HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 54
Item
Unit
Value
Optical Module
800 ps/nm-PID-NRZ-
1500 ps/nm-PID-NRZ-
Type
PIN (40 km)
PIN (80 km)
Central frequency
THz
192.10 to 196.05
192.10 to 196.05
Maximum mean
dBm
+2
+2
launched power
(single wavelength)
Minimum mean
dBm
-4
-6.5
launched power
(single wavelength)
Minimum extinction
dB
6
6
ratio
Central frequency
GHz
±5
±5
deviation
Maximum -20 dB
nm
0.8
0.8
spectral width
Minimum side mode
dB
30
30
suppression ratio
Dispersion tolerance
ps/nm
800
1500
Receiver parameter specifications
at point R
Receiver type
-
PIN
PIN
Operating
nm
1200 to 1650
1200 to 1650
wavelength range
Receiver sensitivity
dBm
-15
-12
(FEC enabled) EOL
Minimum receiver
dBm
3
3
overload
Maximum
dB
-27
-27
reflectance
Table 9-156 Specifications of the red and blue band filters on the TN55NPO2E board
Item
Unit
Value
Working wavelength in the C
nm
1528 to 1561
band
Working wavelength in the blue
THz
196.0 to 193.8
band (T01/R01)
576
Item
Unit
Value
Working wavelength in the red
THz
193.6 to 191.4
band (T02/R02)
Demultiplexing loss (RI->T01,
dB
≤ 1
RI->T02)
Multiplexing loss (R01->T0,
dB
≤ 1
R02->T0)
Isolation between red and blue
dB
≥ 13
bands
Mechanical Specifications
TN55NPO2E:
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.7 kg (3.75 lb.)
TN54PQ2:
l Dimensions of front panel: 24.5 mm (W) x 68 mm (D) x 57 mm (H) (0.96 in. (W) x 2.69
in. (D) x 2.24 in. (H))
l Weight: 0.1 kg (0.22 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN55NPO2E
143
157.3
TN54PQ2
1.1
1.2
9.6 OCS Board Specifications
9.6.1 Specifications of the BPA
Specifications include optical specifications, laser safety class, mechanical specifications, and
power consumption.
Optical Specifications
Table 9-157 lists the optical specifications of the BPA board.
577
Table 9-157 Optical specifications of the BPA board
Item
Value
Nominal bit rate
2488320 kbit/s or 9953280 kbit/s
Application code
V-16.2, U-16.2, L-64.2, V-64.2, and U-64.2
Line code pattern
NRZ
Input wavelength (nm)
BA: 1530 to 1565
PA: 1550.12
Input optical power
BA: -6 to +3
(dBm)
PA: -28 to -10 (when the BPA board works with the line board at
the rate of 10 Gbit/s)
PA: -38 to -10 (when the BPA board works with the line board at
the rate less than 10 Gbit/s)
Output optical power
13 to 15 (BA)
(dBm)
Sensitivity (dBm)
PA: -37
Noise figure (dB)
BA: < 6.5
PA: < 6
NOTE
When you perform a loopback on the PA module of the BPA board, prevent the damage caused by high
input optical power to the optical module.
Laser Safety Class
The laser safety class of the optical interface is CLASS 1M, indicating that the maximum output
optical power of each optical interface ranges from 10 dBm (10 mW) to 22.15 dBm (164 mW).
Mechanical Specifications
The mechanical specifications of the BPA board are as follows:
l Dimensions (mm): 25.4 (W) x 220 (D) x 262.05 (H)
l Weight: 1.2 kg (2.6 lb.)
Power Consumption
Typical power consumption at 25°C (77°F): 11 W
9.6.2 Specifications of the EGSH
Specifications include optical specifications, electrical specifications, laser safety class,
mechanical specifications, and power consumption.
578
Optical Specifications
Table 9-158 lists the optical specifications of the EGSH board.
Table 9-158 Optical specifications of the EGSH board
Item
Value
Type of optical
1000BASE-LX (10 km)
1000BASE-SX (0.5 km)
interface
Type of fiber
Single-mode LC
Multi-mode LC
Operating
1270 to 1355
770 to 860
wavelength range
(nm)
Launched optical
-9 to -3
-9.5 to -3.5
power range (dBm)
Receiver sensitivity
-20
-18
(dBm)
Minimum overload
-3
0
(dBm)
Minimum extinction
9
9
ratio (dB)
Electrical Specifications
Table 9-159 lists the electrical specifications of the EGSH board.
Table 9-159 Electrical specifications of the EGSH board
Type of Interface
Code Pattern
1000BASE-T, RJ45
4D-PAM5
NOTE
Only port 6 and port 8 of the EGSH board can work as the GE electrical interface.
Laser Safety Class
The laser safety class of the optical interface is CLASS 1, indicating that the maximum output
optical power of each optical interface is less than 10 dBm (10 mW).
Mechanical Specifications
The mechanical specifications of the EGSH board are as follows:
579
l Dimensions: 25.4 mm (W) x 220 mm (D) x 266.7 mm (H)
l Weight: 1.2 kg (2.6 lb.)
Power Consumption
Typical power consumption at 25°C (77°F): 89.3 W
9.6.3 Specifications of the SF64
Specifications include optical specifications, laser safety class, mechanical specifications, and
power consumption.
Optical Specifications
Table 9-160 lists the optical specifications of the SF64 board.
Table 9-160 Optical specifications of the SF64 board
Item
Value
Nominal bit
10.709 Gbit/s
rate
Application
Ue-64.2c
Ue-64.2d
Ue-64.2e
codea
OBU101 (-28
OBU101 (-31
OBU101 (-34
OBU101 (-37
dBm to -31
dBm to -34 dBm)
dBm to -37 dBm)
dBm to -40 dBm)
dBm)+
+ CRPC +
+ CRPC +
+ CRPC +
OAU103b +
OAU103 +
OAU103 +
OAU103 +
DCU03 (60) +
DCU03 (60) +
DCU03 (60) +
DCU03 (60) +
MR2
DCU03 (60) +
DCU04 (80) +
DCU04 (80) +
DCU08 (10) +
MR2
DCU08 (10) +
MR2
MR2
Type of fiber
Single-mode LC
Operating
1550.12
wavelength
range (nm)
Launched
-1 to +2
optical
power range
(dBm)c
Receiver
-19
sensitivity
(dBm)
Minimum
0
overload
(dBm)
580
Item
Value
Minimum
10.5
extinction
ratio (dB)
a: The numbers in the brackets indicate the corresponding parameter values. For example,
"OBU101 (-28 dBm to -31 dBm)" indicates that the optical power amplified by the OBU101
is -28 dBm to -31 dBm.
b: "OBU101 + OAU103" indicates that the specifications of the optical interface are measured
when the OBU101 and OAU103 are used.
c: The parameters are only for the optical modules. The parameters of the amplifier are not
provided.
Table 9-161 lists the specifications of the tunable XFP optical interfaces of the SF64 board.
Table 9-161 Specifications of the tunable XFP optical interfaces of the SF64 board
Item
Value
Type of optical
1600 ps/nm - NRZ - tunable
module
Line code format
NRZ - 80 channels tunable
Transmitter parameter specifications at point S
Maximum mean
3
launched power
(dBm)
Minimum mean
-1
launched power
(dBm)
Minimum extinction
9
ratio (dB)
Central wavelength
192.10 to 196.05
(THz)
Central wavelength
±5
deviation (GHz)
Maximum -20 dB
0.3
spectral width (nm)
Minimum side mode
35
suppression ratio
(dB)
Dispersion tolerance
1600
(ps/nm)
581
Item
Value
Receiver parameter specifications at point R
Receiver type
APD
Operating
1260 to 1600
wavelength range
(nm)
Receiver sensitivity
-24
(FEC on) EOL
(dBm)
Minimum overload
-7
(dBm)
Maximum
-27
reflectance (dB)
Table 9-162 lists the specifications of the colored optical interfaces of the SF64 board.
Table 9-162 Specifications of the colored optical interfaces that comply with ITU-T G.692
Item
Value
Nominal bit rate
10.709 Gbit/s
Dispersion limit (km)
40
Mean launched optical power (dBm)
-1 to 2
Receiver sensitivity (dBm)
-19
Minimum overload (dBm)
0
Maximum allowed dispersion (ps/
800
nm)
Minimum extinction ratio (dB)
10
Laser Safety Class
The laser safety class of the optical interface is CLASS 1, indicating that the maximum output
optical power of each optical interface is less than 10 dBm (10 mW).
Mechanical Specifications
The mechanical specifications of the SF64 board are as follows:
l Dimensions: 25.4 mm (W) x 220 mm (D) x 266.7 mm (H)
l Weight: 0.7 kg (1.5 lb.)
582
Power Consumption
Typical power consumption at 25°C (77°F): 27.3 W
9.6.4 Specifications of the SF64A
Specifications include optical specifications, laser safety class, mechanical specifications, and
power consumption.
Optical Specifications
Table 9-163 lists the optical specifications of the SF64A board.
Table 9-163 Optical specifications of the SF64A board
Item
Value
Nominal bit
10.709 Gbit/s
rate
Application
Ue-64.2c
Ue-64.2d
Ue-64.2e
codea
OBU101 (-29
OBU103 (-28
OBU101 (-34.6
OBU101 (-37.9
dBm to -26
dBm to -25 dBm)
dBm to -32 dBm)
dBm to -34.9
dBm) +
+ OAU103 +
+ CRPC +
dBm) + CRPC +
OAU103b +
DCU03 (60) +
OAU103 +
OAU103 +
DCU03 (60) +
DCU04 (80) +
DCU04 (80) +
DCU04 (80) +
DCU04 (80) +
DCU08 (10) +
DCU04 (80) +
DCU04 (80) +
MR2
MR2
MR2
DCU08 (10) +
MR2
Type of fiber
Single-mode LC
Operating
1550.12
wavelength
range (nm)
Launched
-1 to +2
optical
power range
(dBm)c
Receiver
-19
sensitivity
(dBm)
Minimum
0
overload
(dBm)
Minimum
10.5
extinction
ratio (dB)
583
Item
Value
a: The numbers in the brackets indicate the corresponding parameter values. For example,
"OBU101 (-29 dBm to -26 dBm)" indicates that the optical power amplified by the OBU101
is -29 dBm to -26 dBm.
b: "OBU101 + OAU103" indicates that the specifications of the optical interface are measured
when the OBU101 and OAU103 are used.
c: The parameters are only for the optical modules. The parameters of the amplifier are not
provided.
Table 9-164 lists the specifications of the colored optical interfaces of the SF64A board.
Table 9-164 Specifications of the colored optical interfaces that comply with ITU-T G.692
Item
Value
Nominal bit rate
10.709 Gbit/s
Dispersion limit (km)
40
Mean launched optical power (dBm)
-3 to 2
Receiver sensitivity (dBm)
-19
Minimum overload (dBm)
0
Maximum allowed dispersion (ps/
800
nm)
Minimum extinction ratio (dB)
13.5
Laser Safety Class
The laser safety class of the optical interface is CLASS 1, indicating that the maximum output
optical power of each optical interface is less than 10 dBm (10 mW).
Mechanical Specifications
The mechanical specifications of the SF64A board are as follows:
l Dimensions: 25.4 mm (W) x 220 mm (D) x 266.7 mm (H)
l Weight: 0.9 kg (2.0 lb.)
Power Consumption
Typical power consumption at 25°C (77°F): 35.7 W
9.6.5 Specifications of the SFD64
Specifications include optical specifications, laser safety class, mechanical specifications, and
power consumption.
584
Optical Specifications
Table 9-165 lists the optical specifications of the SFD64 board.
Table 9-165 Optical specifications of the SFD64 board
Item
Value
Nominal bit
10.709Gbit/s
rate
Application
Ue-64.2c
Ue-64.2d
Ue-64.2e
codea
OBU101 (-28
OBU101 (-31
OBU101 (-34
OBU101 (-37
dBm to -31
dBm to -34 dBm)
dBm to -37 dBm)
dBm to -40 dBm)
dBm)+
+ CRPC +
+ CRPC +
+ CRPC +
OAU103b +
OAU103 +
OAU103 +
OAU103 +
DCU03 (60) +
DCU03 (60) +
DCU03 (60) +
DCU03 (60) +
MR2
DCU03 (60) +
DCU04 (80) +
DCU04 (80) +
DCU08 (10) +
MR2
DCU08 (10) +
MR2
MR2
Type of fiber
Single-mode LC
Operating
1550.12
wavelength
range (nm)
Launched
-1 to +2
optical
power range
(dBm)c
Receiver
-19
sensitivity
(dBm)
Minimum
0
overload
(dBm)
Minimum
10.5
extinction
ratio (dB)
a: The numbers in the brackets indicate the corresponding parameter values. For example,
"OBU101 (-28 dBm to -31 dBm)" indicates that the optical power amplified by the OBU101
is -28 dBm to -31 dBm.
b: "OBU101 + OAU103" indicates that the specifications of the optical interface are measured
when the OBU101 and OAU103 are used.
c: The parameters are only for the optical modules. The parameters of the amplifier are not
provided.
585
Table 9-166 lists the specifications of the tunable XFP optical interfaces of the SFD64 board.
Table 9-166 Specifications of the tunable XFP optical interfaces of the SFD64 board
Item
Value
Type of optical
1600 ps/nm - NRZ - tunable
module
Line code format
NRZ - 80 channels tunable
Transmitter parameter specifications at point S
Maximum mean
3
launched power
(dBm)
Minimum mean
-1
launched power
(dBm)
Minimum extinction
9
ratio (dB)
Central wavelength
192.10 to 196.05
(THz)
Central wavelength
±5
deviation (GHz)
Maximum -20 dB
0.3
spectral width (nm)
Minimum side mode
35
suppression ratio
(dB)
Dispersion tolerance
1600
(ps/nm)
Receiver parameter specifications at point R
Receiver type
APD
Operating
1260 to 1600
wavelength range
(nm)
Receiver sensitivity
-24
(FEC on) EOL
(dBm)
Minimum overload
-7
(dBm)
Maximum
-27
reflectance (dB)
586
