Challenger Terra Gator 3244 Chassis. Manual - part 11
627333-A
1-41
General
MAINTENANCE INTRODUCTION
IMPORTANT: Perform Maintenance procedures at
regularly scheduled intervals. Failure to
perform regularly scheduled maintenance will
result in damage to the Terra Gator
components or engine. The maintenance
schedule is a recommended guide for correct
maintenance of the Terra Gator.
DO NOT change the schedule unless you
increase the frequency of service when
operating the Terra Gator in very hot, cold,
dusty or corrosive conditions.
Use the hourmeter as a guide for maintenance
intervals.
The maintenance intervals can be shown in both
operating hours and time.
Example: 10 Hours or Every Day. Use the interval
(operating hours or time) that comes first.
MAINTENANCE SCHEDULE
Service Item
Initial
250
Hours
Daily
50
Hours
100
Hours
250
Hours
500
Hours
1000
Hours/
Annual
1. Check Air Pressure - Tires
x
2. Check All Decals
x
3. Remove Water from Air Reservoirs
x
4. Check Coolant
x
5. Check Fuel Water Separator
x
6. Check Engine Oil
x
7. Check Battery Cables - Battery
x
8. Check Hydraulic Oil
x
9. Check Transmission Oil
x
10. Check Hand Rinse Tank
x
11. Grease Articulation Bearings (Hinge) Joint
Pivot Bearings - Upper & Lower
x
12. Check Air Cleaner Indicator
x
13. Check Wheel Bolts
x
14. Lubricate the Dog Walk Rotating Bearing
x
15. Grease Steering Cylinders (2) Bases & Rod
Ends (2x)
x
16. Grease Steering Cylinders Dog Walk (2)
Bases & Rod Ends (2x)
x
17. Grease Dog Walk Locking Pin
x
18. Check Play Dog Walk Tunnel
x
19. Grease Cross Bearings from Drive Shaft
Articulation and Drive Shaft to Rear Axle
x
20. Clean Battery Cables
x
21. Check Hydraulic Hoses and Lines
x
