



The driver/operator may get an electric shock once the machine is in contact with the power line. 3m space
should be kept in front of and right above the machine to avoid electric shock.

[If not]
Heavy casualties may be caused.



It is prohibited to perform manual threshing
in the same position for a long time.
Remove straw accumulated in the rear part timely or move the
machine during manual threshing.

[If not]
Straw may generate heat and cause fire as a result of heat of the
exhaust pipe.

Discharged straw

causes a fire.



Never allow anybody to come close to the machine in operation.



Pay full attention to the surroundings, and especially do not allow children to come close to the machine during
operation. Be sure to sound the horn, pay attention to the surroundings, and do not perform the sack
loading/unloading while turning or reversing.

[If not]
Fatal or major injury accident may be caused.

Safety Instructions



15































































Do not try to clean the threshing section or other moving parts during operation.




[If not]
The sickle may be struck away and cause personal injury.



Be sure to keep slightly away from the harvesting section
and feed a little crop while manual threshing.
Do not stand in front of the harvesting section. The assistant should sit in
the driver’s seat and be prepared for turning off the engine. Put the
harvesting section and reel to the highest position and lock them. Roll up
your cuff, and do not wear gloves or put the towel around your head, neck
or waist.

[If not]
You may be rolled in the machine and injured.

OUCH!



Turn off the engine before removing blockage from the machine.

Be sure to turn off the engine and lock the brake pedal removing any blockage in the harvesting and
threshing sections.


[If not]
Unexpected injuries may be caused.

Safety Instructions



16















































































Drive slowly.

Go into squarely.



Do not get under the machine.



Never get under or put your hands or feet under the machine. Put on
the harvesting lock lever while checking.

[If not]
The harvesting section may fall down unexpectedly and cause
injury.

OUCH!



Remove straw on the engine, exhaust muffler pulley timely.



Remove straw, dust and fuel on the engine, exhaust muffler and
pulley regularly.
Especially, do the cleaning around the exhaust muffler after it works
of deep field.

[If not]
Straw or dust may be ignited and cause fire and burning.

Discharged straw

causes a fire.



Drive at the lowest speed in a right angle while crossing a ridge.



Do not cross the ridge in an inclined angle, but in a right angle
to the ridge.

[If not]
The machine may fall over and cause injury due to loss of balance.

IMPORTANT

Beginners should start from slow-speed operation.
Beginners or less killed operators are recommended to put the main shift lever to “4” or lower gears to prevent
collision. Set the main shift lever in the “High Speed” position and pay full attention to crop and field conditions
after becoming skilled.

[If not]
The harvesting performance may be affected, and the machine may be damaged.
