1 - Ignition Key ❑ Removing and instal‐ ling. Refer to . 3 - Anti-Theft Immobilizer Reader Coil - D2- ❑ Removing and instal‐ ling. Refer to . 4 - Mount ❑ With Turn Signal Switch - E2- / Windshield Wiper Intermittent Mode Switch - E22- ❑ With cruise control: with Cruise Control Switch - E45- ❑ Removing and instal‐ ling. Refer to . 5 - Steering Column Electron‐ ics Control Module - J527- ❑ With Airbag Spiral Spring/Return Spring with Slip Ring - F138- ❑ Removing and installing. Refer to ⇒ “8.6 Steering Column Electronics Control Module J527 , Removing and Installing”, page 187 . Caution Risk of damaging the re‐ turn ring. ♦ The return spring with slip ring must not be turned after removing. 6 - Screw ❑ 1 Nm 7 - Ignition/Starter Switch - D- ❑ Removing and installing. Refer to ⇒ “8.4 Ignition/Starter Switch, Removing and Installing”, page 181 . 8 - Steering Lock Housing ❑ Removing and installing. Refer to ⇒ “8.11 Steering Lock Housing, Removing and Installing”, page 195 . 9 - Screw ❑ 1 Nm |
