36.11
36 30 028
Static balancing of front
wheel/rear wheel
•
Level balancing stand, BMW No. 36 3 600, us-
ing knurled-head screws and bubble
gauge (1/2).
•
Install balancing shaft, BMW No. 36 3 621, and
nut, BMW No. 36 3 622, in front-wheel bearing.
•
Slightly tighten nut to preload bearing.
•
At the rear wheel, secure mounting device,
BMW No. 36 3 618, to the centering collar side
with wheel studs and taper rings.
•
Install balancing shaft, BMW No. 36 3 607, and
nut, BMW No. 36 3 619.
•
Allow wheel to settle.
•
Clean the attachment points for the adhesive
weights.
•
Affix the adhesive weights (3) uniformly spaced
on both sides of the rim opposite the wheel’s
heaviest point.
e
Attention:
Maximum balancing weight 60 g (2.118 oz.).
•
Repeat the balancing procedure as a check.
36 3 600
S360050
36 3 607
36 3 618
36 3 621
36 3 622
36 3 619
3
2
1
