SAFETY INFORMATION

EAU10283

Safe Riding

• Ride where other motorists can

Perform the pre-operation checks each

see you. Avoid riding in another

time you use the vehicle to make sure it

motorist’s blind spot.

Be a Responsible Owner

is in safe operating condition. Failure to

●

Many accidents involve inexperi-

As the vehicle’s owner, you are respon-

inspect or maintain the vehicle properly

enced operators. In fact, many op-

sible for the safe and proper operation

increases the possibility of an accident

erators who have been involved in

of your motorcycle.

or equipment damage. See page 5-1

accidents do not even have a cur-

Motorcycles are single-track vehicles.

for a list of pre-operation checks.

rent motorcycle license.

Their safe use and operation are de-

●

This motorcycle is designed to car-

• Make sure that you are qualified

pendent upon the use of proper riding

ry the operator and a passenger.

and that you only lend your

techniques as well as the expertise of

●

The failure of motorists to detect

motorcycle to other qualified op-

the operator. Every operator should

and recognize motorcycles in traf-

erators.

know the following requirements before

fic is the predominating cause of

• Know your skills and limits.

riding this motorcycle.

automobile/motorcycle accidents.

Staying within your limits may

He or she should:

Many accidents have been caused

help you to avoid an accident.

● Obtain thorough instructions from

by an automobile driver who did

• We recommend that you prac-

a competent source on all aspects

not see the motorcycle. Making

tice riding your motorcycle

of motorcycle operation.

yourself conspicuous appears to

where there is no traffic until you

● Observe the warnings and mainte-

be very effective in reducing the

have become thoroughly famil-

nance requirements in this Own-

chance of this type of accident.

iar with the motorcycle and all of

er’s Manual.

Therefore:

its controls.

● Obtain qualified training in safe

• Wear a brightly colored jacket.

●

Many accidents have been caused

and proper riding techniques.

• Use extra caution when you are

by error of the motorcycle opera-

● Obtain professional technical ser-

approaching and passing

tor. A typical error made by the op-

vice as indicated in this Owner’s

through intersections, since in-

erator is veering wide on a turn

Manual and/or when made neces-

tersections are the most likely

sary by mechanical conditions.

places for motorcycle accidents

to occur.

2-1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SAFETY INFORMATION

due to excessive speed or under-

● This motorcycle is designed for on-

● A passenger should also observe

cornering (insufficient lean angle

road use only. It is not suitable for

the above precautions.

for the speed).

off-road use.

• Always obey the speed limit and

Avoid Carbon Monoxide Poisoning

never travel faster than warrant-

Protective apparel

All engine exhaust contains carbon

ed by road and traffic conditions.

The majority of fatalities from motor-

monoxide, a deadly gas. Breathing car-

• Always signal before turning or

cycle accidents are the result of head

bon monoxide can cause headaches,

changing lanes. Make sure that

injuries. The use of a safety helmet is

dizziness, drowsiness, nausea, confu-

other motorists can see you.

the single most critical factor in the pre-

sion, and eventually death.

●

The posture of the operator and

vention or reduction of head injuries.

Carbon Monoxide is a colorless, odor-

passenger is important for proper

●

Always wear an approved helmet.

less, tasteless gas which may be

control.

●

Wear a face shield or goggles.

present even if you do not see or smell

• The operator should keep both

Wind in your unprotected eyes

any engine exhaust. Deadly levels of

hands on the handlebar and

could contribute to an impairment

carbon monoxide can collect rapidly

both feet on the operator foot-

of vision that could delay seeing a

and you can quickly be overcome and

rests during operation to main-

hazard.

unable to save yourself. Also, deadly

tain control of the motorcycle.

●

The use of a jacket, heavy boots,

levels of carbon monoxide can linger

• The passenger should always

trousers, gloves, etc., is effective in

for hours or days in enclosed or poorly

hold onto the operator, the seat

preventing or reducing abrasions

ventilated areas. If you experience any

strap or grab bar, if equipped,

or lacerations.

symptoms of carbon monoxide poison-

with both hands and keep both

●

Never wear loose-fitting clothes,

ing, leave the area immediately, get

feet on the passenger footrests.

otherwise they could catch on the

fresh air, and SEEK MEDICAL TREAT-

Never carry a passenger unless

control levers, footrests, or wheels

MENT.

he or she can firmly place both

and cause injury or an accident.

● Do not run engine indoors. Even if

feet on the passenger footrests.

●

Always wear protective clothing

you try to ventilate engine exhaust

●

Never ride under the influence of

that covers your legs, ankles, and

with fans or open windows and

alcohol or other drugs.

feet. The engine or exhaust sys-

doors, carbon monoxide can rap-

tem become very hot during or af-

idly reach dangerous levels.

ter operation and can cause burns.

2-2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SAFETY INFORMATION

● Do not run engine in poorly venti-

items, including such cargo as

Maximum load:

lated or partially enclosed areas

186 kg (410 lb)

sleeping bags, duffel bags, or

such as barns, garages, or car-

tents, can create unstable han-

ports.

When loading within this weight limit,

dling or a slow steering re-

● Do not run engine outdoors where

keep the following in mind:

sponse.

engine exhaust can be drawn into

●

Cargo and accessory weight

● This vehicle is not designed to

a building through openings such

should be kept as low and close to

pull a trailer or to be attached to

as windows and doors.

the motorcycle as possible. Se-

a sidecar.

curely pack your heaviest items as

close to the center of the vehicle as

Genuine Yamaha Accessories

Adding accessories or cargo to your

possible and make sure to distrib-

Choosing accessories for your vehicle

motorcycle can adversely affect stabili-

ute the weight as evenly as possi-

is an important decision. Genuine

ty and handling if the weight distribution

ble on both sides of the motorcycle

Yamaha accessories, which are avail-

of the motorcycle is changed. To avoid

to minimize imbalance or instabili-

able only from a Yamaha dealer, have

the possibility of an accident, use ex-

ty.

been designed, tested, and approved

treme caution when adding cargo or

●

Shifting weights can create a sud-

by Yamaha for use on your vehicle.

accessories to your motorcycle. Use

den imbalance. Make sure that ac-

Many companies with no connection to

extra care when riding a motorcycle

cessories and cargo are securely

Yamaha manufacture parts and acces-

that has added cargo or accessories.

attached to the motorcycle before

sories or offer other modifications for

Here, along with the information about

riding. Check accessory mounts

Yamaha vehicles. Yamaha is not in a

accessories below, are some general

and cargo restraints frequently.

position to test the products that these

guidelines to follow if loading cargo to

• Properly adjust the suspension

aftermarket

companies produce.

your motorcycle:

for your load

(suspension-ad-

Therefore, Yamaha can neither en-

The total weight of the operator, pas-

justable models only), and

dorse nor recommend the use of ac-

senger, accessories and cargo must

check the condition and pres-

cessories not sold by Yamaha or

not exceed the maximum load limit.

sure of your tires.

modifications not specifically recom-

Operation of an overloaded vehicle

• Never attach any large or heavy

mended by Yamaha, even if sold and

could cause an accident.

items to the handlebar, front

installed by a Yamaha dealer.

fork, or front fender. These

2-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SAFETY INFORMATION

Aftermarket Parts, Accessories, and

limit suspension travel, steering

tor and may limit control ability,

Modifications

travel or control operation, or ob-

therefore, such accessories are

While you may find aftermarket prod-

scure lights or reflectors.

not recommended.

ucts similar in design and quality to

•

Accessories fitted to the handle-

● Use caution when adding electri-

genuine Yamaha accessories, recog-

bar or the front fork area can

cal accessories. If electrical acces-

nize that some aftermarket accessories

create instability due to improper

sories exceed the capacity of the

or modifications are not suitable be-

weight distribution or aerody-

motorcycle’s electrical system, an

cause of potential safety hazards to you

namic changes. If accessories

electric failure could result, which

or others. Installing aftermarket prod-

are added to the handlebar or

could cause a dangerous loss of

ucts or having other modifications per-

front fork area, they must be as

lights or engine power.

formed to your vehicle that change any

lightweight as possible and

of the vehicle’s design or operation

should be kept to a minimum.

Aftermarket Tires and Rims

characteristics can put you and others

•

Bulky or large accessories may

The tires and rims that came with your

at greater risk of serious injury or death.

seriously affect the stability of

motorcycle were designed to match the

You are responsible for injuries related

the motorcycle due to aerody-

performance capabilities and to provide

to changes in the vehicle.

namic effects. Wind may at-

the best combination of handling, brak-

Keep the following guidelines in mind,

tempt to lift the motorcycle, or

ing, and comfort. Other tires, rims, siz-

as well as those provided under “Load-

the motorcycle may become un-

es, and combinations may not be

ing” when mounting accessories.

stable in cross winds. These ac-

appropriate. Refer to page 7-14 for tire

● Never install accessories or carry

cessories may also cause

specifications and more information on

cargo that would impair the perfor-

instability when passing or being

replacing your tires.

mance of your motorcycle. Care-

passed by large vehicles.

fully inspect the accessory before

•

Certain accessories can dis-

using it to make sure that it does

place the operator from his or

not in any way reduce ground

her normal riding position. This

clearance or cornering clearance,

improper position limits the free-

dom of movement of the opera-

2-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU38390

EAU10540

EAU10681

Main switch/steering lock

LOCK

The main switch/steering lock is locat-

All electrical circuits are supplied with

The steering is locked, and all electrical

ed under the main switch/steering lock

power, and the meter lighting, taillight,

systems are off. The key can be re-

cover.

To access the main

license plate light and position lights

moved.

switch/steering lock, slide the cover for-

come on, and the engine can be start-

ward.

ed. The key cannot be removed.

To lock the steering

TIP

The headlight comes on automatically

when the engine is started and stays on

until the key is turned to “OFF”, even if

the engine stalls.

EAU10661

OFF

All electrical systems are off. The key

1. Main switch/steering lock cover

can be removed.

1. Push.

2. Main switch/steering lock

EWA10061

2. Turn.

WARNING

The main switch/steering lock controls

1. Turn the handlebars all the way to

Never turn the key to

“OFF” or

the left.

the ignition and lighting systems, and is

“LOCK” while the vehicle is moving.

2. Push the key in from the “OFF” po-

used to lock the steering. The various

Otherwise the electrical systems will

sition, and then turn it to “LOCK”

positions are described below.

be switched off, which may result in

while still pushing it.

loss of control or an accident.

3. Remove the key.

4-1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU11003

EAU11080

To unlock the steering

Indicator and warning lights

High beam indicator light “

”

This indicator light comes on when the

high beam of the headlight is switched

on.

EAU11363

Fuel level warning light “

”

This warning light comes on when the

fuel level drops below approximately

3.0 L (0.79 US gal, 0.66 Imp.gal). When

this occurs, refuel as soon as possible.

1. Push.

Neutral indicator light “

”

The electrical circuit of the warning light

2. Turn.

High beam indicator light “

”

can be checked by turning the key to

Push the key in, and then turn it to

Right turn signal indicator light “

”

“ON”.

“OFF” while still pushing it.

Left turn signal indicator light “

”

If the warning light does not come on

Engine trouble warning light “

”

for a few seconds, and then go off,

Fuel level warning light “

”

have a Yamaha dealer check the elec-

trical circuit.

EAU11030

Turn signal indicator lights “

”

TIP

and “

”

This model is also equipped with a self-

The corresponding indicator light flash-

diagnosis device for the fuel level de-

es when the turn signal switch is

tection circuit. If a problem is detected

pushed to the left or right.

in the fuel level detection circuit, the fol-

lowing cycle will be repeated until the

EAU11060

Neutral indicator light “

”

malfunction is corrected: The fuel level

This indicator light comes on when the

warning light will flash eight times, and

transmission is in the neutral position.

4-2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU38429

then go off for 3.0 seconds. If this oc-

●

a tachometer (which shows the en-

Multi-function meter unit

curs, have a Yamaha dealer check the

gine speed)

vehicle.

●

a fuel gauge

●

an odometer (which shows the to-

tal distance traveled)

EAU11532

Engine trouble warning light “

”

●

two tripmeters

(which show the

This warning light comes on or flashes

distance traveled since they were

if a problem is detected in the electrical

last set to zero)

circuit monitoring the engine. If this oc-

●

a fuel reserve tripmeter

(which

curs, have a Yamaha dealer check the

shows the distance traveled on the

self-diagnosis system. (See page 4-6

fuel reserve)

for an explanation of the self-diagnosis

Speedometer

●

a clock

device.)

Fuel gauge

●

a self-diagnosis device

The electrical circuit of the warning light

Odometer/tripmeter/fuel reserve tripme-

●

a brightness control mode

ter/clock

can be checked by turning the key to

Tachometer

TIP

“ON”. If the warning light does not come

●

Be sure to turn the key to “ON” be-

EWA12422

on for a few seconds, then go off, have

fore using the “SELECT” and reset

WARNING

a Yamaha dealer check the electrical

switches, except for setting the

circuit.

Be sure to stop the vehicle before

brightness control mode.

making any setting changes to the

●

To switch the odometer, the trip-

multi-function meter unit. Changing

meters and the fuel reserve trip-

settings while riding can distract the

meter displays between kilometers

operator and increase the risk of an

and miles, press the “SELECT”

accident.

switch for at least two seconds.

The multi-function meter unit is

equipped with the following:

● a speedometer (which shows the

riding speed)

4-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

Speedometer

Tachometer

“SELECT” switch

1. Speedometer

1. Tachometer

2. Tachometer red zone

When the key is turned to “ON”, the

speedometer needle will sweep once

The electric tachometer allows the rider

across the speed range and then return

to monitor the engine speed and keep it

to zero in order to test the electrical cir-

within the ideal power range.

cuit.

When the key is turned to “ON”, the ta-

chometer needle will sweep once

across the r/min range and then return

to zero r/min in order to test the electri-

cal circuit.

Reset switch

ECA10031

NOTICE

Do not operate the engine in the ta-

chometer red zone.

Red zone: 5000 r/min and above

4-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

Fuel gauge

Odometer, tripmeters, fuel reserve

between the various tripmeter, odome-

tripmeter and clock

ter, and clock modes in the following or-

der:

F-TRIP → TRIP 1 → TRIP 2 → Clock

→ ODO → F-TRIP

To reset a tripmeter, select it by push-

ing the

“SELECT” switch, and then

push the reset switch for at least one

second. If you do not reset the fuel re-

serve tripmeter manually, it will reset it-

self automatically, and the display will

1. Fuel gauge

return to the prior mode after refueling

1. Odometer/tripmeter/fuel reserve tripme-

The fuel gauge indicates the amount of

ter/clock

and traveling 5 km (3 mi).

fuel in the fuel tank. The needle moves

Push the “SELECT” switch to switch

towards “E” (Empty) as the fuel level

To set the clock:

the display between the odometer

decreases. When the needle reaches

mode “ODO”, the tripmeter modes

“E”, approximately 3.0 L (0.79 US gal,

“TRIP 1” and “TRIP 2” and the clock

0.66 Imp.gal) remain in the fuel tank. If

mode in the following order:

this occurs, refuel as soon as possible.

ODO → TRIP 1 → TRIP 2 → Clock →

When the key is turned to “ON”, the fuel

ODO

gauge needle will sweep once across

If the fuel level warning light comes on

the fuel level range and then return to

(see page 4-2), the odometer display

the current amount in order to test the

will automatically change to the fuel re-

electrical circuit.

serve tripmeter mode

“F-TRIP” and

TIP

1. Clock

start counting the distance traveled

The fuel gauge does not indicate the

from that point. In that case, push the

1. Push the

“SELECT”

switch

correct fuel level for the first 5 km/h (3

“SELECT” switch to switch the display

change the display to the clock

mi/h) after refueling.

mode.

4-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

ECA11590

2. Push the

“SELECT” and reset

● the speedometer, tachometer, and

NOTICE

switches together for at least two

the fuel gauge needles (item num-

seconds.

If the display indicates an error

ber “3”)

3. When the hour digits start flashing,

code, the vehicle should be checked

Select the brightness control mode as

push the reset switch to set the

as soon as possible in order to avoid

follows.

hours.

engine damage.

1. Turn the key to “OFF”.

4. Push the “SELECT” switch, and

2. Push and hold the

“SELECT”

the minute digits will start flashing.

switch.

Brightness control mode

5. Push the reset switch to set the

3. Turn the key to “ON”, and then re-

minutes.

lease the “SELECT” switch after

6. Push the “SELECT” switch and

five seconds.

then release it to start the clock.

Item number “1” is displayed.

Self-diagnosis device

This model is equipped with a self-diag-

nosis device for various electrical cir-

cuits.

If a problem is detected in any of those

1. Multi-function meter unit panel

circuits, the engine trouble warning light

2. LCD

will come on or flash, and then the

3. Speedometer needle

odometer/tripmeter/clock display will

4. Tachometer needle

indicate a two-digit error code.

5. Fuel gauge needle

1. Multi-function meter unit panel

If the odometer/tripmeter/clock display

2. Item number

indicates any error codes, note the

The brightness can be adjusted for the

3. Brightness level

code number, and then have a Yamaha

following:

4. Adjust the multi-function meter unit

dealer check the vehicle.

● the multi-function meter unit panel

panel brightness level by pushing

(item number “1”)

the reset switch.

● the LCD (item number “2”)

4-6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU12347

5. Push the “SELECT” switch to se-

Handlebar switches

lect the LCD.

Item number “2” is displayed.

Left

Adjust the LCD brightness level by

pushing the reset switch.

1. Speedometer needle

2. Tachometer needle

3. Fuel gauge needle

4. Item number

Dimmer switch “

”

5. Brightness level

Turn signal switch “

”

Horn switch “

”

1. LCD

7. Push the “SELECT” switch.

2. Item number

The odometer/tripmeter/clock dis-

3. Brightness level

play will return to the prior mode.

6. Push the “SELECT” switch to se-

lect the speedometer, tachometer,

and the fuel gauge needles.

Item number “3” is displayed.

Adjust the brightness level of the

speedometer, tachometer, and the

fuel gauge needles by pushing the

reset switch.

“SELECT” switch

4-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU38331

Right

and for approximately

15 seconds.

Light switch (for optional

However, the turn signal lights can also

lights) “

”

be canceled manually by pushing the

This model can be equipped with op-

switch in after it has returned to the cen-

tional lights available at a Yamaha

ter position.

dealer.

TIP

Push this switch to the left to turn the

The self-canceling system only oper-

optional lights on and to the right to turn

ates when the vehicle is moving, so that

them off.

ECA15321

the turn signal lights will not self-cancel

NOTICE

while you are stopped at an intersec-

1. Engine stop switch “

”

tion.

Do not install a bulb which exceeds

2. Light switch (for optional lights) “

”

12 V, 35 W in either light, otherwise

3. Start switch “

”

the headlight fuse may blow or the

EAU12500

EAU12400

Horn switch “

”

battery may discharge.

Dimmer switch “

”

Press this switch to sound the horn.

Set this switch to “

” for

the high

EAU12711

beam and to “

” for the low beam.

EAU12660

Start switch “

”

Engine stop switch “

”

Push this switch to crank the engine

EAU12430

Set this switch to “

” before starting

with the starter. See page 6-1 for start-

Turn signal switch “

”

the engine. Set this switch to “

” to

ing instructions prior to starting the en-

To signal a right-hand turn, push this

stop the engine in case of an emergen-

gine.

switch to “

”. To signal a left-hand

cy, such as when the vehicle overturns

turn, push this switch to “

”. When re-

or when the throttle cable is stuck.

EAU41700

leased, the switch returns to the center

The engine trouble warning light will

position.

come on when the key is turned to “ON”

Since this model is equipped with a

and the start switch is pushed, but this

self-canceling system, the turn signal

does not indicate a malfunction.

lights will self-cancel after the vehicle

has traveled both about 150 m (490 ft)

4-8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU44600

EAU12820

EAU12880

“SELECT” switch

Clutch lever

Shift pedal

This switch is used to perform selec-

tions in the odometer, tripmeter, to set

the clock and to set the brightness

mode of the multi-function meter unit.

See “Multi-function meter unit” on page

4-3 for detailed information.

1. Clutch lever

1. Shift pedal

The clutch lever is located at the left

The shift pedal is located on the left

handlebar grip. To disengage the

side of the engine and is used in com-

clutch, pull the lever toward the handle-

bination with the clutch lever when

bar grip. To engage the clutch, release

shifting the gears of the 5-speed con-

the lever. The lever should be pulled

stant-mesh transmission equipped on

rapidly and released slowly for smooth

this motorcycle.

clutch operation.

TIP

The clutch lever is equipped with a

Use your toes or heel to shift up and

clutch switch, which is part of the igni-

your toes to shift down.

tion circuit cut-off system. (See page

4-22.)

4-9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU12890

EAU12941

EAU13121

Brake lever

Brake pedal

Fuel tank cap

1. Brake lever

1. Brake pedal

1. Fuel tank cap lock cover

2. “

” mark

The brake lever is located at the right

The brake pedal is on the right side of

3. Unlock.

handlebar grip. To apply the front

the motorcycle. To apply the rear

4. Lock.

brake, pull the lever toward the handle-

brake, press down on the brake pedal.

bar grip.

To remove the fuel tank cap

Slide the lock cover open, insert the key

into the lock, and then turn it 1/4 turn

clockwise. The lock will be released

and the fuel tank cap can be removed.

To install the fuel tank cap

1. Insert the fuel tank cap into the

tank opening with the key inserted

in the lock and with the “

” mark

facing forward.

4-10

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU13212

2. Turn the key counterclockwise to

Fuel

the original position, remove it, and

Make sure there is sufficient gasoline in

then close the lock cover.

the tank.

TIP

EWA10881

The fuel tank cap cannot be installed

WARNING

unless the key is in the lock. In addition,

Gasoline and gasoline vapors are

the key cannot be removed if the cap is

extremely flammable. To avoid fires

not properly installed and locked.

and explosions and to reduce the

EWA10131

risk of injury when refueling, follow

1. Fuel tank filler tube

WARNING

these instructions.

2. Fuel level

Make sure that the fuel tank cap is

Before refueling, turn off the en-

3. Wipe up any spilled fuel immedi-

properly installed before

riding.

gine and be sure that no one is sit-

ately. NOTICE: Immediately wipe

Leaking fuel is a fire hazard.

ting on the vehicle. Never refuel

off spilled fuel with a clean, dry,

while smoking, or while in the vi-

soft cloth, since fuel may deteri-

cinity of sparks, open flames, or

orate painted surfaces or plastic

other sources of ignition such as

parts. [ECA10071]

the pilot lights of water heaters and

4. Be sure to securely close the fuel

clothes dryers.

tank cap.

Do not overfill the fuel tank. Stop

EWA15151

filling when the fuel reaches the

WARNING

bottom of the filler tube. Because

Gasoline is poisonous and can

fuel expands when it heats up,

cause injury or death. Handle gaso-

heat from the engine or the sun

line with care. Never siphon gaso-

can cause fuel to spill out of the

line by mouth. If you should swallow

fuel tank.

some gasoline or inhale a lot of gas-

oline vapor, or get some gasoline in

your eyes, see your doctor immedi-

4-11

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU13432

ately. If gasoline spills on your skin,

gasoline of a different brand. Use of un-

Catalytic converter

wash with soap and water. If gaso-

leaded fuel will extend spark plug life

This model is equipped with a catalytic

line spills on your clothing, change

and reduce maintenance costs.

converter in the exhaust system.

your clothes.

Gasohol

EWA10861

There are two types of gasohol: gaso-

WARNING

EAU13381

hol containing ethanol and that contain-

The exhaust system is hot after op-

ing methanol. Gasohol containing

eration. To prevent a fire hazard or

ethanol can be used if the ethanol con-

Recommended fuel:

burns:

tent does not exceed 10% (E10). Gas-

PREMIUM UNLEADED GASOLINE

● Do not park the vehicle near

ohol containing methanol is not

ONLY

possible fire hazards such as

recommended by Yamaha because it

Fuel tank capacity:

grass or other materials that

17.0 L (4.49 US gal, 3.74 Imp.gal)

can cause damage to the fuel system

easily burn.

Fuel reserve amount (when the fuel

or vehicle performance problems.

level warning light comes on):

● Park the motorcycle in a place

3.0 L (0.79 US gal, 0.66 Imp.gal)

where pedestrians or children

are not likely to touch the hot

ECA11400

exhaust system.

NOTICE

● Make sure that the exhaust sys-

Use only unleaded gasoline. The use

tem has cooled down before do-

of leaded gasoline will cause severe

ing any maintenance work.

damage to internal engine parts,

● Do not allow the engine to idle

such as the valves and piston rings,

more than a few minutes. Long

as well as to the exhaust system.

idling can cause a build-up of

heat.

Your Yamaha engine has been de-

signed to use premium unleaded gaso-

line with a pump octane number

[(R+M)/2] of 91 or higher, or a research

octane number of

95 or higher. If

knocking (or pinging) occurs, use a

4-12

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

ECA10701

EAU34042

NOTICE

Rider seat

Use only unleaded gasoline. The use

To remove the rider seat

of leaded gasoline will cause unre-

1. Insert the key into the seat lock,

pairable damage to the catalytic

and then turn it counterclockwise.

converter.

1. Projection

2. Seat holder

2. Push the front of the seat down to

lock it in place.

3. Remove the key.

1. Seat lock

TIP

2. Unlock.

Make sure that the seat is properly se-

2. While holding the key in that posi-

cured before riding.

tion, lift the front of the seat up, and

then pull the seat off.

To install the rider seat

1. Insert the projection on the rear of

the seat into the seat holder as

shown.

4-13

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU39155

To install the backrest

Passenger backrest

1. Open the sidebag lids. (See page

4-17.)

To remove the backrest

2. Fit the slot on each backrest brack-

1. Open the sidebag lids. (See page

(left and right side) into the

4-17.)

groove of its holder. NOTICE: Be

2. Insert the key into the passenger

careful not to scratch the fender

backrest lock, turn it counterclock-

when fitting the slot into the

wise, and then remove the key.

groove.

[ECA15372]

1. Backrest lever

2. Passenger backrest

1. Key

1. Slot

2. Unlock.

2. Holder

3. Pull the lever on each side of the

3. Push the rear of the backrest down

backrest upward.

4. While holding the levers in the up-

smoothly but forcefully to lock it in

ward position, lift the backrest up-

place and make sure that the lever

ward and remove it by pulling it to

hook on each side is securely fit

the rear.

over its holder. WARNING! Both

5. Close the sidebag lids.

lever hooks must be securely

fitted over their holder. If the

4-14

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU38342

backrest is loose, a passenger

Helmet holder

might lose balance and fall.

[EWA14283]

1. Helmet holding cable

2. Helmet

1. Helmet holder

2. Helmet holding cable

Place the helmet on the left side of

the vehicle, and then install the rid-

The helmet holder is located under the

er seat. WARNING! Never ride

rider seat. A helmet holding cable is

with a helmet attached to the

provided beside the owner’s tool kit to

helmet holder, since the helmet

secure a helmet to the helmet holder.

may hit objects, causing loss of

control and possibly an acci-

To secure a helmet to the helmet

dent. [EWA10161] NOTICE: Be sure to

holder

place the helmet on the left side

1. Remove the rider seat. (See page

of the vehicle. Some helmets

4-13.)

may contact the muffler when

1. Holder

2. Pass the helmet holding cable

placed on the right side be-

2. Lever hook

through the buckle on the helmet

cause of their size or shape.

4. Insert the key into the passenger

strap as shown, and then hook the

[ECA15331]

backrest lock, turn it clockwise,

cable loop over the helmet holder.

and then remove the key.

5. Close the sidebag lids.

4-15

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU39141

To release the helmet from the hel-

Windshield

met holder

Remove the rider seat, remove the hel-

To remove the windshield

met holding cable from the helmet hold-

1. Insert the key into the windshield

er and the helmet, and then install the

lock, turn it clockwise and then re-

seat.

move the key.

ECA15350

NOTICE

Securely hold the windshield to pre-

vent it from falling when removing.

To install the windshield

1. Key

1. Fit the slot in each windshield

2. Unlock.

bracket (left and right side) into its

2. Remove the windshield by push-

holder. WARNING! Make sure

ing it forward, and then pulling it

that the throttle cables are not

upward as shown. WARNING! Be

pinched. [EWA14301]

careful not to push the motor-

cycle forward when removing

the windshield. The motorcycle

could fall off the sidestand.

[EWA14321]

4-16

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU39133

then remove the key. WARNING!

Sidebags

Make sure that the fastener is

EWA14340

locked in place as shown. [EWA14271]

WARNING

Improper loading or overloading can

cause loss of control and possibly

an accident or personal injury. See

pages 1-1 and 7-14 for important

loading and tire pressure informa-

tion.

1. Slot

●

Always securely close the side-

2. Holder

bags before riding.

3. Throttle cable

●

Distribute weight evenly on

Lock.

Push the windshield backward un-

each side of the motorcycle.

Fastener

til it snaps into place.

●

Do not exceed the load limit of 5

Holder

kg (11 lb) for each sidebag.

●

Do not exceed the maximum

load of 186 kg (410 lb) for the ve-

hicle.

●

Do not exceed 120 km/h (80

mi/h) when riding with luggage

in the sidebags, otherwise han-

dling could be affected. Improp-

er loading, poor tire or overall

motorcycle conditions, poor

Insert the key into the windshield

road surfaces or adverse weath-

lock, turn it counterclockwise until

er conditions may make it nec-

it stops to lock the fastener, and

essary to further reduce the

riding speed.

4-17

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

ECA15380

NOTICE

To avoid locking the key in, never

lock either sidebag and remove the

key from the lock before closing the

lid.

To open a sidebag lid

1. Insert the key into the sidebag

lock, and then turn the key coun-

1. Fastener

To close a sidebag lid

terclockwise.

1. Fold the sidebag lid down so that

To install a sidebag

the latch snaps into place.

Open the sidebag lid.

2. Turn the key clockwise, and then

Place the sidebag on the bracket,

remove it.

and then align all holes in the side-

bag with the holes in the holders

To remove a sidebag

on the bracket.

1. Open the sidebag lid.

2. Turn the fasteners counterclock-

wise, and then remove the side-

bag by pulling it upward.

1. Key

2. Unlock.

TIP

The fasteners will come loose after the

2. Push the key in, and then fold the

sidebags are removed. Be sure not to

sidebag lid up.

lose the fasteners.

1. Hole

2. Holder

4-18

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU38404

Insert the fasteners through the

4. Close the sidebag lid. WARNING!

Adjusting the shock absorber

holes in the sidebag into their hold-

Make sure that all the fasteners

assembly

ers, and then turn them clockwise

in both sidebags are turned

until they stop.

completely clockwise before

This shock absorber assembly is

riding. [EWA14312]

equipped with a spring preload adjust-

ing nut.

TIP

ECA10101

Water can be harmful to untreated

NOTICE

leather. Use Yamaha Saddle Soap or

To avoid damaging the mechanism,

another quality brand according to the

do not attempt to turn beyond the

manufacturer’s directions to clean the

maximum or minimum settings.

leather on the sidebags. Polish the dry

leather with a soft cloth, and then treat

Adjust the spring preload as follows.

with Yamaha Mink Oil or another high-

1. Fastener

quality leather protectant for increased

water resistance.

1. Locknut

2. Spring preload adjusting nut

1. Fastener

1. Loosen the locknut.

2. To increase the spring preload and

thereby harden the suspension,

turn the adjusting nut in direction

(a). To decrease the spring pre-

4-19

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

load and thereby soften the sus-

3. Tighten the locknut to the specified

pension, turn the adjusting nut in

torque. NOTICE: Always tighten

direction (b).

the locknut against the adjust-

●

To make the adjustment, use

ing nut, and then tighten the

the special wrench and exten-

locknut to the specified torque.

sion bar included in the addi-

[ECA10121]

tional tool kit, which was

handed out separately at the

Tightening torque:

Locknut:

purchase of the vehicle.

30 Nm (3.0 m·kgf, 22 ft·lbf)

●

The spring preload setting is

Special wrench

determined by measuring dis-

EWA10221

tance A, shown in the illustra-

WARNING

tion. The shorter distance A is,

This shock absorber assembly con-

the higher the spring preload;

tains highly pressurized nitrogen

the longer distance A is, the

gas. Read and understand the fol-

lower the spring preload. With

lowing information before handling

each complete turn of the ad-

the shock absorber assembly.

justing nut, distance A is

● Do not tamper with or attempt to

changed by 2.0 mm (0.08 in).

open the cylinder assembly.

● Do not subject the shock ab-

Distance A

sorber assembly to an open

flame or other high heat source.

Spring preload:

This may cause the unit to ex-

Minimum (hard):

plode due to excessive gas

Distance A = 162 mm (6.38 in)

Standard:

pressure.

Distance A = 165 mm (6.50 in)

Maximum (soft):

Distance A = 171 mm (6.73 in)

4-20

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU15281

EAU15301

●

Do not deform or damage the

EXUP system

Sidestand

cylinder in any way. Cylinder

This model is equipped with Yamaha’s

The sidestand is located on the left side

damage will result in poor

EXUP (EXhaust Ultimate Power valve)

of the frame. Raise the sidestand or

damping performance.

system. This system boosts engine

lower it with your foot while holding the

●

Do not dispose of a damaged or

power by means of a valve that regu-

vehicle upright.

worn-out shock absorber as-

lates the diameter of the exhaust pipe.

sembly yourself. Take the shock

TIP

The EXUP system valve is constantly

absorber assembly to a Yamaha

The built-in sidestand switch is part of

adjusted in accordance with the engine

dealer for any service.

the ignition circuit cut-off system, which

speed by a computer-controlled servo-

cuts the ignition in certain situations.

motor.

(See further down for an explanation of

ECA10191

the ignition circuit cut-off system.)

NOTICE

EWA10240

● The EXUP system has been set

and extensively tested at the

WARNING

Yamaha factory. Changing

The vehicle must not be ridden with

these settings without sufficient

the sidestand down, or if the side-

technical knowledge may result

stand cannot be properly moved up

in poor performance of or dam-

(or does not stay up), otherwise the

age to the engine.

sidestand could contact the ground

● If the EXUP system cannot be

and distract the operator, resulting

heard when the main switch is

in a possible loss of control.

turned on, have a Yamaha deal-

Yamaha’s ignition circuit cut-off

er check it.

system has been designed to assist

the operator in fulfilling the respon-

sibility of raising the sidestand be-

fore starting off. Therefore, check

this system regularly as described

4-21

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU44891

below and have a Yamaha dealer re-

Ignition circuit cut-off system

pair it if it does not function proper-

The ignition circuit cut-off system (com-

ly.

prising the sidestand switch, clutch

switch and neutral switch) has the fol-

lowing functions.

● It prevents starting when the trans-

mission is in gear and the side-

stand is up, but the clutch lever is

not pulled.

● It prevents starting when the trans-

mission is in gear and the clutch le-

ver is pulled, but the sidestand is

still down.

● It cuts the running engine when the

transmission is in gear and the sid-

estand is moved down.

Periodically check the operation of the

ignition circuit cut-off system according

to the following procedure.

4-22

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

WARNING

With the engine turned off:

1. Move the sidestand down.

If a malfunction is noted, have a Yamaha

2. Make sure that the engine stop switch is turned on.

dealer check the system before riding.

3. Turn the key on.

4. Shift the transmission into the neutral position.

5. Push the start switch.

Does the engine start?

The neutral switch may not be working correctly.

YES

The motorcycle should not be ridden until

checked by a Yamaha dealer.

With the engine still running:

6. Move the sidestand up.

7. Keep the clutch lever pulled.

8. Shift the transmission into gear.

9. Move the sidestand down.

Does the engine stall?

The sidestand switch may not be working correctly.

YES

The motorcycle should not be ridden until

checked by a Yamaha dealer.

After the engine has stalled:

10. Move the sidestand up.

11. Keep the clutch lever pulled.

12. Push the start switch.

Does the engine start?

The clutch switch may not be working correctly.

YES

The motorcycle should not be ridden until

checked by a Yamaha dealer.

The system is OK. The motorcycle can be ridden.

4-23

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INSTRUMENT AND CONTROL FUNCTIONS

EAU38351

A 12-V accessory connected to the

Auxiliary DC connector

auxiliary DC connector under the rider

seat can be used when the key is in the

“ON” position.

1. Auxiliary DC connector

ECA15310

NOTICE

The accessory connected to the

auxiliary DC connector should not

be used with the engine turned off,

and the load must never exceed 36

W (3 A), otherwise the battery may

discharge.

EWA12531

WARNING

To prevent electrical shock or short-

circuiting, make sure that the cap is

installed when the auxiliary DC con-

nector is not being used.

4-24

-------------------------------------------------------------------------------------------------------------------------------------------------------------

FOR YOUR SAFETY - PRE-OPERATION CHECKS

EAU15595

Inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition. Always follow the inspection

and maintenance procedures and schedules described in the Owner’s Manual.

EWA11151

WARNING

Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage.

Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in

this manual, have the vehicle inspected by a Yamaha dealer.

Before using this vehicle, check the following points:

5-1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

FOR YOUR SAFETY - PRE-OPERATION CHECKS

EAU15605

Pre-operation check list

ITEM

CHECKS

PAGE

•

Check fuel level in fuel tank.

Fuel

•

Refuel if necessary.

4-11

•

Check fuel line for leakage.

•

Check oil level in oil tank.

Engine oil

•

If necessary, add recommended oil to specified level.

7-9

•

Check vehicle for oil leakage.

Transfer case oil

•

Check vehicle for oil leakage.

7-13

•

Check operation.

•

If soft or spongy, have Yamaha dealer bleed hydraulic system.

•

Check brake pads for wear.

Front brake

•

Replace if necessary.

7-17,7-17

•

Check fluid level in reservoir.

•

If necessary, add recommended brake fluid to specified level.

•

Check hydraulic system for leakage.

•

Check operation.

•

If soft or spongy, have Yamaha dealer bleed hydraulic system.

•

Check brake pads for wear.

Rear brake

•

Replace if necessary.

7-17, 7-17

•

Check fluid level in reservoir.

•

If necessary, add recommended brake fluid to specified level.

•

Check hydraulic system for leakage.

•

Check operation.

•

If soft or spongy, have Yamaha dealer bleed hydraulic system.

Clutch

•

Check fluid level in reservoir.

7-16, 7-17

•

If necessary, add recommended fluid to specified level.

•

Check hydraulic system for leakage.

•

Make sure that operation is smooth.

•

Check cable free play.

Throttle grip

7-13, 7-20

•

If necessary, have Yamaha dealer adjust cable free play and lubricate cable and

grip housing.

5-2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

FOR YOUR SAFETY - PRE-OPERATION CHECKS

ITEM

CHECKS

PAGE

•

Make sure that operation is smooth.

Control cables

7-20

•

Lubricate if necessary.

•

Check for damage.

•

Check tire condition and tread depth.

Wheels and tires

7-14, 7-16

•

Check air pressure.

•

Correct if necessary.

•

Make sure that operation is smooth.

Brake and shift pedals

7-20

•

Lubricate pedal pivoting points if necessary.

•

Make sure that operation is smooth.

Brake and clutch levers

7-21

•

Lubricate lever pivoting points if necessary.

•

Make sure that operation is smooth.

Sidestand

7-22

•

Lubricate pivot if necessary.

•

Make sure that all nuts, bolts and screws are properly tightened.

Chassis fasteners

—

•

Tighten if necessary.

Instruments, lights, signals

•

Check operation.

—

and switches

•

Correct if necessary.

•

Check operation of ignition circuit cut-off system.

Sidestand switch

4-21

•

If system is not working correctly, have Yamaha dealer check vehicle.

5-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OPERATION AND IMPORTANT RIDING POINTS

EAU15951

EAU45310

EAU16244

Starting the engine

Read the Owner’s Manual carefully to

In order for the ignition circuit cut-off

TIP

become familiar with all controls. If

system to enable starting, one of the

This model is equipped with a lean an-

there is a control or function you do not

following conditions must be met:

gle sensor to stop the engine in case of

understand, ask your Yamaha dealer.

● The transmission is in the neutral

a turnover. To start the engine after a

EWA10271

position.

turnover, be sure to turn the main

WARNING

● The transmission is in gear with

switch to “OFF” and then to “ON”. Fail-

Failure to familiarize yourself with

the clutch lever pulled and the sid-

ing to do so will prevent the engine from

the controls can lead to loss of con-

estand up.

starting even though the engine will

trol, which could cause an accident

See page 4-22 for more informa-

crank when pushing the start switch.

or injury.

tion.

Turn the key to “ON” and make

sure that the engine stop switch is

set to “

”.

The following warning lights

should come on for a few seconds,

then go off.

● Fuel level warning light

● Engine trouble warning light

ECA15482

NOTICE

If a warning light does not go off, see

page

4-2 for the corresponding

warning light circuit check.

6-1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OPERATION AND IMPORTANT RIDING POINTS

EAU16671

ECA10260

Shift the transmission into the neu-

Shifting

NOTICE

tral position. (See page 6-2.) The

neutral indicator light should come

●

Even with the transmission in

on. If not, ask a Yamaha dealer to

the neutral position, do not

check the electrical circuit.

coast for long periods of time

Start the engine by pushing the

with the engine off, and do not

start switch. NOTICE: For maxi-

tow the motorcycle for long dis-

mum engine life, always warm

tances. The transmission is

the engine up before starting

properly lubricated only when

off. Never accelerate hard when

the engine is running. Inade-

the engine is cold! [ECA11131]

quate lubrication may damage

If the engine fails to start, release

1. Shift pedal

the transmission.

the start switch, wait a few sec-

2. Neutral position

●

Always use the clutch while

onds, and then try again. Each

changing gears to avoid damag-

Shifting gears

lets

you

control

the

starting attempt should be as short

ing the engine, transmission,

amount of engine power available for

as possible to preserve the bat-

and drive train, which are not

starting off, accelerating, climbing hills,

tery. Do not crank the engine more

designed to withstand the

etc.

than 10 seconds on any one at-

shock of forced shifting.

The gear positions are shown in the il-

tempt.

lustration.

EAU16681

TIP

To start out and accelerate

To shift the transmission into the neu-

1. Pull the clutch lever to disengage

tral position, press the shift pedal down

the clutch.

repeatedly until it reaches the end of its

2. Shift the transmission into first

travel, and then slightly raise it.

gear. The neutral indicator light

should go out.

3. Open the throttle gradually, and at

the same time, release the clutch

lever slowly.

6-2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OPERATION AND IMPORTANT RIDING POINTS

EAU16841

4. At the recommended shift points

3. Shift the transmission into the neu-

Engine break-in

shown in the following table, close

tral position when the motorcycle

There is never a more important period

the throttle, and at the same time,

is almost completely stopped. The

in the life of your engine than the period

quickly pull the clutch lever in.

neutral indicator light should come

between 0 and 1600 km (1000 mi). For

5. Shift the transmission into second

on.

this reason, you should read the follow-

gear. (Make sure not to shift the

EAU16720

ing material carefully.

transmission into the neutral posi-

Recommended shift points

Since the engine is brand new, do not

tion.)

The recommended shift points during

put an excessive load on it for the first

6. Open the throttle part way and

acceleration and deceleration

are

1600 km (1000 mi). The various parts in

gradually release the clutch lever.

shown in the table below.

the engine wear and polish themselves

7. Follow the same procedure when

to the correct operating clearances.

shifting to the next higher gear.

Shift up points:

During this period, prolonged full-throt-

1st → 2nd: 20 km/h (13 mi/h)

TIP

tle operation or any condition that might

2nd → 3rd: 30 km/h (19 mi/h)

When shifting gears in normal operat-

result in engine overheating must be

3rd → 4th: 40 km/h (25 mi/h)

ing conditions, use the recommended

4th → 5th: 50 km/h (31 mi/h)

avoided.

shift points.

Shift down points:

5th → 4th: 25 km/h (16 mi/h)

EAU17112

4th → 3rd: 25 km/h (16 mi/h)

EAU16700

3rd → 2nd: 25 km/h (16 mi/h)

0-1000 km (0-600 mi)

To decelerate

2nd → 1st: 25 km/h (16 mi/h)

Avoid prolonged operation above 2500

1. Apply both the front and the rear

r/min. NOTICE: After 1000 km (600

brakes to slow the motorcycle.

mi) of operation, the engine oil and

2. Shift the transmission into first

transfer case oil must be changed,

gear when the motorcycle reaches

and the oil filter cartridge or element

25 km/h (16 mi/h). If the engine is

replaced. [ECA10892]

about to stall or runs very roughly,

1000-1600 km (600-1000 mi)

pull the clutch lever in and use the

Avoid prolonged operation above 3500

brakes to stop the motorcycle.

r/min.

6-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OPERATION AND IMPORTANT RIDING POINTS

EAU17213

1600 km (1000 mi) and beyond

Parking

The vehicle can now be operated nor-

When parking, stop the engine, and

mally.

ECA10310

then remove the key from the main

NOTICE

switch.

EWA10311

●

Keep the engine speed out of

WARNING

the tachometer red zone.

●

Since the engine and exhaust

●

If any engine trouble should oc-

system can become very hot,

cur during the engine break-in

park in a place where pedestri-

period, immediately have a

ans or children are not likely to

Yamaha dealer check the vehi-

touch them and be burned.

cle.

●

Do not park on a slope or on soft

ground, otherwise the vehicle

may overturn, increasing the

risk of a fuel leak and fire.

●

Do not park near grass or other

flammable materials which

might catch fire.

6-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

EAU17232

EAU17302

● A running engine has moving

parts that can catch on body

Periodic inspection, adjustment, and lu-

Emission controls not only function to

parts or clothing and electrical

brication will keep your vehicle in the

ensure cleaner air, but are also vital to

parts that can cause shocks or

safest and most efficient condition pos-

proper engine operation and maximum

fires.

sible. Safety is an obligation of the vehi-

performance. In the following periodic

● Running the engine while ser-

cle owner/operator. The most important

maintenance charts, the services relat-

vicing can lead to eye injury,

points of vehicle inspection, adjust-

ed to emissions control are grouped

burns, fire, or carbon monoxide

ment, and lubrication are explained on

separately. These services require

poisoning - possibly leading to

the following pages.

specialized data, knowledge, and

death. See page 2-1 for more in-

EWA10321

equipment. Maintenance, replacement,

formation about carbon monox-

WARNING

or repair of the emission control devic-

ide.

Failure to properly maintain the ve-

es and systems may be performed by

hicle or performing maintenance ac-

any repair establishment or individual

tivities incorrectly may increase

that is certified (if applicable). Yamaha

your risk of injury or death during

dealers are trained and equipped to

service or while using the vehicle. If

perform these particular services.

you are not familiar with vehicle ser-

vice, have a Yamaha dealer perform

service.

EWA15121

WARNING

Turn off the engine when performing

maintenance unless otherwise

specified.

7-1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

EAU17361

Owner’s tool kit

1. Owner’s tool kit

The owner’s tool kit is located under the

rider seat. (See page 4-13.)

The service information included in this

manual and the tools provided in the

owner’s tool kit are intended to assist

you in the performance of preventive

maintenance and minor repairs. How-

ever, additional tools such as a torque

wrench may be necessary to perform

certain maintenance work correctly.

TIP

If you do not have the tools or experi-

ence required for a particular job, have

a Yamaha dealer perform it for you.

7-2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

EAU17600

Periodic maintenance chart for the emission control system

INITIAL

ODOMETER READINGS

600 mi

4000 mi

8000 mi

12000 mi

16000 mi

20000 mi

No.

ITEM

ROUTINE

(1000 km)

(7000 km)

(13000 km)

(19000 km)

(25000 km)

(31000 km)

1 month

6 months

12 months

18 months

24 months

30 months

•

Check fuel hoses for cracks or

Fuel line

damage.

√

•

Replace if necessary.

•

Check condition.

•

Adjust gap and clean.

Spark plugs

√

Replace.

√

Replace.

√

•

Replace every 8000 mi (13000

km) or 12 months.

•

Check and adjust valve clearance

Valve clearance

when engine is cold.

Every 16000 mi (25000 km)

•

Adjust if necessary.

•

Check breather hose for cracks or

Crankcase breather

damage.

√

system

•

Replace if necessary.

Fuel injection

•

Adjust synchronization.

√

•

Check for leakage.

Exhaust system

•

Tighten if necessary.

√

•

Replace gasket(s) if necessary.

Evaporative emis-

•

Check control system for dam-

sion control system

age.

√

(For California only)

•

Replace if necessary.

* Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service.

7-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

EAU32185

General maintenance and lubrication chart

INITIAL

ODOMETER READINGS

600 mi

4000 mi

8000 mi

12000 mi

16000 mi

20000 mi

No.

ITEM

ROUTINE

(1000 km)

(7000 km)

(13000 km)

(19000 km)

(25000 km)

(31000 km)

1 month

6 months

12 months

18 months

24 months

30 months

Air filter element

• Replace.

Every 24000 mi (37000 km)

• Check operation and fluid leak-

Clutch

age.

√

• Correct if necessary.

• Check operation, fluid level, and

Front brake

for fluid leakage.

√

• Replace brake pads if necessary.

• Check operation, fluid level, and

Rear brake

for fluid leakage.

√

• Replace brake pads if necessary.

• Check for cracks or damage.

√

Brake hoses

• Replace.

Every 4 years

• Check runout and for damage.

Wheels

√

• Replace if necessary.

• Check tread depth and for dam-

age.

Tires

• Replace if necessary.

√

• Check air pressure.

• Correct if necessary.

• Check bearings for smooth oper-

Wheel bearings

ation.

√

• Replace if necessary.

Swingarm pivot

• Check bearing assemblies for

√

bearings

looseness.

7-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

INITIAL

ODOMETER READINGS

600 mi

4000 mi

8000 mi

12000 mi

16000 mi

20000 mi

No.

ITEM

ROUTINE

(1000 km)

(7000 km)

(13000 km)

(19000 km)

(25000 km)

(31000 km)

1 month

6 months

12 months

18 months

24 months

30 months

•

Check belt tension.

Drive belt

√

Every 2500 mi (4000 km)

•

Adjust if necessary.

•

Check bearing assemblies for

looseness.

Steering bearings

•

Moderately repack with lithium-

√

Repack.

√

soap-based grease every 16000

mi (25000 km) or 24 months.

•

Check all chassis fitting and fas-

Chassis fasteners

teners.

√

•

Correct if necessary.

Brake lever pivot

•

Apply silicone grease lightly.

√

shaft

Brake pedal pivot

•

Apply lithium-soap-based grease

√

shaft

lightly.

Clutch lever pivot

•

Apply silicone grease lightly.

√

shaft

Shift pedal pivot

•

Apply lithium-soap-based grease

√

shaft

lightly.

•

Check operation.

Sidestand pivot

•

Apply lithium-soap-based grease

√

lightly.

•

Check operation and replace if

Sidestand switch

√

necessary.

•

Check operation and for oil leak-

Front fork

age.

√

•

Replace if necessary.

7-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

INITIAL

ODOMETER READINGS

600 mi

4000 mi

8000 mi

12000 mi

16000 mi

20000 mi

No.

ITEM

ROUTINE

(1000 km)

(7000 km)

(13000 km)

(19000 km)

(25000 km)

(31000 km)

1 month

6 months

12 months

18 months

24 months

30 months

• Check operation and for oil leak-

Shock absorber as-

age.

√

sembly

• Replace if necessary.

Rear suspension

• Apply lithium-soap-based grease

√

link pivots

lightly.

• Change (warm engine before

Engine oil

√

draining).

Engine oil filter car-

• Replace.

√

tridge

• Check for leakage.

• Change at initial 600 mi (1000

Transfer case oil

km) or 1 month, and thereafter

Change.

√

Change.

every 16000 mi (25000 km) or 24

months.

Front and rear brake

• Check operation.

√

switches

• Apply Yamaha chain and cable

Control cables

√

lube or engine oil thoroughly.

• Check operation and free play.

• Adjust the throttle cable free play

Throttle grip hous-

if necessary.

√

ing and cable

• Lubricate the throttle grip housing

and cable.

Lights, signals and

• Check operation.

√

switches

• Adjust headlight beam.

* Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service.

7-6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

TIP

From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.

EAU38440

TIP

● Air filter

• This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com-

pressed air to avoid damaging it.

• The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas.

● Hydraulic brake and clutch systems

• After disassembling the brake or clutch master cylinders, caliper cylinders or clutch release cylinder, always change

the fluid. Regularly check the brake and clutch fluid levels and fill the reservoirs as required.

• Replace the oil seals on the inner parts of the brake or clutch master cylinders, caliper cylinders and clutch release

cylinder every two years.

• Replace the brake and clutch hoses every four years or if cracked or damaged.

7-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

EAU19642

Specified spark plug:

Tightening torque:

Checking the spark plugs

NGK/DPR8EA-9

Spark plug:

The spark plugs are important engine

DENSO/X24EPR-U9

17.5 Nm (1.75 m·kgf, 12.7 ft·lbf)

components, which should be checked

periodically, preferably by a Yamaha

Before installing a spark plug, the spark

TIP

dealer. Since heat and deposits will

plug gap should be measured with a

If a torque wrench is not available when

cause any spark plug to slowly erode,

wire thickness gauge and, if necessary,

installing a spark plug, a good estimate

they should be removed and checked

adjusted to specification.

of the correct torque is 1/4-1/2 turn

in accordance with the periodic mainte-

past finger tight. However, the spark

nance and lubrication chart. In addition,

plug should be tightened to the speci-

the condition of the spark plugs can re-

fied torque as soon as possible.

veal the condition of the engine.

The porcelain insulator around the cen-

ter electrode of each spark plug should

be a medium-to-light tan (the ideal color

when the vehicle is ridden normally),

and all spark plugs installed in the en-

gine should have the same color. If any

1. Spark plug gap

spark plug shows a distinctly different

color, the engine could be operating im-

Spark plug gap:

properly. Do not attempt to diagnose

0.8-0.9 mm (0.031-0.035 in)

such problems yourself. Instead, have

a Yamaha dealer check the vehicle.

Clean the surface of the spark

plug

If a spark plug shows signs of electrode

gasket and its mating surface, and then

erosion and excessive carbon or other

wipe off any grime from the spark plug

deposits, it should be replaced.

threads.

7-8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERIODIC MAINTENANCE AND ADJUSTMENT

EAU19681

EAU38367

completely cooled down, and then

Canister (for California only)

Engine oil and oil filter car-

warmed up again for several minutes to

tridge

normal operating temperature.

The engine oil level should be checked

4. Wait a few minutes until the oil set-

before each ride. In addition, the oil

tles, remove the oil filler cap, wipe

must be changed and the oil filter car-

the dipstick clean, insert it back

tridge replaced at the intervals speci-

into the oil filler hole

(without

fied in the periodic maintenance and

screwing it in), and then remove it

lubrication chart.

again to check the oil level.

To check the engine oil level

TIP

1. Place the vehicle on a level sur-

The engine oil should be between the

This model is equipped with a canister

face and hold it in an upright posi-

minimum and maximum level marks.

to prevent the discharging of fuel vapor

tion. A slight tilt to the side can

into the atmosphere. Before operating

result in a false reading.

this vehicle, make sure to check the fol-

2. Remove the rider seat. (See page

lowing:

4-13.)

● Check each hose connection.

3. Start the engine, warm it up until

● Check each hose and canister for

the engine oil has reached a nor-

cracks or damage. Replace if dam-

mal temperature of 60 °C (140 °F),

aged.

let it continue to idle for ten sec-

● Make sure that the canister breath-

onds, and then turn the engine off.

er is not blocked, and if necessary,

clean it.

TIP

1. Engine oil filler cap

To achieve the proper engine oil tem-

perature for an accurate oil level read-

ing, the engine must have first

7-9

Yamaha XV19CTSY(C), XV19CTY(C) Stratoliner. Service Manual - part 1
