HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 62





Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.8 kg (1.8 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
SCS
0.2
0.3
9.16 Spectrum Analyzer Unit Specifications
9.16.1 MCA4 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-230 lists the optical specifications of the MCA4 board.
Table 9-230 Optical specifications of the MCA4 board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
Detect range for single channel optical power
dBm
-30 to -10
Detect accuracy for optical power
dB
±1.5
Detect accuracy for OSNR (The detect range
dB
±1.5 (OSNR: 13 to 19)
for signal-to-noise ratio is 13 dB to 23 dB, and
±2 (OSNR: 19 to 23)
the wavelength spacing is 50 GHz.)
Detect accuracy for central wavelength
nm
±0.1
Numbers of optical interface
pcs
4
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.9 kg (4.2 lb.)
664
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
MCA4
8.0
8.5
9.16.2 MCA8 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-231 lists the optical specifications of the MCA8 board.
Table 9-231 Optical specifications of the MCA8 board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
Detect range for single channel optical power
dBm
-30 to -10
Detect accuracy for optical power
dBm
±1.5
Detect accuracy for OSNR (The detect range
dB
±1.5 (OSNR: 13 to 19)
for signal-to-noise ratio is 13 dB to 23 dB, and
±2 (OSNR: 19 to 23)
the wavelength spacing is 50 GHz.)
Detect accuracy for central wavelength
nm
±0.1
Numbers of optical interface
pcs
8
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.9 kg (4.2 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
MCA8
12.0
13.0
665
9.16.3 OPM8 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-232 lists the optical specifications of the OPM8 board.
Table 9-232 Optical specifications of the OPM8 board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
Detect range for single channel optical power
dBm
-30 to -10
Detected accuracy for optical power
dB
±1.5
Channel spacing
GHz
50/100
Numbers of optical interface
pcs
8
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.2 kg (2.6 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11OPM8
12
15
9.16.4 WMU Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-233 Optical specifications of the WMU board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
Adjacent channel spacing
GHz
50/100
666
Item
Unit
Value
Per-channel input optical power range
dBm
-36 to -16
Detect accuracy for central wavelength
GHz
<2.5
Detect accuracy for single channel optical
dB
<2
power
Detect range for Central wavelength offset
GHz
-10 to 10
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Optical Module
Typical Power
Maximum Power
Type
Consumption at
Consumption at
25°C (77°F) (W)
55°C (131°F) (W)
TN11WMU
-
12
15
9.17 Variable Optical Attenuator Unit Specifications
9.17.1 VA1 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
TN11VA1 Optical Specifications
Table 9-234 lists the optical specifications of the TN11VA1 board.
Table 9-234 Optical specifications of the TN11VA1 board
Item
Unit
Value
IN-OUT
Inherent insertion loss
dB
≤1.5
Dynamic attenuation
dB
20
range
Adjustment accuracy
dB
1
667
TN12VA1 Optical Specifications
Table 9-235 lists the optical specifications of the TN12VA1 board.
Table 9-235 Optical specifications of the TN12VA1 board
Item
Unit
Value
IN-OUT
Inherent insertion loss
dB
≤1.5
Dynamic attenuation
dB
20
range
Adjustment accuracy
dB
1 (attenuation≤10dB)
1.5 (attenuation≤15dB)
1.8 (attenuation>15dB)
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Optical Module
Typical Power
Maximum Power
Type
Consumption at
Consumption at
25°C (77°F) (W)
55°C (131°F) (W)
VA1
-
6.5
7.2
9.17.2 VA4 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
TN11VA4 Optical Specifications
Table 9-236 lists the optical specifications of the TN11VA4 board.
Table 9-236 Optical specifications of the TN11VA4 board
Item
Unit
Value
IN-OUT
Inherent insertion loss
dB
≤1.5
Dynamic attenuation
dB
20
range
Adjustment accuracy
dB
1
668
TN12VA4 Optical Specifications
Table 9-237 lists the optical specifications of the TN12VA4 board.
Table 9-237 Optical specifications of the TN12VA4 board
Item
Unit
Value
IN-OUT
Inherent insertion
dB
≤1.5
loss
Dynamic
dB
20
attenuation range
Adjustment accuracy
dB
1 (attenuation≤10 dB)
1.5 (attenuation≤15 dB)
1.8 (attenuation>15 dB)
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Optical Module
Typical Power
Maximum Power
Type
Consumption at
Consumption at
25°C (77°F) (W)
55°C (131°F) (W)
VA4
-
8.5
9.4
9.18 Optical Power and Dispersion Slope Equalizing Board
Specifications
9.18.1 GFU Board Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-238 Optical specifications of the GFU board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
669
Item
Unit
Value
Channel insertion loss
dB
0.5-6.0
Polarization dependent loss
dB
≤0.5
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 2.0 lb. (0.9 kg)
Power Consumption
l Typical power consumption at 25°C (77°F): 0.2 W
l Maximum power consumption at 55°C (131°F): 0.3 W
9.18.2 DCU Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-239 Optical specifications of the DCU board (1)
Item
Unit
Value
DC
DC
DC
DC
DC
DC
D
DCU0
U0
U0
U0
U0
U0
U06
CU
8
1
2
3
4
5
07
Typical dispersion
km
20
40
60
80
100
120
5
10
compensation distance
Maximum insertion loss
dB
3.3
4.7
6.4
8
9
9.8
2.3
2.8
Dispersion compensation
-
90%-110%
slope
Polarization mode
ps
0.4
0.5
0.6
0.7
0.8
0.8
0.3
0.3
dispersion
Polarization-dependent
dB
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
loss
Maximum input power a
dBm
20
20
20
20
20
20
20
20
Operating wavelength
nm
1528-1568
range
Dispersion compensating
-
G.652 fiber
fiber type
670
Item
Unit
Value
DC
DC
DC
DC
DC
DC
D
DCU0
U0
U0
U0
U0
U0
U06
CU
8
1
2
3
4
5
07
a: The maximum input power refers to the maximum input optical power permitted by the
optical module on the condition that the optical module is not damaged.
Table 9-240 Optical specifications of the DCU board (2)
Item
Unit
Value
DCU
DCU
DCU
DCU
DCU1
DCU1
11
12
13
14
5
6
Typical dispersion
km
20
40
60
80
100
120
compensation distance
Maximum insertion loss
dB
4
5
5.9
6.9
7.8
8.8
Dispersion compensation
-
90%-110%
slope
Polarization mode
ps
0.4
0.5
0.7
0.8
0.9
1.0
dispersion
Polarization-dependent
dB
0.3
0.3
0.3
0.3
0.3
0.3
loss
Maximum input power a
dBm
20
20
20
20
20
20
Operating wavelength
nm
1528-1568
range
Dispersion compensating
-
G.655 fiber
fiber type
a: The maximum input power refers to the maximum input optical power permitted by the
optical module on the condition that the optical module is not damaged.
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.5 kg (3.3 lb)
671
Power Consumption
Board
Optical Module
Typical Power
Maximum Power
Type
Consumption at
Consumption at
25°C (77°F) (W)
55°C (131°F) (W)
TN11DCU
-
0.2
0.3
9.18.3 TDC Specifications
Specifications include optical specifications, laser safety level, mechanical specifications and
power consumption.
Optical Specifications
Table 9-241 lists the optical specifications of the TDC board.
Table 9-241 Optical specifications of the TDC board
Parameter
Unit
Value
Optical channels
-
80
Dispersion tuning range
ps/nm
±400
Dispersion tuning resolution
sec
<15
Input power range
dBm
-13 to 0
Dispersion accuracy
ps/nm
±10
Output optical power
dBm
The output optical power should
be close to the input power, with
an error range of ±1.5 dB.
Mechanical Specifications
The mechanical specifications of the board are as follows:
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.5 kg (1.1 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11TDC
13
15
672
9.19 DCM Specifications
Table 9-242 Table 4-16 Performance requirements for C-band dispersion compensation optical
fibers (G.652 fibers)
DCM
Distance
Max.
DSC
PMD
PD
Max.
Operatin
Module
(mi./km)
Inserti
R
(ps)
L
Allowed
g
on Loss
(dB
Powera
Wavelen
(dB)
)
(dBm)
gth (nm)
DCM(S)
3.1/5
2.3
90%
0.3
0.1
20
1528 to
to
1568
DCM(T)
6.2/10
2.8
0.3
0.1
20
110%
DCM(A)
12.4/20
3.3
0.4
0.1
20
DCM(B)
24.8/40
4.7
0.5
0.1
20
DCM(C)
37.3/60
6.4
0.6
0.1
20
DCM(D)
49.7/80
8
0.7
0.1
20
DCM(E)
62.1/100
9
0.8
0.1
20
DCM(F)
74.5/120
9.8
0.8
0.1
20
FBG-DCM
49.7/80
4
1.0
0.2
23
(80)
FBG-DCM
62.1/100
4
1.0
0.2
23
(100)
FBG-DCM
74.5/120
4
1.0
0.2
23
(120)
FBG-DCM
99.4/160
8
1.6
0.4
23
(160)
FBG-DCM
124.2/200
8
1.6
0.4
23
(200)
FBG-DCM
149.1/240
8
1.6
0.4
23
(240)
a: The Max. Allowed Power refers to the maximum input optical power that the optical module
can receive without being damaged.
673
Table 9-243 Table 4-17 Performance requirements for C-band dispersion compensation optical
fibers (G.655 LEAF fibers)
DCM
Distance
Max.
DSC
PMD
PD
Max.
Operatin
Module
(mi./km)
Inserti
R
(ps)
L
Allowed
g
on Loss
(dB
Powera
Wavelen
(dB)
)
(dBm)
gth (nm)
DCM(A)
12.4/20
4
90%
0.4
0.3
20
1528 to
to
1568
DCM(B)
24.8/40
5
0.5
0.3
20
110%
DCM(C)
37.3/60
5.9
0.7
0.3
20
DCM(D)
49.7/80
6.9
0.8
0.3
20
DCM(E)
62.1/100
7.8
0.9
0.3
20
DCM(F)
74.5/120
8.8
1.0
0.3
20
FBG-DCM
74.5/120
3.7
1.0
0.2
23
(120)
FBG-DCM
99.4/160
3.7
1.0
0.2
23
(160)
FBG-DCM
124.2/200
3.7
1.0
0.2
23
(200)
FBG-DCM
149.1/240
3.7
1.0
0.2
23
(240)
a: The Max. Allowed Power refers to the maximum input optical power that the optical module
can receive without being damaged.
Table 9-244 Table 4-18 Performance requirements for C-band dispersion compensation optical
fibers (G.653 fibers)
DCM
Distance
Max.
DSC
PMD
PDL
Max.
Opera
Module
(mi./km)
Insert
R
(ps)
(dB)
Allowe
ting
ion
d
Wavel
Loss
Powera
ength
(dB)
(dBm)
(nm)
DCM(S)
3.1/5
2
90%
0.2
0.1
20
1528 to
to
1568
DCM(T)
6.2/10
3
0.3
0.1
20
110%
DCM(A)
12.4/20
5
0.5
0.1
20
a: The Max. Allowed Power refers to the maximum input optical power that the optical module
can receive without being damaged.
674















Content   ..  60  61  62  63   ..
