Index motorcycles Motorcycle BMW R1150RT - service repair manual 2001 year
|
|
|
BMW Motorrad Customer Licence No. Mileage Job Order No. Date Mechanic’s signature BM W I n s p e c ti on at 1, 000 k m /6 00 m il e s BM W M a in te na nce
S e rv ic e ev er y
1 0 ,00 0 k m /6 ,000 m il e s BM W I n s p e c ti on e v e ry 2 0 ,000 k m / 12 ,0 0 0 m il e s
BM W An nu al Se rv ic e Use BMW MoDiTeC to read stored error codes from fault memory [Integral ABS] Performing bleed test with BMW MoDiTeC Change engine oil, warmed to normal operating temperature, replace oil filter when used exclusively in short-distance operation, or at outside temperatures below 0°C (32 °F), or no later than every *) Change oil in gearbox, with oil warmed to normal operating temperature at least every 2 years *) Change final-drive lubricant, warmed to normal operating temperature every 40,000 km/25,000 miles, or no later than every 2 years *) Replace fuel filter *) Standard replacement interval is 40,000 km/25,000 miles, with substandard fuel quality every 20,000 km/12,000 miles Check battery electrolyte level, top up with distilled water as necessary Replace intake air filter element Replace air filter every 10,000 km/6,000 miles when vehicle is exposed to high levels of dirt and dust, *) Check front/rear circuit brake fluid Check operation of brake system, inspect for leaks; repair/replace as indicated *) Check brake pads and discs for wear, replace as required *) [Integral ABS] Change wheel-circuit brake fluid at least once a year [Integral ABS] Change control circuit brake fluid at least every 2 years *) [Integral ABS] Perform bleed test with BMW MoDiTeC Check clutch operating fluid level Change clutch hydraulic circuit fluid *) at least every 2 years Check rear lug bolts to ensure they are tight Check rear wheel bearing play by tilting wheel Check swing arm bearings (no play), adjust as required *) Check operation of side stand switch Grease the side stand pivot Retention poly-V-belt Re-adjust new poly-V-belt one time at 10,000 km/6,000 miles Replace poly-V-belt *) Replace poly-V-belt every 60,000 km/35,000 miles Inspect spark plugs Replace spark plugs Retorque cylinder heads Check valve clearance and adjust as necessary Check throttle cable for ease of motion, inspect for abrasion and bends, replace as indicated *) Check cable free travel Final inspection with operation assessment and road safety check: Condition of wheels and tyres, tire inflation pressure – Clutch, shift mechanism, hand and foot brakes, steering – Lighting and signal indicators, warning and indicator lamps, instruments – Optional equipment – Conduct road test as required *) Write up on separate invoice; Not part of standard service procedure UX-VS-2, 07.2001 BMW recommends Castrol |
