Parker Variable Speed Drive AC30 series. User’s Manual (2017) - page 1

AC30 series

Variable Speed Drive

HA501718U002 Issue

Product Manual

aerospace

climate

control

electromechanical

filtration
fluid & gas handling

hydraulics

pneumatics

process

control

sealing &

shielding

ENGINEERING

YOUR

SUCCESS.

FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DESCRIBED HEREIN OR RELATED ITEMS

CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.

This document and other information from Parker Hannifin Corporation, its subsidiaries and authorized distributors provide product or

system options for further investigation by users having technical expertise.

The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components

and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met. The user

must analyze all aspects of the application, follow applicable industry standards, and follow the information concerning the product in

the current product catalogue and in any other materials provided from Parker Hannifin Corporation or its subsidiaries or authorized

distributors.

To the extent that Parker Hannifin Corporation or its subsidiaries or authorized distributors provide component or system options based

upon data or specifications provided by the user, the user is responsible for determining that such data and specifications are suitable

and sufficient for all applications and reasonably foreseeable uses of the components or systems.

The above disclaimer is being specifically brought to the user’s attention and is in addition to and not in substitution to the Exclusions

and Limitations on Liability which are set out in the terms and conditions of sale.

AC30 series User’s Manual

Frames D, E, F, G, H, J, K including AC30P & AC30D

HA501718U002 Issue 8

Compatible with Firmware Version 1.13 for AC30V, and Versions 2.13 & 3.13 for AC30P / AC30D, onwards

2017 © Parker Hannifin Manufacturing Limited.

All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any form

or by any means to persons not employed by a Parker Hannifin Manufacturing Limited company without written

permission from Parker Hannifin Manufacturing Ltd. Although evry efford has been taken to ensure the accuracy

of this document it may be necessary, without notice, to make amendments or corect omissions Parker Hannifin

Manufacturing Limited cannot accept responsibility for damage, injury, or expenses resulting thereform.

WARRANTY

The general terms and conditions of sale of goods and/or services of Parker Hannifin Europe Sàrl, Luxembourg,

Switzerland Branch, Etoy, apply to this contract unless otherwise agreed. The terms and conditions are available

on our website: www.parker.com/termsandconditons/switzerland

Parker Hannifin Manufacturing Limited reserved the right to change the content and product specification without

notice.
