HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 59
Item
Unit
Value
Type
-
TN12WSD9
TN13WSD9
Adjacent channel isolation
dB
> 25
> 25
Non-adjacent channel isolation
dB
> 30
> 30
Extinction ratio
dB
≥ 35
≥ 35
Reconfiguration time
s
≤ 3
≤ 3
Maximum reflectance
dB
-40
-40
Directivity
dB
35
35
Polarization dependence loss
dB
≤ 1
≤ 1
Attenuation range of each of
dB
0-15
0-15
dropping wavelengths
Attenuation precision of each of
dB
≤ 1 (0 to 10 dB)
≤ 1 (0 to 10 dB)
dropping wavelengths
≤ 1.5 (>10 dB)
≤ 1.5 (>10 dB)
NOTE
a: DMx represents the DM1-DM8 interface.
b: This value can be reached when the attenuation of the VOA is set to 0 dB.
Mechanical Specifications
Dimensions of front panel:
l TN12WSD9: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) or 2.0 in. (W) x 8.7 in. (D) x
10.4 in. (H)
l TN13WSD9: 76.2 mm (W) x 220 mm (D) x 264.6 mm (H) or 3.0 in. (W) x 8.7 in. (D) x
10.4 in. (H)
Weight:
l TN12WSD9: 2.7 kg (5.94 lb.)
l TN13WSD9: 2.9 kg (6.38 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11WSD9
17.0
18.7
TN12WSD9
25.4
28.5
TN13WSD9
25.4
28.5
631
9.10.5 WSM9 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-206 Optical specifications of the WSM9 board
Item
Unit
Value
Type
-
TN12WSM9
TN13WSM9
Optical channels
-
40
80
Adjacent channel spacing
GHz
100
50
Insertion
AMxa-OUT
dB
≤ 8b
≤ 8b
loss
EXPI-OUT
Maximum channel insertion
dB
1.5
1.5
loss difference
Operating wavelength range
nm
1529-1561
1529-1561
-1 dB spectral width
nm
> 0.32
> 0.16
Port isolation
dB
> 25
> 25
Adjacent channel isolation
dB
> 25
> 25
Non-adjacent channel isolation
dB
> 30
> 30
Extinction ratio
dB
≥ 35
≥ 35
Reconfiguration time
s
≤ 3
≤ 3
Directivity
dB
35
35
Maximum reflectance
dB
-40
-40
Polarization dependence loss
dB
≤ 1
≤ 1
Attenuation range of each of
dB
0-15
0-15
adding wavelengths
Attenuation precision of each of
dB
≤ 1 (0 to 10 dB)
≤ 1 (0 to 10 dB)
adding wavelengths
≤ 1.5 (>10 dB)
≤ 1.5 (>10 dB)
NOTE
a: AMx represents the AM1-AM8 interface.
b: This value can be reached when the attenuation of the VOA is set to 0 dB.
Mechanical Specifications
Dimensions of front panel:
632
l TN12WSM9: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) or 2.0 in. (W) x 8.7 in. (D) x
10.4 in. (H)
l TN13WSM9: 76.2 mm (W) x 220 mm (D) x 264.6 mm (H) or 3.0 in. (W) x 8.7 in. (D) x
10.4 in. (H)
Weight:
l TN12WSM9: 2.7 kg (5.94 lb.)
l TN13WSM9: 2.9 kg (6.38 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11WSM9
17.0
18.7
TN12WSM9
25.4
28.5
TN13WSM9
25.4
28.5
9.10.6 WSMD2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-207 lists the optical specifications of the WSMD2 board.
Table 9-207 Optical specifications of the TN11WSMD2 board
Item
Unit
Value
Optical channels
-
40
Adjacent channel spacing
GHz
100
Operating wavelength range
nm
1529-1561
-1 dB spectral width
nm
> 0.32
Insertion loss
AM-OUT
dB
≤ 8a
EXPI-OUT
IN-DM
≤ 4.5a
IN-EXPO
Maximum channel insertion loss difference
dB
1.5
Port isolation
dB
> 25
Extinction ratio
dB
≥ 35
633
Item
Unit
Value
Reconfiguration time
s
≤ 3
Maximum reflectance
dB
-40
Directivity
dB
35
Polarization dependence loss
dB
≤ 1
Attenuation range of each of adding
dB
0-15
wavelength
Attenuation precision of each of adding
dB
≤ 1 (0 dB to 10 dB)
wavelength
≤ 1.5 (> 10 dB)
a: This value can be reached when the attenuation of the VOA is set to 0 dB.
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 3.2 kg (7.0 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11WSMD2
17.0
18.7
9.10.7 WSMD4 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-208 Optical specifications of the WSMD4 board
Item
Unit
Value
TN11WSMD4
TN12WSMD4
Optical channels
-
40
80
Adjacent channel spacing
GHz
100
50
Operating wavelength range
nm
1529-1561
1529-1561
-1dB spectral width
nm
> 0.32
> 0.16
634
Item
Unit
Value
TN11WSMD4
TN12WSMD4
Insertion loss
AMxa-OUT
dB
≤ 8b
≤ 8b
IN-DMxa
≤ 8
≤ 8
Maximum channel insertion
dB
1.5
1.5
loss difference
Port isolation
dB
> 25
> 25
Extinction ratio
dB
≥ 35
≥ 35
Reconfiguration time
s
≤ 3
≤ 3
Maximum reflectance
dB
-40
-40
Directivity
dB
35
35
Polarization dependence loss
dB
≤ 1
≤ 1
Attenuation range of each of
dB
0-15
0-15
adding wavelength
Attenuation precision of each of
dB
≤ 1 (0 to 10 dB)
≤ 1 (0 to 10 dB)
adding wavelength
≤ 1.5 (> 10 dB)
≤ 1.5 (> 10 dB)
Dimension
-
4
4
a: AMx represents the AM1-AM4 interface. DMx represents the DM1-DM4 interface.
b: This value can be reached when the attenuation of the VOA is set to 0 dB.
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight:
- TN11WSMD4: 3.2 kg (7.1 lb.)
- TN12WSMD4: 2.6 kg (5.7 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11WSMD4
17
18.7
TN12WSMD4
12
15
635
9.10.8 WSMD9 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-209 Optical specifications of the TN11WSMD9 board
Item
Unit
Value
Optical channels
-
80
Adjacent channel spacing
GHz
50
Insertion loss
AMxa/EXPI-OUT
dB
≤ 8b
IN-DMxa/EXPO
≤ 12
Maximum channel insertion loss difference
dB
1.5
Operating wavelength range
nm
1529-1561
-1dB spectral width
nm
> 0.16
Port isolation
dB
> 25
Extinction ratio
dB
≥ 35
Reconfiguration time
s
≤ 3
Maximum reflectance
dB
-40
Directivity
dB
35
Polarization dependence loss
dB
≤ 1
Attenuation range of each of adding
dB
0 to 15
wavelength
Attenuation precision of each of adding
dB
< 1 (0 to 10 dB)
wavelength
< 1.5 (> 10 dB)
Dimension
-
9
a: AMx represents the AM1-AM8 interface. DMx represents the DM1-DM8 interface.
b: This value can be reached when the attenuation of the VOA is set to 0 dB.
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 3.1 kg (6.8 lb.)
636
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11WSMD9
25
30
9.11 Optical Amplifier Unit Specifications
9.11.1 CRPC Specifications
Specifications include optical specifications, weight and power consumption.
Optical Specifications
Table 9-210 Optical specifications of the CRPC board
Item
Un
Value
it
CRPC01
CRPC03
Pump wavelength range
nm
1400-1500
1400-1500
Operating wavelength range
nm
1529-1561
1529-1561
Maximum pump power
dB
29
29.5
m
Channel gain on G.652 fiber
dB
> 10
> 10
Channel gain on G.653 fiber
dB
N/A
> 16
Channel gain on LEAF fiber
dB
> 12
N/A
Channel gain on TWRS fiber
dB
> 13
N/A
Effective noise figure on G.652
dB
≤ 0
N/A
fiber
Effective noise figure on G.653
dB
N/A
N/A
fiber
Effective noise figure on LEAF
dB
≤ -1
N/A
fiber
Effective noise figure on
dB
≤ -1.5
N/A
TWRS fiber
Polarization dependence loss
dB
≤ 0.5
≤ 0.5
Output connector type
-
LSH/APC, LC/PC
LSH/APC, LC/PC
637
Mechanical Specifications
l Dimensions of board: 345.0 mm (H) x 218.5 mm (D) x 76.0 mm (W) or 13.8 in. (H) x 8.7
in. (D) x 3.0 in. (W)
Weight
l CRPC01: 4.0 kg (8.8 1b.)
l CRPC03: 4.2 kg (9.2 1b.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
CRPC01
110.0
121.0
CRPC03
70.0
77.0
9.11.2 DAS1 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-211 Optical specifications of the TN11DAS1 board
Item
Uni
Value
t
Specifica
Operating wavelength range
nm
1529-1561
1529-1561
1529-1561
tions of
Nominal gain
dB
20
26
31
OA
Nominal input power range
dB
-32 to 0
-32 to -6
-32 to -11
m
Input power range
40
dB
-32 to -16
-32 to -22
-32 to -27
per channel
channels
m
80
dB
-32 to -19
-32 to -25
-32 to -30
channels
m
Nominal single-
40
dB
-16
-22
-27
wavelength input
channels
m
optical power
80
dB
-19
-25
-30
channels
m
Nominal single-
40
dB
4
4
4
wavelength input
channels
m
optical power
638
Item
Uni
Value
t
80
dB
1
1
1
channels
m
Noise figure (NF)a
dB
≤ 8.5
≤ 5.5
≤ 5.5
Gain response time on adding/
ms
< 10
< 10
< 10
dropping of channels
Channel gain
dB
20 to 31
Gain flatness
dB
≤ 2.0
≤ 2.0
≤ 2.0
Multi-channel gain slope
dB/
≤ 2.0
≤ 2.0
≤ 2.0
dB
Input reflectance
dB
< -40
< -40
< -40
Output reflectance
dB
< -40
< -40
< -40
Pump leakage at input
dB
< -30
< -30
< -30
m
Maximum reflectance tolerance
dB
-27
-27
-27
at input
Maximum reflectance tolerance
dB
-27
-27
-27
at output
Maximum total output optical
dB
20
20
20
power
m
Polarization dependent loss
dB
≤ 0.5
≤ 0.5
≤ 0.5
Input VOA inherent insertion
dB
≤ 1.5
loss
Input VOA dynamic attenuation
dB
20
range
Input VOA adjustment accuracy
dB
1
Specifica
Operating wavelength range of
nm
1480 to 1520
tions of
optical supervisory channel
demultipl
Optical return loss
dB
> 40
exer and
multiplex
Insert loss of optical
LIN-TM
dB
≤ 1.5
er
supervisory
RM-
channel
LOUT
Insert loss of C-band
dB
≤ 1
Polarization dependent loss
dB
< 0.2
639
Item
Uni
Value
t
Specifica
Operating wavelength range
nm
1504.5 to 1517.5
tions of
1484.5 to 1497.5
OSC
Signal rate
Mbi
155.52
optical
t/s
module
Launched optical power
dB
0.5 to 5
m
Receiver sensitivity
dB
≤ -41
m
Receiver overload
dB
-10
m
a: The gain can be adjusted continuously. The noise figure varies with the gain. The previous table lists the noise
figure when the noise figure uses the typical value.
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.4 kg (3.1 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F)
(131°F)
TN11DAS1
22
28.6
9.11.3 HBA Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-212 Optical specifications of the HBA board
Item
Unit
Value
Type
-
TN11HBA
Channel allocation
nm
1529 - 1561
Nominal input power range
dBm
-25 to -3
640
Item
Unit
Value
Typical input power of a single
dBm
80-channel system: -22
wavelength
40-channel system: -19
10-channel system: -13
Noise figure (NF)
dB
< 8
Input reflectance
dB
< -45
Output reflectance
dB
< -45
Maximum total output power
dBm
26
Gain response time on adding/dropping of
ms
< 10
channels
Channel gain
dB
29±1
Gain flatness
dB
≤ 2.5
Polarization dependent loss
dB
< 0.5
Mechanical Specifications
l Dimensions of front panel: 76.2 mm (W) x 220 mm (D) x 264.6 mm (H) (3.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 3.0 kg (6.6 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
HBA
47
75
9.11.4 OAU1 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-213 Optical specifications of the TN12OAU100 board
Item
Unit
Value
Operating wavelength range
nm
1529-1561
1529-1561
1529-1561
Nominal gain
dB
16
22
25.5
641
