Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 999

5G0 601 025 BD - “AUSTIN” Aluminum Rim

Dimension:

7

1

/2 J x 18

Offset (mm):

49

Wheel load in kg:

600

2.7

7

1

/2 J x 18 ET 51

Note

Pay attention to wheels/tires assignments for respective engine

versions which are listed in the overview table.

Explanatory notes of indications on

disc wheels:

Refer to ⇒  Wheel and Tire Guide General Information; Rep. Gr.  44 .

Tightening specifications for wheel

bolts:

Refer to ⇒  Suspension, Wheels, Steering; Rep. Gr.  44 ; Wheels and

Tires; Wheel Bolt Tightening Specifications .

Pitch circle diameter:

112 mm

Number of wheel bolt holes:

5

5G0 601 025 G - “DURBAN” Aluminum Rim

Dimension:

7

1

/2 J x 18

Offset (mm):

51

Wheel load in kg:

615

Golf 2015 ➤

Wheel and Tire Guide - Edition 12.2015

2. Wheel Allocation

9

3

Recommended Summer Tires

⇒ “3.1 Recommended Summer Tires, Mexico”, page 10
⇒ “3.2 Recommended Summer Tires”, page 10

3.1

Recommended Summer Tires, Mexico

Information about the recommended tires. Refer to

⇒ , page 1

 .

Refer to

⇒ “1.2 Explanations about Regions”, page 2

Tire size

Manufacturer

Tread designation

205/55 R 16 91V

Michelin

Energy Saver



Bridgestone

Turanza ER 300 Ecopia



Dunlop

SP Fast Response

225/45 R 17 91W

Dunlop

SP Sport 01A



Bridgestone

Turanza ER 300 Ecopia



Pirelli

Cinturato P7



Dunlop

SportMaxx RT

225/40 R 18 92Y

Continental

Sport Contact 2



Bridgestone

Potenza S001



Dunlop

SportMaxx GT

1) Refer to ⇒  Wheel and Tire Guide General Information; Rep. Gr.  44 .

3.2

Recommended Summer Tires

Information about the recommended tires. Refer to

⇒ , page 1

 .

Refer to

⇒ “1.2 Explanations about Regions”, page 2

Tire size

Manufacturer

Tread designation

225/45 R 17 91W

Dunlop

SportMaxx RT

225/40 R 18 92Y

Bridgestone

Potenza S001

Golf 2015 ➤

Wheel and Tire Guide - Edition 12.2015

10

     Rep. Gr.44 - Wheels, Tires, Wheel Alignment

4

Recommended All Season Tires

⇒ “4.1 Recommended All Season Tires”, page 11

4.1

Recommended All Season Tires

Information about the recommended tires. Refer to

⇒ , page 1

 .

Refer to

⇒ “1.2 Explanations about Regions”, page 2

Tire size

Manufacturer

Tread designation

195/65 R 15 91H

Continental

Pro Contact

205/55 R 16 91H

Continental

Pro Contact



Michelin

Primacy MXV 4



Bridgestone

Turanza EL 400-2



Goodyear

Eagle LS2



Hankook

Optimo H725A

225/45 R 17 91H

Continental

Pro Contact



Michelin

MXM 4

225/40 R 18 92H

Pirelli

P Zero Nero



Goodyear

Eagle LS2

Golf 2015 ➤

Wheel and Tire Guide - Edition 12.2015

4. Recommended All Season Tires

11

5

Recommended Spare Tires and

Emergency Wheels

If necessary, explain to the customer the information about tires

and refer the customer to the Owner's Manual.
The notes listed in the following also apply to spare wheels, e.g.

6.5 J x 16 with 205/55 R 16 tires, which are marked with the let‐

tering “MAX 80 km/h” or “MAX 50 mph” on a yellow sticker.

Note

♦

The vehicle may have a spare wheel with the above mentioned

sticker in place of an emergency wheel, depending on the ve‐

hicle equipment.

♦

Emergency wheel/spare wheel is designed only for sporadic

and brief use. Therefore it is to be replaced with the normal

wheel again as soon as possible.

♦

After mounting the emergency wheel/spare wheel, tire inflation

pressure must be checked as soon as possible.

♦

The tire pressures are listed on the tire pressure label on the

inside of the fuel filler door and on the B-pillar on the driver

side.

♦

Always observe the speed rating on the spare tire on the

emergency wheel (“MAX 80 km/h” or “MAX 50 mph”).

♦

Wide Open Throttle (WOT) acceleration, strong braking and

rapid driving around curves should be prevented.

♦

Never drive with more than one emergency wheel/spare

wheel.

♦

It is not permissible to use snow chains on the emergency

wheel for technical reasons.

♦

If it is necessary to drive with snow chains, then for a front axle

breakdown the emergency wheel must be installed on the rear

axle. The freed-up rear wheel must then be mounted in place

of the faulty front wheel.

Refer to the Parts Catalog for replacement part number.

Disc Wheel

Tires

Dimension

Dimension

Manufacturer

Tread

3

1

/2 J x 18 ET 25.5

T125/70 R 18 99M

Continental

CST 17

3

1

/2 J x 16 ET 25.5

T125/70 R 16 96M

Continental

CST 17

Golf 2015 ➤

Wheel and Tire Guide - Edition 12.2015

12

     Rep. Gr.44 - Wheels, Tires, Wheel Alignment
