Motorcycle BMW R1150RT. Manual - part 9

00.32

00 11 209

Changing engine oil, replac-

ing oil filter element

(Inspections I, II, III and IV)

L

 Note:

If the motorcycle is ridden only for short distances or
outside temperatures are below 0 °C (32 °F) change
the oil and replace the oil filter element every 3
months, or not later than every
3,000 km (1,800 miles).

•

Change the oil at operating temperature.

•

Remove screw plug.

•

Remove oil drain plug and drain off oil.

•

Use oil filter wrench, BMW No. 11 4 650, to re-
move the oil filter.

•

Coat sealing ring on new oil filter element with oil
and install filter.

•

Reinstall the oil drain plug with a new sealing
ring.

•

Refill with oil to correct level.

•

Insert and tighten the screw plug.

e

 Attention:

Never top up the engine-oil level past the “MAX”
mark.

X

Tightening torque:

Oil filter......................................................... 11 Nm
Oil drain plug................................................ 32 Nm

Engine oil capacities:
with oil filter replacement

................... 3.75 l (6.60 Imp. pints/3.96 US quarts)

without oil filter replacement

................... 3.50 l (6.16 Imp. pints/3.69 US quarts)

Quantity of oil between
MIN and MAX marks

................... 0.50 l (0.88 Imp. pints/0.52 US quarts)

Engine oil grade:
Mineral or synthetic multi-grade oils, API quality
classes up to SH.

R22000080

11 4 650

C000030

BMW recommends Castrol

 00.33

00 11 229

Changing oil in gearbox

(Inspections III and IV)
or at the latest every 2 years

•

Change the gear oil at operating temperature.

•

Remove oil filler plug (1).

•

Install oil drain tube, BMW No. 23 4 791, turning
it back and forth to seat it.

•

Remove oil drain plug (2) and allow the oil to
drain out.

•

Reinstall the oil drain plug with a new sealing
ring.

•

Fill with gearbox oil.

•

Insert oil filler plug with new seal.

X

Tightening torque:

Oil drain plug................................................ 30 Nm
Oil filler plug ................................................. 30 Nm

Quantity:
to bottom edge of filler neck

........ approx. 0.8 l (1.41 Imp. pints/0.85 US quarts)

Oil grade for gearbox:
Brand name SAE 90 API GL 5 hypoid lubricant or
Castrol MTX 75W-140 GL 5

00 11 229

Changing the oil in the rear

wheel drive

(Inspections I, III and IV)
every 40,000 km (24,000 miles) or at the latest
every 2 years

•

Change the gear oil at operating temperature.

e

 Attention:

Do not allow oil to drip onto the rear tyre.

•

Remove oil filler plug (1).

•

Remove oil drain plug (2) and allow the oil to
drain out.

•

Reinstall the oil drain plug with a new sealing
ring.

•

Fill with gearbox oil.

•

Insert oil filler plug with new seal.

X

Tightening torque:

Oil drain plug................................................ 23 Nm
Oil filler plug ................................................. 23 Nm

Quantity:
to bottom of thread in oil filler hole

...... approx. 0.25 l (0.44 Imp. pints/0.26 US quarts)

Oil grade for rear wheel drive:
Brand name hypoid-gear lubricant SAE 90 API GL 5

R22000250

1

2

R28000100

1

2

BMW recommends Castrol

00.34

16 12 008

Replacing fuel filter

(Inspection III)
In normal operating conditions every 40,000 km
(24,000 miles); if fuel quality is poor every
20,000 km (12,000 miles)

•

Remove front and rear seats.

•

Remove left and right side sections of fairing.

•

Disengage stowage compartment and lift it up to
remove.

•

Use a cable tie to secure the stowage compart-
ment to the motorcycle.

d

 Warning:

Fuel is flammable and a hazard to health. Observe
relevant safety regulations.

•

Remove screw securing fuel tank.

•

Disconnect breather and overflow hoses.

•

Disconnect quick-connect adapters of the fuel
lines.

•

Disconnect the plug of the fuel pump.

•

Drain fuel tank.

L

 Note:

To avoid damaging the paintwork of the fuel tank, lay
a cloth between the fork bridge and the fuel tank.

•

Pull fuel tank up and to the rear to remove.

•

Remove fuel pump unit.

R22160010

 00.35

•

Disconnect hoses from fuel filter.

•

Install new fuel filter.

e

 Attention:

Note correct direction of flow through fuel filter.

•

Secure non-reusable hose clips with pliers,
BMW No. 13 1 500.

e

 Attention:

Make sure O-ring (arrow) is in perfect condition. Af-
ter installing, check fuel pump unit for leaks.

•

Installation is the reverse of the removal proce-
dure.

L

 Note:

Make sure that breather lines are correctly routed.

X

Tightening torque:

Fuel pump unit to fuel tank ............................. 5 Nm
Fuel tank to rear frame ................................. 22 Nm

R22160021
