Parker Variable Speed Drive AC30 series. User’s Manual (2017)

Parameter Reference

D-17

Parameter Name

No.

Path

Default

Range

Units

Writable

AR Trip Mask

1472

Same as PNO 1469

00000000

0:01 OVER VOLTAGE
1:02 UNDER VOLTAGE
2:03 OVER CURRENT
3:04 STACK FAULT
4:05 STACK OVER CURRENT
5:06 CURRENT LIMIT
6:07 MOTOR STALL
7:08 INVERSE TIME
8:09 MOTOR I2T
9:10 LOW SPEED I
10:11 HEATSINK OVERTEMP
11:12 INTERNAL OVERTEMP
12:13 MOTOR OVERTEMP
13:14 EXTERNAL TRIP
14:15 BRAKE SHORT CCT
15:16 BRAKE RESISTOR
16:17 BRAKE SWITCH
17:18 LOCAL CONTROL
18:19 COMMS BREAK
19:20 LINE CONTACTOR
20:21 PHASE FAIL
21:22 VDC RIPPLE
22:23 BASE MODBUS BREAK
23:24 24 V OVERLOAD
24:25 PMAC SPEED ERROR
25:26 OVERSPEED
26:27 STO ACTIVE
27:28 FEEDBACK MISSING
28:29 INTERNAL FAN FAIL
29:30 CURRENT SENSOR
30:31 POWER LOSS STOP

31:32 SPEED SENSOR

ALWAYS

AR Trip Mask 2

0796

Setup::Motor Control::Auto Restart
Parameters::Motor Control::Auto
Restart

FFFFFFFF

0:33 A1
1:34 A2
2:35 A3
3:36 A4
4:37 A5
5:38 A6
6:39 A7
7:40 A8

8:41 SPEED ERROR
9:42 PEERTOPEER OVERRUN
10:43 PHASE CONFIG
11:44 ETHERNET IP BREAK

ALWAYS

Defines the trip causes that the AR feature will attempt to automatically reset, followed by an attempt to restart the drive if appropriate.

Refer to Chapter 10 “Trips and Fault Finding” for details of the value corresponding to each trip.

D-18

Parameter Reference

Parameter Name

No.

Path

Default

Range

Units

Writable

AR Initial Delay

1505

Same as PNO 1502

10.000

0.000 to 3600.000

ALWAYS

The timein seconds for which the AR feature will wait before attempting to restart the drive for the first restart attempt, (

1509 AR

Restarts Remaining

equals

1471 AR Max Restarts

). The delay time is started once all trips have become inactive.

The delay time is ignored if the AR feature is configured to simply reset the trip without attempting to restart the motor.

AR Repeat Delay

1506

Same as PNO 1502

60.000

0.000 to 3600.000

ALWAYS

The time in seconds for which the AR feature will wait before attempting to restart the drive for the second and subsequent restart
attempts, (

1509 AR Restarts Remaining

is not equal to

1471 AR Max Restarts

). The delay time is started once all trips have become

inactive.

The delay time is ignored if the AR feature is configured to simply reset the trip without attempting to restart the motor.

AR Trip Mask B

1734

Parameters::Motor Control::Auto
Restart

00000000

ALWAYS

AR Trip Mask 2 B

1735

Parameters::Motor Control::Auto
Restart

00000000

ALWAYS

AR Initial Delay B

1736

Parameters::Motor Control::Auto
Restart

60.000

0.000 to 3600.000

ALWAYS

AR Repeat Delay B

1737

Parameters::Motor Control::Auto
Restart

120.000

0.000 to 3600.000

ALWAYS

The ‘B’ parameters define a second set of trips and associated restart delays. This set operates in parallel with the primary set. If a trip
is enabled in both sets, the restart time associated with the primary set, (A), will apply.

Typically use of the ‘B’ set of trips will be to configure some trips to cause a delayed restart action, while the primary set of trips may be
acted on with a shorter delay.

AR Active

1507

Parameters::Motor Control::Auto Restart

NEVER

Indicates that the AR feature will reset the trip source once all trips have become inactive, (following a delay time if the AR feature has
been configured to also restart the motor).

Parameter Reference

D-19

Parameter Name

No.

Path

Default

Range

Units

Writable

AR Restart Pending

1508

Parameters::Motor Control::Auto Restart

NEVER

Indicates that the AR feature will reset the trip source and attempt to restart the motor once all trips have become inactive and the
relevant delay timer has expired.

AR Restarts Remaining

1509

Parameters::Motor Control::Auto Restart

0 to 20

NEVER

Indicates the number of restart attempts remaining before the AR feature disables itself.

This count is reset to

1471 AR Max Restarts

after a successful manual or remote trip reset. The count is also reset after a period of

trip free operation. This period is the longer of 5 minutes, or 5 * AR Repeat Delay B.

AR Time Remaining

1510

Parameters::Motor Control::Auto Restart

0.000 to 3600.000

NEVER

Indicates the time remaining before a restart attempt will be made. This value starts to count down once all trip sources are inactive.

Functional Description

The AR feature can be configured to operate in one of three modes via the parameter

1470 AR Mode

In all modes the AR feature becomes active when the drive trips on one of the trips selected by parameter

1472 AR Trip Mask

. If the drive trips due

to a trip not selected in

1472 AR Trip Mask

the AR feature will remain in the idle state.

Setting parameter

1469 AR Enable

to FALSE will disable the AR feature regardless of its current state.

1470 AR Mode 0:

Trip Reset

In Trip Reset mode, once the AR feature becomes active it monitors all possible trip sources. Once all trip sources are inactive the AR feature will
attempt to reset the trip event, moving the Sequencing State from the FAULTED state, (see Appendix B: Sequencing Logic). The AR feature resets
the trip as soon as possible, it does not wait for either

1505 Initial Delay

1506 AR Repeat Delay

In this mode the AR feature will not attempt to restart the motor.

This mode may be used when an external supervisiory system is monitoring the Faulted bit in

0661 Status Word

. This bit will be cleared once all trip

sources are inactive and the trip has been successfully cleared, indicating that the drive may be started.

D-20

Parameter Reference

1470 AR Mode 1:

Auto Restart

Caution: when Auto Restart is selected the motor may run unexpectedly.

In Auto Restart mode, once the AR feature becomes active it monitors all possible trip sources. Once all trip sources are inactive the AR feature
starts the programmed delay. Once the delay timer expires the AR feature attempts to reset the trip and to restart the motor.

The AR feature will not restart the motor if it was not running at the time of the trip, nor will it restart the motor if the run signal has been removed at
any time since the trip, (even if it is subsequently re-applied). When a motor restart will not be attempted the AR feature will act as if it had been
configured for

Trip Reset

only. If a motor restart will be attempted the parameter

1508 AR Restart Pending

is set TRUE.

Each time a restart is attempted the value in

1509 Restarts Remaining

is decremented. Once this value reaches zero, any further trip selected for

auto restart will cause the AR feature to disable itself.

1470 AR Mode 2:

Auto Start

Caution: when Auto Start is selected the motor may run unexpectedly.

In Auto Start mode, once the AR feature becomes active it monitors all possible trip sources. Once all trip sources are inactive the AR feature starts
the programmed delay. Once the delay timer expires the AR feature attempts to reset the trip and to restart the motor.

The AR feature will attempt to start the motor even if it was not running at the time of the trip, as long as the Sequencing Logic parameter

0644

Control Word

is configured to run, (typically bits 0, 1, 2 and 3 all set), see Appendix B: Sequencing Logic.

In this mode the parameter

1508 AR Restart Pending

is set TRUE. Each time a restart is attempted the value in

1509 Restarts Remaining

decremented. Once this value reaches zero, any further trip selected for auto restart will cause the AR feature to disable itself.

Recovery from Self Disabled state

The

AR feature will remain in the Self Disabled state indefinitely. It may be re-activated by the trip condition being reset by some other means, (ie.

Manually by pressing the stop key on the GKP, or remotely using trip reset). Alternatively the AR feature may be re-enabled by setting

1469 AR Enable

to FALSE then back to TRUE.

Indication

When the AR feature is activated the parameter

1507 AR Active

is set TRUE.

While a restart is pending the parameter

1508 AR Restart Pending

is set TRUE. In addition the green LED illuminating the run key on the GKP will

flash.
All indicators are reset once the restart, (or trip reset), attempt has been completed or if the AR feature is disabled.

Parameter Reference

D-21

Autotune

Setup:: Motor Control::Autotune
Parameters::Motor Control::Autotune

The autotune is an automatic test sequence performed by the Drive to identify motor model parameters. The motor model is used by the Vector
control modes.

If an induction motor is used, and the control mode is set to vector control, you

MUST

perform an autotune before operating the Drive. It the control

mode is set to Open Loop (V/Hz) mode an autotune is not necessary. Whether the drive is in Vector Control mode or in Open Loop mode is
determined by the parameter 0512 Control Strategy in menu Control Mode (see page D-40). Induction motor nameplate parameters must be
entered before running the autotune procedures in order for them to correctly measure motor model parameters.

The motor must be allowed to spin freely. It is acceptable for the motor to be connected to a load during autotune, provided that the load is purely
inertia, with negligible friction, and does not require the motor to produce torque in order to turn.

Sometimes it is not possible to spin the motor freely, for example it has already been connected to a machine and it is not convenient to uncouple it.
In this case a stationary autotune must be carried out.  Select Autotune Mode = STATIONARY.  If you select stationary autotune, a parameter
Nameplate Mag Current will appear.  You must enter the motor magnetising current into this parameter before proceeding with the stationary
autotune. Stationary autotune should be avoided if possible: first, because the magnetising current may not be accurate; second, because operation
above base speed requires the rotating autotune to map the motor characteristics in the field weakening region, and if this is not done, operation
may not be possible above base speed.

If a permanent magnet motor is used and there is no datasheet available from your motor provider, You MUST perform an autotune before operating
the Drive in the Vector control mode . Before running the autotune, some PMAC Motor parameters should be set. Some are available on the motor
nameplate :

0555 PMAC Max Speed

:motor rated speed

0557 PMAC Rated Current

: motor rated current

0558 PMAC Rated Torque

: motor rated torque

1387 PMAC Base Volts

: motor voltage

0556 PMAC Max Current

: motor max current ( if not known, set it to the same value as

0557 PMAC Rated Current

)

0559 PMAC Motor Poles

: motor number of poles ( should be an even number )

0564 PMAC Motor Inertia

: motor inertia : try to set good estimated value, the speed loop will use it for setting correct control parameters

If a permanent magnet motor is used and there is datasheet available from your motor provider, You must either perform an autotune before
operating the Drive in the Vector control mode or enter the required motor parameters from the datasheet.

If a permanent magnet motor is used, setting the

0412 Stack Frequency

to 4kHz or less will help to better estimate the motor resistance (

0562

PMAC Winding Resistance

For best results is is better to carry out the autotune at the maximum speed that is likely to be required. If you run the autotune at a particular speed,
the motor characteristics will be measured up to this speed, and estimated above this speed. If you later discover that you need to run the motor
faster than this, you can do this up to twice the speed at which the autotune is carried out, but the values will not be so accurate, and the control may
not be as good in this region. It is better to run another autotune at the higher speed. If you wish to run the motor at more than twice the speed at
which the autotune was carried out, this will not be allowed. If in doubt, the autotune speed is recorded in the parameter Max Spd When Autotuned,
described below.

D-22

Parameter Reference

Parameter Name

No.

Path

Default

Range

Units

Writable

Autotune Enable

0255

Setup::Motor Control::Autotune
Parameters::Motor Control::Autotune

FALSE

STOPPED

Puts the autotune feature into a state where it will carry out the autotune when the drive is started.

Autotune Mode

0256

Same as PNO 255

0:STATIONARY
1:ROTATING

STOPPED

Selects whether the autotune is carried out on a rotating motor, or whether it just calculates from nameplate data (not the preferred
method). It may be necessary to carry out a stationary autotune if the motor is not free to rotate, for example if it is already connected
to a machine. Leakage inductance (to tune the current loop) and stator resistance may be measured when the motor is stationary, but
other parameters can only be inferred from nameplate data. Use the rotating autotune where possible.

Nameplate Mag Current

1550

Setup::Motor Control::Autotune
Parameters::Motor Control::Autotune

1.00

0.01 to 1000.00

STOPPED

This parameter will only become visible if Autotune Mode = STATIONARY is selected.

If you select stationary autotune, you must enter the motor magnetising current into this parameter before proceeding with the
stationary autotune. If this is not known, it can be approximated from the motor rated current and the power factor, as motor current

times √(1 – PF^2).

The value of mag current entered here will be copied into the magnetising current parameter in the Induction Motor Data menu. If a
rotating autotune is run at a later date, it will be replaced with the more accurate value, and this parameter will be irrelevant.

Autotune Test Disable

0257

Same as PNO 255

0000

0:Stator Resistance
1:Leakage Inductance
2:Magnetising Current
3:Rotor Time Constant
4:Encoder Direction

STOPPED

This is only valid for induction motor autotune

Allows selected tests to be disabled (default all tests are carried out).

Each test can be individually disabled by setting to TRUE.

Parameter Reference

D-23

Parameter Name

No.

Path

Default

Range

Units

Writable

ATN PMAC Test Disable

1388

Setup::Motor Control::Autotune
Parameters::Motor Control::Autotune

0000

0:Stator Resistance
1:Leakage Inductance
2:KE Constant

STOPPED

This is only valid for Permanent magnet motor control

Allows selected tests to be disabled (default all tests are carried out).

Each test can be individually disabled by setting to TRUE.

Bitfield Value : Test

Autotune Ramp Time

0274

Same as PNO 255

10.000

1.000 to 1000.000

STOPPED

Sets the ramp up time to motor base speed during autotune.

ATN PMAC Ls Test Freq

1405

Same as PNO 1388

100.0

0.0 to 500.0

STOPPED

This is only valid for Permanent magnet motor control

Set up the test frequency for the leakage inductance autotune of the permanent magnet motor control0255 Autotune Ramp Time

Max Spd when Autotuned

1459

Parameters::Motor Control::Autotune

-1 to 100000

RPM

NEVER

This parameter records the value of the "100% speed in rpm" parameter at the time the autotune was carried out.

"100% speed in rpm" determines the max speed at which the motor can be commanded to run. When the autotune is carried out, it
can only measure the motor characteristics up to this speed. Beyond this speed, the motor characteristics are filled in according to the
best possible estimate, but are not necessarily accurate.

If at a later date the "100% speed in rpm" parameter is increased, then that will allow the motor to run in the region where the motor
characteristics have been estimated, not measured. The further into this region the motor is allowed to run, the less accurate will be
the motor characteristics and hence the control.

The user is allowed to increase "100% speed in rpm" up to 2 times the value stored in “Max Spd when Autotuned”. Beyond this it is
considered that the resulting control inaccuracy may be unacceptable. In this case, an error will be generated. If the user wishes to
run the motor more than 2 times the value at which it was autotuned, then he must carry out a new autotune at the higher speed.

D-24

Parameter Reference

Functional Description

You MUST carry out an Autotune if you intend to use the drive in vector control mode. If you are using it in
Volts/Hz control an Autotune is not necessary.

Autotune can only be initiated from the “stopped” condition. When the test is complete, the stack is disabled and Autotune Enable is set to FALSE.

Note

Refer to the Chapter 9: Setup Wizard for details on how to perform an Autotune.

Standard Autotune

If an induction motor is fitted, the autotune will identify parameters as follows.

Parameter

Description

Note

MAG CURRENT

Magnetising current

Not measured by Stationary Autotune

STATOR RES

Per phase stator resistance

LEAKAGE INDUC

Per phase stator leakage inductance

MUTUAL INDUC

Per phase mutual inductance

ROTOR TIME CONST

Rotor time constant

This will be identified while the motor is spinning, while measuring the
magnestising current. If stationary autotune is selected, it will be
identified from magnetising current and motor nameplate rpm

♦

The Rotating autotune sequence rotates the motor up to the user-programmed MAX SPEED (

Scale Setpoint

function) in order to

identify these parameters. (A rotating autotune is required if the motor is to be operated above base speed).

♦

The Stationary autotune sequence does not rotate the motor and requires the correct value of MAG CURRENT to be entered.
(Stationey Autotune should only be considered if roatating autotune is not possible to execute).

If a permanent magnet motor is fitted, the autotune will identify parameters as follows.

Parameter

Description

Note

STATOR RES

Phase to phase stator resistance

LEAKAGE INDUC

Phase to phase stator leakage inductance

KE CONSTANT

Back-emf constant

This will be identified while the motor is spinning. If stationary autotune
is selected, it will be identified from motor nameplate parameters

♦

The Stationary autotune sequence does not rotate the motor and requires the correct permanant magnet nameplate value to be
entered.

♦

The Rotating autotune sequence rotates the motor up to the half of the rated motor speed in order to identify these parameters.

Parameter Reference

D-27

Black Box

Parameters::Trips::Black Box Recorder

The Black Box Recorder feature captures the state of the drive in the moments leading up to a trip, and at the moment of the trip. This data is saved
in the drive’s internal memory. The captured data may be transferred to an SD card for investigation.

Parameter Name

No.

Path

Default

Range

Units

Writable

Black Box PNOs[0]

1831

Parameters::Trips::Black Box Recorder

0829

0000 to 3131

ALWAYS

Black Box PNOs[1]

1832

Parameters::Trips::Black Box Recorder

0514

0000 to 3131

ALWAYS

Black Box PNOs[2]

1833

Parameters::Trips::Black Box Recorder

1022

0000 to 3131

ALWAYS

Black Box PNOs[3]

1834

Parameters::Trips::Black Box Recorder

0393

0000 to 3131

ALWAYS

Select up to four parameters that are recorded leading up to a trip along with the fixed set of data.

Copy to SD Card

1829

Parameters::Trips::Black Box Recorder

FALSE

ALWAYS

When a usable SD Card is inserted in the drive, changing this parameter from FALSE to TRUE will start the process of copying the
black box records from internal memory to the SD card. Each record is created as a separate file on the SD card.

Once started, the copy process will continue until all the records have been transferred, this can take up to a minute. To ensure that
the ERROR status is correctly displayed, it is recommended that this value is left at TRUE until the copy has completed.

This parameter is not saved. It is initialised to FALSE when the drive powers on.

Copy Status

1852

Parameters::Trips::Black Box Recorder

0:IDLE
1:ACTIVE
2:ERROR

NEVER

Indicates the status of the copy process. Once the copy is complete the status will return to IDLE. The ERROR status is cleared on
changing the parameter “Clone to SD Card” back to FALSE.

Functional Description

Refer to chapter 10 “Trips and Fault Finding” for further information.

D-28

Parameter Reference

Braking

Parameters::Motor Control::Braking

The braking function controls the rate at which energy from a regenerating motor is dumped into a resistive load. This dumping prevents the dc link
voltage reaching levels which would cause an Overvoltage trip.

Parameter Name

No.

Path

Default

Range

Units

Writable

Braking Enable

0249

Parameters::Motor Control::Braking

TRUE

ALWAYS

Enables operation of the dynamic braking feature.

Brake Resistance

0251

Parameters::Motor Control::Braking

100.00

0.01 to 1000.00

Ohm

STOPPED

The value of the dynamic braking load resistance.

Brake Rated Power

0252

Parameters::Motor Control::Braking

0.10

0.10 to 510.00

STOPPED

The power that the load resistance may continually dissipate.

Brake Overrating

0253

Parameters::Motor Control::Braking

25.00

1.00 to 40.00

STOPPED

Multiplier that may be applied to

Brake Power

for power overloads lasting no more than 1 second.

Braking Active

0254

Parameters::Motor Control::Braking

NEVER

A read-only parameter indicating the state of the brake switch.

Functional Description

When enabled, the

Braking

feature monitors the internal dc link voltage every millisecond and sets the state of the brake switch accordingly. When

using braking, the brake resistor information must be entered it ordered for the resistor protection to operate.

The

Braking

feature operates even when the motor output is not enabled. This allows the function to continually monitor the energy dumped into the

braking resistor, and the energy dissipated across the brake switch. With this information the Drive is able to deduce the loading on the brake
resistor.

Parameter Reference

D-29

If the instantaneous braking power is greater than the Brake Rated Power parameter then this overload is accumulated. If the overload area (power
excess x time) reaches the level set in the Brake Overrating parameter then the brake switch is automatically disabled. This can then lead to an
overvoltage trip protecting the inverter.

The voltage level at which braking occurs is nominally 764V, but rises linearly to 773V as the overload area rises to the Brake Overrating limit. This
improves the brake energy sharing in a multi-brake common d.c. bus system, which can be effected by variation in the exact braking voltage level in
each inverter.

The

Braking

feature also provides a control signal that is used by the

Slew Rate

limit feature. This causes the setpoint to be temporarily frozen

whenever the brake is operating because the dc link voltage exceeds the internal comparison level. This allows the stop rate to be automatically
tuned to the characteristics of the load, motor, Drive and brake resistor.

Brake Overrating x
Brake Rated Power

Brake Rated Power

Time

Overload Area

773V

764V

Nominal Braking
Voltage Level

(Brake Overating-1)

x Brake Rated Power

Overload Area (kWs)

Power

Parameter Reference

D-31

Clone

Setup::Clone
Parameters::Device Manager::Clone

The clone feature allows the drive configuration (application and parameters) to be saved to an SD card and subsequently loaded to the same or a
different drive.

All parameters fall into one of the following cloning categories listed in the parameter table at the end of this appendix:

•

Never

: This type of parameter would never be copied to a new drive. This category includes parameters that are not saved

and parameters that contain information such as runtime statistics.

•

Drive Unique

: This type of parameter is normally unique to the drive, such as the drive name.

•

Power:

This type of parameter is related to the power stack of the drive or to the motor connected to the drive.

•

Other:

Any saved parameter that is not in the other cloning categories. This category is the majority of the parameters

including the application parameters.

The visibility of the following cloning parameters on the GKP may depend on the selection of other cloning parameters and whether an SD card is
fitted.

Parameter Name

No.

Path

Default

Range

Units

Writable

Clone Filename

1534

Setup::Clone
Parameters::Device Manager::Clone

clone

ALWAYS

The filename used for saving or loading the clone file. The file extension for clone files is “.cln” and will be added to the filename if it is
not provided by the user.

A single file contains the information for the parameters and the application.

Clone Direction

1537

Same as PNO 1534

0:SAVE TO FILE
1:LOAD FROM FILE

ALWAYS

Sets whether a clone save or a clone load should be performed.

D-32

Parameter Reference

Parameter Name

No.

Path

Default

Range

Units

Writable

Full Restore

1538

Same as PNO 1534

0:YES
1:PARTIAL

ALWAYS

If the parameter

1537 Clone Direction

is set to LOAD FROM FILE, then the parameter

Full Restore

determines if a full restore or a

partial restore is required from the file specified.

If YES is chosen then all the saved parameters and the saved application will be loaded including ‘drive unique’ parameters.

If PARTIAL is chosen then the user has the choice of what to restore, however ‘drive unique’ parameters will keep their current values.
The following clone parameters apply:

1539 Application

1541 Power Parameters

1540 Other parameters

Notes:

If the power stack of the drive is different to the power stack from which the clone file was saved and the user chooses YES then the
clone load will not be permitted. However the clone load will be permitted if the control module on which the user is restoring is not
attached to a power stack, or if PARTIAL is chosen instead.

The power parameters cannot be restored from a clone file that was saved on a control module with the parameter 0989 Power Stack
Required set to NONE.

Application

1539

Same as PNO 1534

0:LOAD FROM FILE
1:LEAVE CURRENT APP

ALWAYS

If the parameter

1538 Full Restore

is set to PARTIAL, then the parameter

Application

allows the user to either load the application

from the file or to leave the currently installed application.

Power Parameters

1541

Same as PNO 1534

Same as PNO 1540

ALWAYS

If the parameter

1538 Full Restore

is set to PARTIAL, then the parameter

Power Parameters

allows the user to load the ‘power’

parameters from the file, leave the current values or set the values to the defaults.

Notes:

If the power stack of the drive is different to the power stack from which the clone file was saved and the user chooses LOAD FROM
FILE then the clone load will not be permitted. However the clone load will be permitted if the control module on which the user is
restoring is not attached to a power stack, or if LEAVE CURRENT VALUES or SET TO DEFAULT VALUES is chosen instead.

Parker Variable Speed Drive AC30 series. User’s Manual (2017) - page 20
