Challenger Terra Gator 3244 Chassis. Manual - part 1

627333-A

1-1

Safety

SAFETY

IMPORTANT: Any modifications to machine or

systems not authorized by AGCO void warranty. This

includes, but is not limited to hitches.

FOLLOW SAFETY INSTRUCTIONS

FIG. 1: Carefully read, learn and understand all safety

messages and information in this manual and on

machine's safety signs. Keep safety signs in good

condition. Replace missing or damaged safety signs.

Make sure new machine components and repair parts

include current safety signs. Replacement safety signs

are available from local AGCO dealer.

Never operate machine or equipment without proper

instruction and a complete understanding of control

operation.

Learn how to properly operate machine and use all

controls before operation. Do not allow anyone to

operate machine, systems or perform service and

maintenance procedures without proper instruction.

Keep machine, all components and systems in proper

working condition. Modifications to machine,

unauthorized by AGCO, may impair functionality and

safety, affect machine life and void machine warranty.

PREPARE FOR EMERGENCIES

FIG. 2: Be prepared if a fire starts. keep a first aid kit

and fire extinguisher handy.

Dial 112 or your national emergency number in cases

of emergency.

Keep emergency numbers for doctors, ambulance

service, hospital and fire department readily available at

all times.

FIG. 1

FIG. 2

Safety

1-2

627333-A

SAFETY ALERT SYMBOL

FIG. 3: This is the safety alert symbol and it means

attention, become alert, safety is involved. Look for the

safety alert symbol in this manual and on safety signs

on machine, it directs attention to information involving

operator safety and safety of others.

SIGNAL WORDS

Danger, warning or caution are used with the safety

alert symbol. Learn to recognize these safety alerts and

follow recommended precautions and safe practices.

m

DANGER: Indicates imminently

hazardous situation that, if not avoided,

results in death or very serious injury.

m

WARNING: Indicates potentially

hazardous situation that, if not avoided,

could result in death or serious injury.

m

CAUTION: Indicates potentially

hazardous situation that, if not avoided,

may result in minor injury.

INFORMATIONAL MESSAGES

The words IMPORTANT and NOTE are not related to

personal safety, but are used to give additional

information and tips for operating and servicing

machine.

IMPORTANT: Identifies special instructions or

procedures that, if not strictly observed, could

result in damage to, or destruction of machine,

attachments or environment.

NOTE: Identifies points of particular interest for more

efficient and convenient operation or repair.

FIG. 3

0001

627333-A

1-3

Safety

IMPORTANT SAFETY INFORMATION

Most personal injuries occur during product operation,

maintenance or repair and are caused by failure to

observe basic safety rules and precautions. In most

cases, an injury can be avoided by recognizing

hazardous situations before an injury occurs.

Operator must be alert to potential hazards and have the

necessary training, skills and tools to perform functions

properly.

Improper operation, lubrication, maintenance or repair of

product can be hazardous and could result in injury or

death.

Do not operate or perform any lubrication, maintenance

or repair of machine until reading and understanding

associated information.

Safety precautions and warnings are provided in manual

and on machine. If these hazard warnings are not

heeded, bodily injury or death could occur to operator or

bystanders.

Not every circumstance involving a potential hazard can

be anticipated. Warnings in this publication and on

machine are, therefore, not all inclusive. If a tool,

procedure, work method or operating technique, not

specifically recommended by AGCO is used, ensure it is

safe for operator and others.

Make sure machine will not be damaged or be made

unsafe by operation, lubrication, maintenance or repair

procedures chosen. Information, specifications and

illustrations in publication are on basis of information

available at time publication was written.

Specifications, torques, pressures, measurements,

adjustments, illustrations and other items can change at

any time. These changes can affect service given to

product. Obtain complete and most current information

before starting any job. Local AGCO dealer has the

most current information available.

m

WARNING: When replacement parts are

required for this product, AGCO

recommends using AGCO replacement

parts or parts with equivalent

specifications including, but not limited to,

physical dimensions, type, strength and

material. Failure to heed this warning can

lead to premature failures, product

damage, personal injury or death.

GENERAL HAZARD INFORMATION

Do not start engine until area is free of personnel to

avoid personal injury due to unexpected machine

movement.

Know width of machine to maintain proper clearance

when operating near fences or boundary obstacles.

As required, wear a hard hat, protective glasses and

other protective equipment.

Do not wear loose clothing or jewelry that can snag on

controls or other parts.

All protective guards and covers must be secured in

place.

Keep machine free of foreign material. Remove debris,

oil, tools and other items from deck, walkways and

steps.

Secure lunchboxes, tools and other loose items not a

part of machine.

Know appropriate work site hand signals, personnel

authorized to give hand signals and only accept hand

signals from one person.

Drain all liquids into a suitable container, never put

maintenance fluids into glass containers.

Discard any drained fluids and filter elements according

to local regulations.

Use all cleaning solutions with care.

Report all necessary repairs.

Do not allow unauthorized personnel on machine.

Do not smoke when servicing air conditioner or when

refrigerant gas may be present. Inhaling fumes released

from a flame that contacts air conditioner refrigerant can

cause bodily harm or death.

Inhaling gas from air conditioner refrigerant through a lit

cigarette can cause bodily harm or death.

Unless otherwise instructed, perform maintenance

under the following conditions:

•

Park on level ground

•

Lower implements to ground

•

Transmission control lever in park

•

Stop engine

•

Engine start switch is off and key removed

•

Machine has cooled down

Safety

1-4

627333-A

Pressurized Air

Air under pressure can cause personal injury. When

pressurized air is used for cleaning, wear a protective

face shield, protective clothing and protective shoes.

Maximum air pressure for cleaning purposes must be

below 205 kPa (30 PSI).

Asbestos Information

AGCO equipment and replacement parts shipped from

AGCO are asbestos-free. AGCO recommends use of

only genuine AGCO replacement parts.

Electrical Storm Injury Prevention

When lightning is striking in vicinity of machine, do not

attempt to mount or dismount machine.

Do not leave operator sation during an electrical storm.

Stay away from machine if on ground during an

electrical storm.

Mounting and Dismounting

Mount or dismount machine only at locations with steps

and/or hand holds. Before mounting or dismounting,

clean steps and hand holds. Inspect stairs and hand

holds and make any necessary repairs.

Maintain three-point contact with steps and hand holds.

Three-point contact is two feet and one hand or one

foot and two hands.

Never mount or dismount a moving machine. Never

jump from machine except in an emergency.

Do not carry tools or supplies when mounting or

dismounting machine, use a hand line to pull

equipment onto platform.

Do not use any controls as hand holds when entering

or exiting operator compartment.

IMPORTANT: Make sure steps are not adjusted too

close to machine hood.

A minimum dimension of 75 mm (2 in) between inside

hand hold and hood must be maintained to allow room

for operator's hand.
