5.2.2 Component Location Overview - Telephone System, Wagon 1 - Telephone Microphone - R38- ❑ In the Front Interior Lamp - W1- ❑ Removing and instal‐ ling. Refer to 2 - Information Electronics Control Module 1 - J794- ❑ In the glove compart‐ ment ❑ Connector assignment. Refer to ⇒ Wiring dia‐ grams, Troubleshooting & Component locations. ❑ Removing and instal‐ ling. Refer to . 3 - Mobile Communication 2- Way Signal Amplifier - J984- ❑ Behind the luggage compartment trim panel on the right side ❑ Removing and instal‐ ling. Refer to 4 - Bolt ❑ 2 Nm 5 - Storage Compartment with Cell Phone Interface - R265- ❑ Removing and installing. Refer to ⇒ “5.5 Storage Compartment with Cell Phone Interface R265 , Removing and Installing”, page 44 6 - Bolt ❑ 2 Nm |
